MBR净化受污染地表水的自然启动及稳定运行除污染特性

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

杨威, 赵秋静, 韩正双, 李凯, 梁恒, 李圭白. MBR净化受污染地表水的自然启动及稳定运行除污染特性[J]. 环境工程学报, 2013, 7(4): 1363-1367.
引用本文: 杨威, 赵秋静, 韩正双, 李凯, 梁恒, 李圭白. MBR净化受污染地表水的自然启动及稳定运行除污染特性[J]. 环境工程学报, 2013, 7(4): 1363-1367.
shu
Yang Wei, Zhao Qiujing, Han Zhengshuang, Li Kai, Liang Heng, Li Guibai. Pollutants removal characteristics of natural start-up and steady operation of membrane bioreactor (MBR) for treating polluted surface water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1363-1367.
Citation: Yang Wei, Zhao Qiujing, Han Zhengshuang, Li Kai, Liang Heng, Li Guibai. Pollutants removal characteristics of natural start-up and steady operation of membrane bioreactor (MBR) for treating polluted surface water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1363-1367.
shu

MBR净化受污染地表水的自然启动及稳定运行除污染特性

  • 1.

    哈尔滨商业大学环境工程系,哈尔滨150076

  • 2.

    哈尔滨商业大学生命科学与环境科学研究中心,150076 哈尔滨

  • 3.

    哈尔滨工业大学环境科学与工程博士后流动站,哈尔滨 150090

  • 4.

    哈尔滨工业大学城市水资源与水环境国家重点实验室,150090 哈尔滨

  • 基金项目:

    粤港关键领域重点突破项目(2010Z52401)

    禅城区产学研项目(2010B1023)

    黑龙江省自然科学基金项目(E200818)

    黑龙江省政府博士后基金资助项目

  • 中图分类号: X703

Pollutants removal characteristics of natural start-up and steady operation of membrane bioreactor (MBR) for treating polluted surface water

  • 1.

    Department of Environmental Engineering, Harbin University of Commerce,Harbin 150076, China

  • 2.

    Research Center on Life Sciences and Environmental Sciences,Harbin University of Commerce,Harbin 150076, China

  • 3.

    Post-Doctoral Stations of Environmental Science & Engineering, Harbin Institute of Technology, Harbin 150090, China

  • 4.

    State Key Laboratory of Urban Water Resource and Environment,Harbin Institute of Technology,Harbin 150090,China

  • Fund Project:

