UASB-PACT工艺处理有机颜料废水中试研究

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

郭新双, 苏本生, 宋英豪, 贾立敏, 徐冬利, 王旭鹏. UASB-PACT工艺处理有机颜料废水中试研究[J]. 环境工程学报, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
引用本文: 郭新双, 苏本生, 宋英豪, 贾立敏, 徐冬利, 王旭鹏. UASB-PACT工艺处理有机颜料废水中试研究[J]. 环境工程学报, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
shu
GUO Xinshuang, SU Bensheng, SONG Yinghao, JIA Limin, XU Dongli, WANG Xupeng. Pilot-scale study on treatment of organic pigment wastewater by UASB-PACT process[J]. Chinese Journal of Environmental Engineering, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
Citation: GUO Xinshuang, SU Bensheng, SONG Yinghao, JIA Limin, XU Dongli, WANG Xupeng. Pilot-scale study on treatment of organic pigment wastewater by UASB-PACT process[J]. Chinese Journal of Environmental Engineering, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
shu

UASB-PACT工艺处理有机颜料废水中试研究

  • 1.

    北京化工大学高新技术研究院, 北京 100029

  • 2.

    北京联合创业环保股份有限公司, 北京 100007

  • 基金项目:

  • 中图分类号: X703

Pilot-scale study on treatment of organic pigment wastewater by UASB-PACT process

  • 1.

    Beijing University of Chemical Technology Engineering Institute, Beijing 100029, China

  • 2.

    Beijing Union Entrepreneurship Company Limited, Beijing 100007, China

  • Fund Project:

摘要

  • 摘要: 针对颜料废水有机物浓度含量高、水质波动大、可生化性差等特点，实验采用了UASB-PACT（powdered activated carbon treatment）组合工艺在常温下对颜料废水进行中试研究。实验共进行了119 d，分2个阶段进行，第1阶段为低浓度运行阶段，进水COD逐步提升至3 000 mg·L-1左右，经过36 d的运行，系统出水COD可稳定保持在500 mg·L-1以下，UASB、PACT反应器对COD的平均去除率分别为37.0%和80.5%；第2阶段为负荷提高阶段，共运行了83 d，UASB、PACT反应器对COD的平均去除率分别为53.9%和81.7%。76 d后在平均进水浓度为6 207.75 mg·L-1的条件下，出水COD -1。在工程应用阶段，经过6个月的调试，在进水量1 920 m3·d-1、COD为5 000 mg·L-1的条件下，UASB反应器的出水COD -1，PACT出水COD在300~500 mg·L-1之间波动，去除率分别为50.9%和75.3%。实验结果表明，针对有机颜料废水，采用UASB-PACT组合工艺能够达到很好的处理效果，出水满足《污水排入城镇下水道水质标准》（CJ 343-2010）中A级排放要求。
    Abstract: Pigment wastewater is characterized by a high amount of organic content, low rate of biological degradation, and significant fluctuation in quality. A pilot study on the treatment of pigment wastewater was conducted at room temperature by using a combined process of UASB-PACT (which involves adding powdered activated carbon to a normal activated sludge system). The two-stage experiment was carried out over 119 days. The respective efficiencies of COD removal from the effluent via UASB and PACT were 37.0% and 80.5% in the first stage, and the concentration of organics in the effluent was below 500 mg·L-1 when the COD of the influent increased to 3 000 mg·L-1. The respective average efficiencies for COD removal from the effluent via UASB and PACT were 53.9% and 81.7% in the second stage. Further, the concentration of organics in the effluent was below 500 mg·L-1 when the average COD influent was 6 207.75 mg·L-1. In the stage of engineering application, the combined process was debugged over six months. When the water ingress was 1 920 m3·d-1 and the COD was 5 000 mg·L-1, the respective efficiencies for COD removal from the effluent via UASB and PACT were 50.9% and 75.3%, and the concentration of organics in the effluent was in the range of 300 to 500 mg·L-1. The experimental results showed that the combined UASB-PACT process is an effective approach for treatment of pigment wastewater.
  • [1] 朱广伟.太湖富营养化现状及原因分析.湖泊科学,2008,20(1):21-2 HU Guangwei.Eutrophic status and causing factors for a large,shallow and subtropical Lake Taihu,China.Journal of Lake Sciences,2008,20(1):21-26(in Chinese)
    [2] 王成林,潘维玉,韩月琪,等.全球气候变化对太湖蓝藻水华发展演变的影响.中国环境科学,2010,30(6):822-82 ANG Chenglin,PAN Weiyu,HAN Yueqi,et al.Effect of global climate change on cyanobacteria bloom in Taihu Lake.China Environmental Science,2010,30(6):822-828(in Chinese)
    [3] 成芳,凌去非,徐海军,等.太湖水质现状与主要污染物分析.上海海洋大学学报,2010,19(1):105-11 HENG Fang,LING Qufei,XU Haijun,et al.Assessment of water quality and the main pollutions of Taihu Lake.Journal of Shanghai Ocean University,2010,19(1):105-110(in Chinese)
    [4] 金颖薇,朱广伟,许海,等.太湖水华期营养盐空间分异特征与赋存量估算.环境科学,2015,36(3):936-94 IN Yingwei,ZHU Guangwei,XU Hai,et al.Spatial distribution pattern and stock estimation of nutrients during bloom season in Lake Taihu.Environmental Science,2015,36(3):936-945(in Chinese)
    [5] 朱广伟.太湖水质的时空分异特征及其与水华的关系.长江流域资源与环境,2009,18(5):439-44 HU Guangwei.Spatio-temporal distribution pattern of water quality in lake Taihu and its relation with cyanobacterial blooms.Resources and Environment in the Yangtze Basin,2009,18(5):439-445(in Chinese)
    [6] 袁和忠,沈吉,刘恩峰.太湖重金属和营养盐污染特征分析.环境科学,2011,32(3):649-657 YUAN Hezhong,SHEN Ji,LIU Enfeng.Assessment and characterization of heavy metals and nutrients in sediments from Taihu Lake.Environmental Science,2011,32(3):649-657(in Chinese)
    [7] 袁和忠,沈吉,刘恩峰.太湖不同湖区沉积物磷形态变化分析.中国环境科学,2010,30(11):1522-152 UAN Hezhong,SHEN Ji,LIU Enfeng.Analysis of phosphorus forms in different regions of Taihu Lake.China Environmental Science,2010,30(11):1522-1528(in Chinese)
    [8] 毛志刚,谷孝鸿,陆小明,等.太湖东部不同类型湖区疏浚后沉积物重金属污染及潜在生态风险评价.环境科学,2014,35(1):186-19 AO Zhigang,GU Xiaohong,LU Xiaoming,et al.Pollution distribution and potential ecological risk assessment of heavy metals in sediments from the different eastern dredging regions of Lake Taihu.Environmental Science,2014,35(1):186-193(in Chinese)
    [9] 燕姝雯,余辉,张璐璐,等.200环太湖入出湖河流水量及污染负荷通量.湖泊科学,2011,23(6):855-86 AN Shuwen,YU Hui,ZHANG Lulu,et al.Water quantity and pollutant fluxes of inflow and outflow rivers of Lake Taihu,2009.Journal of Lake Sciences,2011,23(6):855-862(in Chinese)
    [10] 陈小锋,揣小明,曾巾,等.太湖氮素出入湖通量与自净能力研究.环境科学,2012,33(7):2309-231 HEN Xiaofeng,CHUAI Xiaoming,ZENG Jin,et al.Nitrogenous fluxes and its self-purification capacity in Lake Taihu.Environmental Science,2012,33(7):2309-2314(in Chinese)
    [11] 翟淑华,张红举.环太湖河流进出湖水量及污染负荷(2000-200).湖泊科学,2006,18(3):225-23 HAI Shuhua,ZHANG Hongju.Water quantity and waste load variation of rivers around Lake Taihu from 2000 to 2002.Journal of Lake Sciences,2006,18(3):225-230(in Chinese)
    [12] 王睿喆,王沛芳,任凌霄,等.营养盐输入对太湖水体中磷形态转化及藻类生长的影响.环境科学,2015,36(4):1301-130 ANG Ruiji,WANG Peifang,REN Lingxiao,et al.Effects of nutrient inputs on changes of phosphorus forms and phytoplankton growth in Taihu Lake.Environmental Science,2015,36(4):1301-1308(in Chinese)
    [13] 叶琳琳,吴晓东,孔繁翔,等.太湖入湖河流溶解性有机碳来源及碳水化合物生物可利用性.环境科学,2015,36(3):914-92 E Linlin,WU Xiaodong,KONG Fanxiang,et al.Sources of dissolved organic carbon and the bioavailability of dissolved carbohydrates in the tributaries of Lake Taihu.Environmental Science,2015,36(3):914-921(in Chinese)
    [14] 鲍琨,逄勇,孙瀚.基于控制断面水质达标的水环境容量计算方法研究:以殷村港为例.资源科学,2011,33(2):249-25 AO Kun,PANG Yong,SUN Han.A water environment capacity calculation method based on water quality standards at the control sections:A case study of the Yincun Port.Resources Science,2011,33(2):249-252(in Chinese)
    [15] 鲍琨,逄勇,孙瀚,等.基于控制单元划分技术的百渎港断面水质达标分析.河海大学学报(自然科学版),2011,39(6):651-65 AO Kun,PANG Yong,SUN Han,et al.Up-to-standard assessment of water quality based on control unit division technology:A case study of Baidu Port.Journal of Hohai University(Natural Sciences),2011,39(6):651-655(in Chinese)
    [16] 刘伟龙,胡维平,陈永根,等.西太湖水生植物时空变化.生态学报,2007,27(1):159-17 IU Weilong,HU Weiping,CHEN Yonggen,et al.Temporal and spatial variation of aquatic macrophytes in West Taihu Lake.Acta Ecologica Sinica,2007,27(1):159-170(in Chinese)
    [17] 朱琳.西太湖宜兴段近岸水质分析与现状评价.南京:南京林业大学硕士学位论文,2013 ZHU Lin.Water quality analysis and evaluation of current situation in the riparian of West Lake Taihu in Yixing.Nanjing:Master Dissertation of Nanjing Forestry University,2013(in Chinese)
    [18] 李彬华.西太湖宜兴段湖滨带水质现状分析.环境教育,2014(3):48-5 I Binhua.Analysis of water quality in Yixing section of West Taihu Lake Zone.Environmental Education,2014(3):48-50(in Chinese)
    [19] 吴雅丽,许海,杨桂军,等.太湖水体氮素污染状况研究进展.湖泊科学,2014,26(1):19-2 U Yali,XU Hai,YANG Guijun,et al.Progress in nitrogen pollution research in Lake Taihu.Journal of Lake Sciences,2014,26(1):19-28(in Chinese)
    [20] 美英,杨晓华,郭亚男,等.四种草本植物对城市非点源模拟雨水中镉的去除效果研究.干旱区资源与环境,2014,28(3):198-20 EI Ying,YANG Xiaohua,GUO Ya'nan,et al.Cadmium removal effect of 4 grasses in simulated rainfall experiment.Journal of Arid Land Resources and Environment,2014,28(3):198-203(in Chinese)
    [21] 美英,杨晓华,郭亚男,等.植物滞留系统草本植物对人工雨水中铅的富集及去除效果.水土保持学报,2013,27(1):158-16 EI Ying,YANG Xiaohua,GUO Ya'nan,et al.Bioaccumulation and removal efficiency of lead by grasses in bioretention.Journal of Soil and Water Conservation,2013,27(1):158-161(in Chinese)
    [22] 美英,杨晓华,郭亚男,等.植物滞留系统中草本植物对磷的去除效果研究.环境工程,2013,31(2):27-3 EI Ying,YANG Xiaohua,GUO Ya'nan,et al.Study on removal efficiency of phosphorus by grasses in bioretention.Environmental Engineering,2013,31(2):27-30(in Chinese)
    [23] MEI Ying,YANG Xiaohua,HE Jun,et al.A new assessment model for pollutant removal using mulch in bioretention processes.Fresenius Environmental Bulletin,2013,22():1507-1515
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1627
  • HTML全文浏览数:  1007
  • PDF下载数:  422
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-05-15
  • 刊出日期:  2016-08-12
郭新双, 苏本生, 宋英豪, 贾立敏, 徐冬利, 王旭鹏. UASB-PACT工艺处理有机颜料废水中试研究[J]. 环境工程学报, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
引用本文: 郭新双, 苏本生, 宋英豪, 贾立敏, 徐冬利, 王旭鹏. UASB-PACT工艺处理有机颜料废水中试研究[J]. 环境工程学报, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
shu
GUO Xinshuang, SU Bensheng, SONG Yinghao, JIA Limin, XU Dongli, WANG Xupeng. Pilot-scale study on treatment of organic pigment wastewater by UASB-PACT process[J]. Chinese Journal of Environmental Engineering, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
Citation: GUO Xinshuang, SU Bensheng, SONG Yinghao, JIA Limin, XU Dongli, WANG Xupeng. Pilot-scale study on treatment of organic pigment wastewater by UASB-PACT process[J]. Chinese Journal of Environmental Engineering, 2016, 10(8): 4337-4342. doi: 10.12030/j.cjee.201503162
shu

