不同因素对人工湿地基质脱氮除磷效果的影响

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

陈丽丽, 赵同科, 张成军, 李鹏, 李新荣, 董若征. 不同因素对人工湿地基质脱氮除磷效果的影响[J]. 环境工程学报, 2013, 7(4): 1261-1266.
引用本文: 陈丽丽, 赵同科, 张成军, 李鹏, 李新荣, 董若征. 不同因素对人工湿地基质脱氮除磷效果的影响[J]. 环境工程学报, 2013, 7(4): 1261-1266.
shu
Chen Lili, Zhao Tongke, Zhang Chengjun, Li Peng, Li Xinrong, Dong Ruozheng. Influences of different factors on effect of matrix nitrogen and phosphorus removal in substrates of constructed wetland[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1261-1266.
Citation: Chen Lili, Zhao Tongke, Zhang Chengjun, Li Peng, Li Xinrong, Dong Ruozheng. Influences of different factors on effect of matrix nitrogen and phosphorus removal in substrates of constructed wetland[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1261-1266.
shu

不同因素对人工湿地基质脱氮除磷效果的影响

  • 1.

    北京市农林科学院植物营养与资源研究所,北京 100097

  • 2.

    河北农业大学资源与环境科学学院,保定 071000

  • 基金项目:

    "十二五"国家科技支撑计划课题(2012BAD15B01)

    农业部生态环境保护项目(20110402-201258)

  • 中图分类号: X52

Influences of different factors on effect of matrix nitrogen and phosphorus removal in substrates of constructed wetland

  • 1.

    Institute of Plant Nutrition Resources, Beijing Academy of Agricultural and Forestry Sciences, Beijing 100097, China

  • 2.

    College of Resources and Environmental Sciences, Agricultural University of Hebei, Baoding 071000, China

  • Fund Project:

