SCR系统超洁净排放调整与出口NOx均匀性分析
Ultra clean emissions adjustment and uniformity analysis of export NOx for SCR systems
-
摘要: 针对典型SCR系统普遍存在的出口烟道与烟囱处NOx在线监测值不一致的问题与超洁净排放要求，选择2台流场与喷氨格栅结构不同的SCR系统进行性能与优化调整实验。通过对喷氨格栅区域烟气分布与喷氨调整前后出口烟道内NOx分布的测试，分析了导致问题的原因与调整方案的有效性以及不同喷氨格栅结构的优劣性。结果表明：喷氨格栅区域烟气流场分布与区域喷氨量的不一致性是导致不同点位NOx浓度在线监测值不一致的原因；依据调整方案能有效实现SCR出口烟道内NOx浓度均匀分布与超洁净排放的要求；改造后，能针对烟道宽度方向上烟气不均现象进行区域喷氨量调整的喷氨格栅结构Ⅱ与更均匀的烟气分布，促使调整后的2号机组A、B两侧出口NOx浓度分布相对标准偏差明显优于1号机组。Abstract: Aiming at typical SCR system common problem that the online monitoring values of NOx in the outlet flue pipes did not match the online monitoring value of NOx in the chimney and the requirement of ultra clean discharge, two SCR systems with the different flue gas flow fields and the different ammonia-injection grid structures were chosen to do the performance test and optimized adjustment test. The causes of common problem, the effects of adjustment strategies and the advantages and disadvantages of different ammonia-injection grid structures were analyzed by measuring the flue gas distribution in the areas of ammonia-injection grid and measuring the NOx distribution in the outlet flue pipes. The results showed that the common problem was caused by the amount of ammonia-injection did not match the regularity of flue gas flow field. According to the adjustment scheme, the uniform distribution of NOx concentration in the outlet flue pipes and the requirement of ultra clean discharge could be effectively realized. After promoting adjustment, the relative standard deviation of NOx concentration distribution in the outlet flue pipes of unit 2 A and B sides were significantly better than that of the unit 1.One of the reasons was the ammonia-injection grid structure Ⅱ which could efficiently adjust the amount of ammonia-injection according to the uneven distributed flue gas in the width direction. And the other reason was that the distribution of flue gas flow field was more uniform in the unit 2.
-
[1] 中华人民共和国环境保护部. 火电厂大气污染物排放标准:GB 13223-2011[S]. 北京:中国环境科学出版社, 2011 [2] 郭崇云. 《2013中国环境状况公报》发布[J]. 纸和造纸,2014,33(6):91 [3] 方绪文. 660 MW机组SCR氨喷射系统故障排除及调整[J]. 节能技术, 2015, 33(6):562-565 [4] 刘晓敏. 烟气脱硝SCR装置喷氨优化研究[J]. 热力发电, 2012, 41(7):81-83 [5] 胡劲逸. 基于氨逃逸浓度场的SCR喷氨协调优化控制[D]. 杭州:浙江大学, 2015 [6] 郭金龙, 火电机组选择性催化还原脱硝喷氨的优化控制[D]. 北京:华北电力大学(北京), 2011 [7] 张文志, 曾毅夫. SCR脱硝系统烟道内流场优化[J]. 环境工程学报, 2015, 9(2):883-887 [8] 董建勋, 李辰飞, 王松岭, 等. 还原剂分布不均匀对脱硝性能影响的模拟分析[J]. 电站系统工程, 2007, 23(1):20-21 [9] LEI Z G, WEN C P, CHEN B H. Optimization of internals for selective catalytic reduction(SCR) for NO removal[J]. Environmental Science and Technology, 2011, 45:3437-3444 [10] 毛剑宏. 大型电站锅炉SCR烟气脱硝系统关键技术研究[D]. 杭州:浙江大学, 2011 [11] 周志明, 樊卫国, 董立春. 选择性催化还原脱硝系统烟道中导流板设计数值模拟[J]. 重庆大学学报(自然科学版), 2009, 32(10):1187-1192 [12] 凌忠钱, 曾宪阳, 胡善涛, 等. 电站锅炉SCR烟气脱硝系统优化数值模拟[J]. 动力工程学报, 2014, 34(1):50-56 [13] 杨超, 张杰群, 郭婷婷, 等. SCR烟气脱硝装置烟气流场数值模拟[J]. 东北电力大学学报, 2012, 32(1):66-70 [14] 肖育军, 陶莉, 符思聪, 等. 脱硝系统烟气流场的性能与优化[J]. 环境工程学报, 2016, 10(8):4407-4413 [15] 蒋新伟. 变截面烟道SCR烟气脱硝反应器整流装置的优化研究[D]. 杭州:浙江大学, 2010 [16] 王乐乐, 周健, 姚友工, 等. 烟气脱硝SCR氨喷射系统调整效果评估[J].中国电力, 2015, 48(4):16-22 [17] 汤元强, 吴国江, 赵亮. SCR脱硝系统喷氨格栅优化设计[J]. 热力发电, 2013, 42(3):59-62 [18] 国家能源局. 燃煤电厂烟气脱硝装置性能验收试验规范:DL/T 260-2012[S]. 北京:中国电力出版社, 2012 [19] 李坦, 靳世平, 黄素逸,等. 流场速度分布均匀性评价指标比较与应用研究[J]. 热力发电, 2013, 42(11):60-63 -