UASB-PACT工艺处理有机颜料废水中试研究

  • 1. 北京化工大学高新技术研究院, 北京 100029
  • 2. 北京联合创业环保股份有限公司, 北京 100007
  • 收稿日期:  2015-05-15
基金项目:

摘要: 针对颜料废水有机物浓度含量高、水质波动大、可生化性差等特点，实验采用了UASB-PACT（powdered activated carbon treatment）组合工艺在常温下对颜料废水进行中试研究。实验共进行了119 d，分2个阶段进行，第1阶段为低浓度运行阶段，进水COD逐步提升至3 000 mg·L-1左右，经过36 d的运行，系统出水COD可稳定保持在500 mg·L-1以下，UASB、PACT反应器对COD的平均去除率分别为37.0%和80.5%；第2阶段为负荷提高阶段，共运行了83 d，UASB、PACT反应器对COD的平均去除率分别为53.9%和81.7%。76 d后在平均进水浓度为6 207.75 mg·L-1的条件下，出水COD -1。在工程应用阶段，经过6个月的调试，在进水量1 920 m3·d-1、COD为5 000 mg·L-1的条件下，UASB反应器的出水COD -1，PACT出水COD在300~500 mg·L-1之间波动，去除率分别为50.9%和75.3%。实验结果表明，针对有机颜料废水，采用UASB-PACT组合工艺能够达到很好的处理效果，出水满足《污水排入城镇下水道水质标准》（CJ 343-2010）中A级排放要求。