摘要

  • 摘要: 为了考察膜生物反应器(MBR)净化受污染地表水自然启动过程中功能菌群的成熟规律及碱度对MBR去除水中氨氮的影响,通过构建小试规模的MBR,考察了MBR处理受污染地表水的自然启动和稳定运行除污染特性。结果表明,MBR在自然启动过程中不会出现异养菌成熟的标志,系统对进水DOC、UV254和CODMn的平均去除率分别仅为(14.5±5.1)%、(12.6±5.6)%和(31.2±7.4)%,应考虑将其他工艺与MBR联用以提高系统的有机物去除能力。启动23天后,MBR中的亚硝化细菌成熟,NH3-N去除率达到80%以上;启动31 d后,MBR中的硝化细菌成熟,出水NO2--N稳定在0.05 mg/L以下。碱度对MBR去除NH3-N效能影响较大,向进水中投加30 mg/L的NaHCO3能使MBR对NH3-N的去除率由(86.1±3.7)%提高至(98.0±1.6)%。在连续曝气、10 L/(m2·h)通量、每10 min反洗15 s运行模式下,MBR的膜污染较为严重,平均TMP增长速率为0.45 kPa/d,需进一步优化相关参数以实现MBR的长期稳定运行。
    Abstract: A bench scale membrane bioreactor (MBR) was constructed for investigating the pollutants removal characteristics of natural start-up and steady operation of MBR for treating polluted surface water. During the experiments, there was no clear indication for the maturity of heterotrophic bacteria, and the removal efficiencies for DOC, UV254 and CODMn were only (14.5±5.1)%, (12.6±5.6)% and (31.2±7.4)%, respectively. Therefore, the MBR need to be coupled with other processes to improve its capacity for removal of organic matter. However, the indications for the maturity of nitroso-bacteria and nitro-bacteria were visible. Respectively, the nitroso-bacteria came to mature 23 days after start-up and nitro-bacteria came to mature 31 days after start-up. During the steady state, the removal of influent NH3-N was over 80% and the effluent NO2--N was bellow 0.05 mg/L. Besides, the results of ammonia removal demonstrated that the alkalinity had significant influence on the performance of MBR for ammonia removal, and the removal efficiency of ammonia increased from (86.1±3.7)% to (98.0±1.6)% while dosing 30 mg/L of NaHCO3 in influent. In the investigation, the membrane in MBR was operated under the conditions of constant flux (10 L/(m2·h)), continuous aeration and backwashing for 15 s after every 10 min of filtration. Under these conditions, obvious membrane fouling was observed, with the average trans-membrane pressure development rate of 0.45 kPa/d. To mitigate the membrane fouling of MBR, it is required to further optimize the relevant operating parameters.
  • [1] 中华人民共和国环境保护部. 2010 中国环境状况公报. 北京: 中华人民共和国环境保护部, 2011.5-14
    [2] Sang Junqiang, Zhang Xihui, Li Lingzhi, et al. Improvement of organics removal by bio-ceramic filtration of raw water with addition of phosphorus. Water Research, 2003,37(19):4711-4718
    [3] 田家宇. 浸没式膜生物反应器组合工艺净化受污染水源水的研究. 哈尔滨: 哈尔滨工业大学博士学位论文, 2009 Tian Jiayu. Study on the hybrid process of submerged membrane bioreactor for treating polluted source water. Harbin: Doctoral Dissertation of Harbin Institute of Technology, 2009(in Chinese)
    [4] Meng Fangang, Chae So-Ryong, Drews Anja, et al. Recent advances in membrane bioreactors (MBRs): Membrane fouling and membrane material. Water Research, 2009,43(6):1489-1512
    [5] Liu Ting, Chen Zhonglin, Yu Wenzheng, et al. Characterization of organic membrane foulants in a submerged membrane bioreactor with pre-ozonation using three-dimensional excitation-emission matrix fluorescence spectroscopy. Water Research, 2011,45(5):2111-2121
    [6] Tian Jiayu, Chen Zhonglin, Nan Jun, et al. Integrative membrane coagulation adsorption bioreactor (MCABR) for enhanced organic matter removal in drinking water treatment. Journal of Membrane Science, 2010,352(1-2):205-212
    [7] Trequer Ronan, Tatin Romuald, Couvert Annabelle, et al. Ozonation effect on natural organic matter adsorption and biodegradation——Application to a membrane bioreactor containing activated carbon for drinking water production. Water Research, 2010,44(3):781-788
    [8] Tian Jiayu, Liang Heng, Li Xing, et al. Membrane coagulation bioreactor (MCBR) for drinking water treatment. Water Research, 2008,42(14):3910-3920
    [9] Williams Mark D., Pirbazari Massoud. Membrane bioreactor process for removing biodegradable organic matter from water. Water Research, 2007,41(17):3880-3893
    [10] 田家宇,杨艳玲,南军,等. 膜生物反应器用于饮用水处理的启动特性. 北京工业大学学报, 2009,35(12):1680-1684 Tian Jiayu, Yang Yanling, Nan Jun, et al. Start-up characteristics of membrane bioreactor (MBR) for drinking water treatment. Journal of Beijing University of Technology, 2009,35(12):1680-1684(in Chinese)
    [11] 高伟,梁恒,韩梅,等. 膜生物反应器净化微污染引黄水库水效能. 哈尔滨工业大学学报, 2011,43(8):31-34 Gao Wei, Liang Heng, Han Mei, et al. Purification of micro-polluted reservoir water from Huanghe river by membrane bioreactors. Journal of Harbin Institute of Technology, 2011,43(8):31-34(in Chinese)
    [12] 国家环境保护总局. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社, 2002.223-226,271-281
    [13] Edzwald James K., Becker William C., Wattier Kevin L. Surrogate parameters for monitoring organic matter and THM precursors. Journal of the American Water Works Association. 1985,77(4):122-132
    [14] Metcalf & Eddy Inc. Wastewater Engineering: Treatment and Reuse (Fourth Edition). New York: McGraw-Hill Companies, 2003.611-616
    [15] 李圭白,张杰. 水质工程学. 北京: 中国建筑工业出版社, 2005.416-423
