刘瑜, 杨慧, 于宏兵, 展思辉, 王浩闻, 杜丹瑶. Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠[J]. 环境工程学报, 2013, 7(6): 2191-2196.
引用本文: 刘瑜, 杨慧, 于宏兵, 展思辉, 王浩闻, 杜丹瑶. Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠[J]. 环境工程学报, 2013, 7(6): 2191-2196.
shu
Liu Yu, Yang Hui, Yu Hongbing, Zhan Sihui, Wang Haowen, Du Danyao. Adsorption of PCP-Na from aqueous solution by magnetic monodisperse pompon-like nanocomposites as a novel adsorbent[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2191-2196.
Citation: Liu Yu, Yang Hui, Yu Hongbing, Zhan Sihui, Wang Haowen, Du Danyao. Adsorption of PCP-Na from aqueous solution by magnetic monodisperse pompon-like nanocomposites as a novel adsorbent[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2191-2196.
shu

Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠

  • 1.

    天津市水利科学研究院, 天津 300061

  • 2.

    南开大学环境科学与工程学院, 天津 300071

  • 基金项目:

    水利部公益性行业科研专项(201101059)

  • 中图分类号: X703

Adsorption of PCP-Na from aqueous solution by magnetic monodisperse pompon-like nanocomposites as a novel adsorbent

  • 1.

    Tianjin Hydraulic Science Research Institute, Tianjin 300061, China

  • 2.

    College of Environmental Science and Engineering, Nankai University, Tianjin 300071, China

  • Fund Project:

HTML全文

  • 摘要: 采用溶剂热法成功制备了具有新型形貌的Fe3O4/CS单分散磁性纳米绒球。选取Fe3O4/CS纳米绒球作为磁性吸附剂,研究了其脱除水中五氯酚钠(PCP-Na)的吸附性能。吸附平衡实验表明,Fe3O4/CS吸附脱除PCP-Na的吸附过程能在30 min以内迅速实现吸附平衡,且对于初始浓度为100 mg/L、初始pH为6.5的PCP-Na溶液,在25℃吸附条件下能使溶液中的PCP-Na去除率高达91.5%。吸附等温线和吸附动力学研究表明,Fe3O4/CS吸附脱除PCP-Na的吸附过程属于放热反应,遵循Langmuir吸附模型,符合Lagergren二级动力学方程。此外,在完成吸附过程后,通过一块永久磁铁即能从吸附溶剂中迅速分离出Fe3O4/CS,从而实现吸附剂的有效分离和重复利用,显示了该磁性吸附剂的优越性和用于实际废水处理的潜力。
    Abstract: Magnetic monodisperse pompon-like magnetite/chitosan (Fe3O4/CS) nanocomposites were synthesized by a solvent-thermal method. Then the Fe3O4/CS nanocomposites were used as a magnetic adsorbent for removal of toxic sodium pentachlorophenate (PCP-Na) from aqueous media. Adsorption studies showed that the adsorption equilibrium was achieved within 30 min. And for the PCP-Na solution with initial concentration of 100 mg/L, the prominent removal of PCP-Na (91.5%) was obtained at 25℃ and pH 6.5. Adsorption isotherms and adsorption kinetics showed that the adsorption behavior of PCP-Na on Fe3O4/CS was an exothermic adsorption process, obeyed the Langmuir isotherm and fitted the pseudo-second-order kinetics model. Furthermore, after the adsorption process, the Fe3O4/CS can be easily separated from water with magnets for recycle and reuse, which showed that the magnetic adsorbents have great potential and superiority to be used for treating wastewater in practice.
  • [1] Muir J.,Eduljee G.PCP in the freshwater and marine environment of the European Union.Science of the Total Environment,1999,236(1-3):41-56
    [2] Keith L. H.,Telliard W. A. ES&T special report:Priority pollutants.I.A perspective view.Environmental Science and Technology,1979,13(4):416-423
    [3] Leyva-Ramos R.,Bernal-Jacome L. A.,Mendoza-Barron J.,et al.Kinetic modeling of pentachlorophenol adsorption onto granular activated carbon.Journal of the Taiwan Institute of Chemical,2009,40(6):622-629
    [4] 王琳玲,胡睿,陆晓华.活性碳纤维对水中五氯酚的吸附性能研究.环境科学与技术,2008,31(10):19-25 Wang L.L.,Hu R.,Lu X.H.Adsorption efficiency of pentachlorophenol on activated carbon fibers.Environmental Science & Technology,2008,31(10):19-25(in Chinese)
    [5] Domínguez-Vargas J. R.,Navarro-Rodríguez J. A.,Jesús Beltrán de Heredia,et al.Removal of chlorophenols in aqueous solution by carbon black low-cost adsorbents.Equilibrium study and influence of operation conditions. Journal of Hazardous Materials,2009,169(1-3):302-308
    [6] Akbal F.Sorption of phenol and 4-chlorophenol onto pumice treated with cationic surfactant.Journal of Environmental Management,2005,74(3):239-244
    [7] Kuleyin A.Removal of phenol and 4-chlorophenol by surfactant-modified natural zeolite.Journal of Hazardous Materials,2007,144(1-2):307-315
    [8] 曾普,李梦耀,潘珺,等.D311A树脂吸附五氯苯酚钠的研究.应用化工,2008,37(1):86-89 Zeng P.,Li M.Y.,Pan J.,et al.Study on the adsorption of D311A resin for sodium pentachlorophenolate.Applied Chemical Industry,2008,37(1):86-89(in Chinese)
    [9] 张庆云,张静,杨秀云,等.几种吸附树脂对五氯酚钠吸附性能的研究.离子交换与吸附,2001,17(5):357-362 Zhang Q.Y.,Zhang J.,Yang X. Y.,et al. Study on adsorption effects of several adsorption resins for sodium pentachlorophenate.Ion Exchange and Adsorption,2001,17(5):357-362(in Chinese)
    [10] Bulte J. W. M.,Douglas T.,Witwer B.,et al.Magnetodendrimers allow endosomal magnetic labeling and in vivo tracking of stem cells.Nature Biotechnology,2001,19(12):1141-1147
    [11] Nam J. M.,Thaxton C. S.,Mirkin C. A.Nanoparticle-based bio-bar codes for the ultrasensitive detection of proteins.Science,2003,301(5641):1884-1886
    [12] Hu J.,Chen G.,Lo I. M. C. Removal and recovery of Cr(VI)from wastewater by maghemite nanoparticles.Water Research,2005,39(18):4528-4536
    [13] 黄文,周梅芳.Fe3O4/SDS磁性纳米颗粒吸附水体中的Cd2+和Zn2+.环境工程学报,2012,6(4):1251-1256 Huang W.,Zhou M.F.SDS coated Fe3O4 magnetic nanoparticles for adsorption of Cd2+ and Zn2+ in aqueous solution. Chinese Journal of Environmental Engineering,2012,6(4):1251-1256(in Chinese)
    [14] Ngomsik A. F.,Bee A.,Draye M.,et al.Magnetic nano-and microparticles for metal removal and environmental applications:A review.Comptes Rendus Chimie,2005,8(6-7):963-970
    [15] 胡林林.表层沉积物及其主要组分吸附五氯酚的特征及Cu2+的影响.长春:吉林大学硕士学位论文,2007 Hu L.L.Sorption of pentachlorophenol onto the surficial sediments and its main components and effect of Cu2+.Changchun:Master's Degree Thesis of Jilin University,2007(in Chinese)
    [16] Lawrie G.,Keen I.,Drew B.,et al.Interactions between alginate and chitosan biopolymers characterized using FTIR and XPS.Biomacromolecules,2007,8(8):2533-2541
    [17] Ge J.P.,Hu Y.X.,Biasini M.,et al.Superparamagnetic magnetite colloidal nanocrystal clusters.Angewandte Chemie International Edition,2007,46(23):4342-4345
    [18] Hu J.,Lo I.M.C.,Chen G.H.Comparative study of various magnetic nanoparticles for Cr(VI)removal.Separation and Purification Technology,2007,56(3):249-256
    [19] Wang J. L.,Qian Y.,Horan N.,et al.Bioadsorption of pentachlorophenol(PCP)from aqueous solution by activated sludge biomass. Bioresource Technology,2000,75(2):157-161
    [20] Marouf R.,Khelifa N.,Marouf-Khelifa K.,et al.Removal of pentachlorophenol from aqueous solutions by dolomitic sorbents.Journal of Colloid and Interface Science,2006,297(1):45-53
    [21] Marouf-Khelifa K.,Khelifa A.,Belhakem A.,et al.The adsorption of pentachlorophenol from aqueous solutions onto exchanged Al-MCM-41 materials.Adsorption Science and Technology,2004,22(1):1-12
    [22] Diaz-Flores P.E.,Leyva-Ramos R.,Guerrero-Coronado R.M.,et al.Adsorption of pentachlorophenol from aqueous solution onto activated carbon fiber.Industrial and Engineering Chemistry Research,2006,45(1):330-336
    [23] Khezami L.,Capart R.Removal of chromium(VI)from aqueous solution by activated carbons:kinetic and equilibrium studies.Journal of Hazardous Materials,2005,123(1-3):223-231
    [24] 贾海红,王学松,韩宝平.壳聚糖吸附酸性品红的平衡及动力学研究.环境工程学报,2011,5(8):1800-1804 Jia H. H.,Wang X. S.,Han B. P. Study on equilibrium and kinetics on adsorption of acid fuchsin onto chitosan.Chinese Journal of Environmental Engineering,2011,5(8):1800-1804(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2523
  • HTML全文浏览数:  1152
  • PDF下载数:  1201
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-11-28
  • 刊出日期:  2013-06-11
刘瑜, 杨慧, 于宏兵, 展思辉, 王浩闻, 杜丹瑶. Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠[J]. 环境工程学报, 2013, 7(6): 2191-2196.
引用本文: 刘瑜, 杨慧, 于宏兵, 展思辉, 王浩闻, 杜丹瑶. Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠[J]. 环境工程学报, 2013, 7(6): 2191-2196.
shu
Liu Yu, Yang Hui, Yu Hongbing, Zhan Sihui, Wang Haowen, Du Danyao. Adsorption of PCP-Na from aqueous solution by magnetic monodisperse pompon-like nanocomposites as a novel adsorbent[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2191-2196.
Citation: Liu Yu, Yang Hui, Yu Hongbing, Zhan Sihui, Wang Haowen, Du Danyao. Adsorption of PCP-Na from aqueous solution by magnetic monodisperse pompon-like nanocomposites as a novel adsorbent[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2191-2196.
shu