摘要

  • 摘要: 在人工配制的污水中投入一定量的基质,不同条件下振荡培养,评价沸石、炉渣和陶瓷滤料3种基质在不同因素影响下对氨氮(NH4+-N)和总磷(TP)的吸附能力。结果表明,不同吸附时间时,沸石对NH4+-N的吸附效果最好,陶瓷滤料对TP的吸附效果最好;进水浓度对沸石吸附NH4+-N的影响较大,其吸附量随进水浓度的增大而增大,进水浓度对炉渣和陶瓷滤料吸附NH4+-N及炉渣吸附TP影响不大;3种基质对NH4+-N和TP的吸附量均是随吸附剂量的增加而降低,要达到较好的去污效果,应根据实验结果考虑基质投入量;pH值对沸石吸附NH4+-N影响显著,pH值6~7范围内吸附效果最好,pH值8~12的碱性条件有利于基质对TP的吸附。
    Abstract: The three substrates of zeolite, blast furnace slag and ceramic filter were put into constructed sewage to evaluate their absorption capacity to the ammonium nitrogen (NH4+-N) and total P (TP) under different influencing factors. The results showed that at different adsorption times, the zeolite had a best absorption capacity to NH4+-N, and the ceramic filter had a strong absorption effect to TP.The concentration of sewage had a bigger effect on the absorption of zeolite to NH4+-N, and the absorption amount increased with the concentration of sewage increasing, while it had little effect on the absorption of blast furnace slag to NH4+-N and TP, and ceramic filter to NH4+-N.The three substrates absorption amount to NH4+-N and TP decreased with the adsorbent amount increasing. To achieve a better absorption capacity, tests results could be considered based on the substrate inputs. The pH value had a significant effect on the zeolite absorption to NH4+-N, and it had a best absorption effect when pH was at 6~7,whereas when pH was at 8~12 (alkaline conditions),the matrix had a strong absorption to TP.
  • [1] 王东,李岚波,王磊.北方地区人工湿地系统去除氨氮、总磷试验研究.环境保护科学,2008,34(3):86-87 Wang D., Li L. B., Wang L.Experimental study on purification effect of ammonia nitrogen and total phosphorus by constructed wetlands system in northern area. Environmental Protection Science, 2008,34(3):86-87(in Chinese)
    [2] 蔡明凯,邓春光.评述影响人工湿地除磷的因子.中国水运,2007,7(6):74-75 Cai M. K., Deng C. G. Review of impact factor wetland phosphorus removal. China Water Transport, 2007,7(6):74-75(in Chinese)
    [3] 陈英旭.环境学.北京:中国环境科学出版社,2001
    [4] 陆健健,何文珊,童春富,等.湿地生态学.北京:高等教育出版社,2006
    [5] 朱彤,许振成,胡康萍,等.人工湿地污水处理系统应用研究.环境科学研究,1991,4(5):17-22 Zhu T., Xu Z. C., Hu K. P., et al. Applied research of constructed wetland wastewater treatment system. Research of Environmental Science, 1991,4(5):17-22(in Chinese)
    [6] 籍国东,倪晋仁.人工湿地废水生态处理系统的作用机制.环境污染治理技术与设备,2004,5(6):71-75 Ji G. D., Ni J. R. Mechanisms of constructed wetland wastewater ecological treatment systems. Techniques and Equipment for Environmental Pollution Control, 2004,5(6):71-75(in Chinese)
    [7] 刘波,陈玉成,王莉玮,等.4种人工湿地填料对磷的吸附特性分析.环境工程学报,2010,4(1):48-49 Liu B., Chen Y. C., Wang L. W., et al.Phosphorus adsorption characteristics of four substrates in constructed wetland. Chinese Journal of Environmental Engineering, 2010,4(1):48-49(in Chinese)
    [8] 袁东海,景丽洁,张孟群,等.几种人工湿地基质净化磷素的机理.中国环境科学,2004,24(5):614-617 Yuan D. H., Jing L. J., Zhang M. Q., et al.Mechanism of phosphorus purification in some kinds of substrates constructed wetland systems. China Environmental Science, 2004,24(5):614-617(in Chinese)
    [9] 徐祖信,谢海林,叶建锋,等.模拟煤灰渣垂直潜流人工湿地的除磷性能分析.环境污染与防治,2007,29(4):241-243 Xu Z. X., Xie H. L., Ye J. F., et al.Feasibility of phosphorus removal by coal ash in a vertical flow constructed wetland system. Environmental Pollution & Control, 2007,29(4):241-243(in Chinese)
    [10] 陈博谦, 王星, 尹澄清. 湿地土壤因素对污水处理作用的模拟研究.城市环境与城市生态, 1999,12(1):19-21 Chen B. Q., Wang X., Yin C. Q.The role of soils in wastewater treatment in a simulated constructed wetland. Urban Environment & Urban Ecology, 1999,12(1):19-21(in Chinese)
    [11] 吴振斌, 陈辉蓉, 贺锋,等.人工湿地系统对污水磷的净化效果.水生生物学报,2001,25(1):28-35 Wu Z. B., Chen H. R., He F., et al. Primary studies on the purification efficiency of phosphorus by means of constructed wetland system. Acta Hydrobiologica Sinica, 2001,25(1):28-35(in Chinese)