Fe3O4/CS磁性纳米绒球高效吸附水体中的五氯酚钠

  • 1.  天津市水利科学研究院, 天津 300061
  • 2.  南开大学环境科学与工程学院, 天津 300071
  • 收稿日期:  2012-11-28
基金项目:

水利部公益性行业科研专项(201101059)

摘要: 采用溶剂热法成功制备了具有新型形貌的Fe3O4/CS单分散磁性纳米绒球。选取Fe3O4/CS纳米绒球作为磁性吸附剂,研究了其脱除水中五氯酚钠(PCP-Na)的吸附性能。吸附平衡实验表明,Fe3O4/CS吸附脱除PCP-Na的吸附过程能在30 min以内迅速实现吸附平衡,且对于初始浓度为100 mg/L、初始pH为6.5的PCP-Na溶液,在25℃吸附条件下能使溶液中的PCP-Na去除率高达91.5%。吸附等温线和吸附动力学研究表明,Fe3O4/CS吸附脱除PCP-Na的吸附过程属于放热反应,遵循Langmuir吸附模型,符合Lagergren二级动力学方程。此外,在完成吸附过程后,通过一块永久磁铁即能从吸附溶剂中迅速分离出Fe3O4/CS,从而实现吸附剂的有效分离和重复利用,显示了该磁性吸附剂的优越性和用于实际废水处理的潜力。