    [12] 国家环境保护总局.水和废水监测分析方法(第4版).北京:中国环境科学出版社,2002
    [13] 赵玉华,邢国印,赵杰.人工湿地填料对氮磷的静态吸附筛选实验.辽宁化工,2009,38(11):773-776 Zhao Y. H., Xing G. Y., Zhao J. Static adsorption experiments of the filled materials in constructed wetland for nitrogen and phosphorus. Liaoning Chemical Industry, 2009,38(11):773-776(in Chinese)
    [14] 姜应和,柳君侠.粉煤灰碎砖颗粒除磷实验研究.环境工程学报,2011,5(7):1532-1537 Jiang Y. H., Liu J. X. Experimental study on phosphorus removal by fly ash brickbat particle. Chinese Journal of Environmental Engineering, 2011,5(7):1532-1537(in Chinese)
    [15] 聂发辉.系统评价天然蛭石吸附氨氮的效果.四川环境,2004,23(4):15-19 Nie F. H. A systematic study on the effect of crude vermiculite on the adsorption of NH3-N.Sichuan Environment, 2004,23(4):15-19(in Chinese)
    [16] 黄辉,赵洁,饶群,等.人工湿地基质除磷影响因素研究进展.环境科学与技术,2006,29(11):112-115 Huang H., Zhao J., Rao Q., et al. Review on influential factors of phosphorus removal by substrates in constructed wetland. Environmental Science & Technology, 2006,29(11):112-115(in Chinese)
    [17] 胡曰利,吴晓芙,聂发辉.天然蛭石对污水中氨氮吸附去除率的影响.中南林学院学报,2004,24(1):30-33 Hu Y. L., Wu X. F., Nie F. H. Study of removal rate of ammonium by vermiculite adsorption. Journal of Central South University of Forestry & Technology, 2004,24(1):30-33(in Chinese)
    [18] 王雅萍,刘云,董元华,等.斜发沸石对氨氮废水吸附性能的实验研究.非金属矿,2007,30(6):60-62 Wang Y. P., Liu Y., Dong Y. H., et al.Adsorption of ammonia nitrogen from waste water by natural clinoptilolite.Non-Metallic Mines, 2007,30(6):60-62(in Chinese)
    [19] 孙大志,李绪谦,潘晓峰.氨氮在土壤中的吸附/解吸动力学行为的研究.环境科学与技术,2007,30(8):16-18 Sun D. Z., Li X. Q., Pan X. F.Ammonia absorption/desorption behavior in soil. Environmental Science and Technology, 2007,30(8):16-18(in Chinese)
    [20] Rozic M., Cerjan-Stefanovic S., Kurajica S., et al.Ammoniacal nitrogen removal from water by treatment with clays and zeolites. Water Research, 2000,34(14):3675-3681
    [21] 张冬娜,宋永会,弓爱君,等.利用丝光沸石吸附高浓度氨氮的研究.安全与环境学报,2006,6(5):17-20 Zhang D. N., Song Y. H., Gong A. J., et al. Study on adsorption behavior of high-concentration ammonium nitrogen by means of mordenite.Journal of Safety and Environment,2006,6(5):17-20(in Chinese)
    [22] Ye H. P., Chen F. Z., Sheng Y. Q. Adorption of phosphate from aqueous solution onto modified palygorskites.Separation Purification Technology, 2006,50(3):283-290
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1859
  • HTML全文浏览数:  734
  • PDF下载数:  1957
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-04-17
  • 刊出日期:  2013-04-09
陈丽丽, 赵同科, 张成军, 李鹏, 李新荣, 董若征. 不同因素对人工湿地基质脱氮除磷效果的影响[J]. 环境工程学报, 2013, 7(4): 1261-1266.
引用本文: 陈丽丽, 赵同科, 张成军, 李鹏, 李新荣, 董若征. 不同因素对人工湿地基质脱氮除磷效果的影响[J]. 环境工程学报, 2013, 7(4): 1261-1266.
shu
Chen Lili, Zhao Tongke, Zhang Chengjun, Li Peng, Li Xinrong, Dong Ruozheng. Influences of different factors on effect of matrix nitrogen and phosphorus removal in substrates of constructed wetland[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1261-1266.
Citation: Chen Lili, Zhao Tongke, Zhang Chengjun, Li Peng, Li Xinrong, Dong Ruozheng. Influences of different factors on effect of matrix nitrogen and phosphorus removal in substrates of constructed wetland[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1261-1266.
shu

不同因素对人工湿地基质脱氮除磷效果的影响

  • 1.  北京市农林科学院植物营养与资源研究所,北京 100097
  • 2.  河北农业大学资源与环境科学学院,保定 071000
  • 收稿日期:  2012-04-17
基金项目:

"十二五"国家科技支撑计划课题(2012BAD15B01)

农业部生态环境保护项目(20110402-201258)

摘要: 在人工配制的污水中投入一定量的基质,不同条件下振荡培养,评价沸石、炉渣和陶瓷滤料3种基质在不同因素影响下对氨氮(NH4+-N)和总磷(TP)的吸附能力。结果表明,不同吸附时间时,沸石对NH4+-N的吸附效果最好,陶瓷滤料对TP的吸附效果最好;进水浓度对沸石吸附NH4+-N的影响较大,其吸附量随进水浓度的增大而增大,进水浓度对炉渣和陶瓷滤料吸附NH4+-N及炉渣吸附TP影响不大;3种基质对NH4+-N和TP的吸附量均是随吸附剂量的增加而降低,要达到较好的去污效果,应根据实验结果考虑基质投入量;pH值对沸石吸附NH4+-N影响显著,pH值6~7范围内吸附效果最好,pH值8~12的碱性条件有利于基质对TP的吸附。
