潮汐流人工湿地对高污染河水的处理功效

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

熊家晴, 李东辉, 郑于聪, 尉中伟, 赵泽宁, 王晓昌. 潮汐流人工湿地对高污染河水的处理功效[J]. 环境工程学报, 2014, 8(12): 5179-5184.
引用本文: 熊家晴, 李东辉, 郑于聪, 尉中伟, 赵泽宁, 王晓昌. 潮汐流人工湿地对高污染河水的处理功效[J]. 环境工程学报, 2014, 8(12): 5179-5184.
shu
Xiong Jiaqing, Li Donghui, Zheng Yucong, Yu Zhongwei, Zhao Zening, Wang Xiaochang. Performance of tidal flow constructed wetland for treating highly polluted river water[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5179-5184.
Citation: Xiong Jiaqing, Li Donghui, Zheng Yucong, Yu Zhongwei, Zhao Zening, Wang Xiaochang. Performance of tidal flow constructed wetland for treating highly polluted river water[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5179-5184.
shu

潮汐流人工湿地对高污染河水的处理功效

  • 1.

    西安建筑科技大学环境与市政工程学院, 西北水资源与环境生态教育部重点实验室, 西安 710055

  • 基金项目:

    国家水体污染控制与治理科技重大专项(2012ZX07308-001-08)

  • 中图分类号: X522

Performance of tidal flow constructed wetland for treating highly polluted river water

  • 1.

    Key Laboratory of Northwest Water Resource, Environment and Ecology, Ministry of Education, School of Environmental and Municipal Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

  • Fund Project:

摘要

  • 摘要: 为了研究潮汐流人工湿地对高污染河流污染物的去除效果及其影响因素,实验构建了潮汐流人工湿地系统。运行春夏两季以来,系统对TN、NH3-N、TP、COD和BOD5的平均去除率分别为49.14%、48.34%、79.40%、81.52%和83.39%;其中系统对TN和NH3-N的去除受到温度的影响,且温度变化对NH3-N去除效果的影响大于TN;在实验周期内,系统对TN、TP、COD和BOD5的去除均受进水污染负荷的影响,但却有着较好的抗负荷冲击能力;潮汐流人工湿地能够显著提高系统内溶解氧,使其不再成为去除污染物的限制性因素。
    Abstract: A tidal flow constructed wetland system was constructed to treat highly polluted river water and acquire information on the removal efficiencies of pollutants and assess the impact factors. During a half year's experiment (from spring to summer), the average removal rates of TN, NH3-N, TP, COD and BOD5 were 49.14%, 48.34%, 79.40%, 81.52% and 83.39%, respectively. The removal rate of NH3-N was easier affected by the temperature than TN. The unit removal of TN, TP, COD and BOD5 was affected by the influent loading, but the constructed wetland had a great capacity to resist the influence of load. Since the concentration of DO was greatly improved by the tidal flow constructed wetland, it would not be a limiting factor for pollutant removal any more.
  • [1] Zhang Ting, Xu Dong, He Feng, et al. Application of constructed wetland for water pollution control in China during 1990—2010. Ecological Engineering, 2012, 47(10): 189-197
    [2] Vymazal J. Removal of nutrients in various types of constructed wetlands. Science of the Total Environment, 2007, 380(1-3): 48-65
    [3] Saeed T., Sun Guangzhi. A review on nitrogen and organics removal mechanisms in subsurface flow constructed wetlands: Dependency on environmental parameters, operating conditions and supporting media. Journal of Environmental Management, 2012, 112(12): 429-448
    [4] 杨旭, 于水利, 张洪洋, 等. 潜流人工湿地低温下黄河原水预处理效果研究. 生态环境, 2008, 17(1): 70-73 Yang Xu, Yu Shuili, Zhang Hongyang, et al. Pretreatment effects of Yellow River raw water by subsurface constructed wetland in low temperature. Ecology and Environment, 2008, 17(1): 70-73(in Chinese)
    [5] 杨新萍, 周立祥, 戴媛媛, 等. 潜流人工湿地处理微污染河道水中有机物和氮的净化效率及沿程变化. 环境科学, 2008, 29(8): 2177-2182 Yang Xinping, Zhou Lixiang, Dai Yuanyuan, et al. Removal efficiency of C and N in micro-polluted river through a subsurface-horizontal flow constructed wetlands. Environmental Science, 2008, 29(8): 2177-2182 (in Chinese)
    [6] 谢飞, 黄磊, 高旭, 等. 潜流人工湿地对微污染河水的净化效果. 环境工程学报, 2013, 7(1): 65-71 Xie Fei, Huang Lei, Gao Xu, et al. Purification efficiencies of subsurface horizontal flow constructed wetland treating slightly polluted river water. Chinese Journal of Environmental Engineering, 2013, 7(1): 65-71(in Chinese)
    [7] 尹炜, 李培军, 尹澄清, 等. 潜流人工湿地的局限性与运行问题. 中国给水排水, 2004, 20(11): 36-38 Yin Wei, Li Peijun, Yin Chengqing, et al. Application limitation and operation of subsurface flow constructed wetland. China Water & Wastewater, 2004, 20(11): 36-38 (in Chinese)
    [8] 丁怡, 宋新山, 严登华. 影响潜流人工湿地脱氮主要因素及其解决途径. 环境科学与技术, 2011, 34(12H): 103-106 Ding Yi, Song Xinshan, Yan Denghua. The main effect factors of nitrogen removal in subsurface flow constructed wetlands and its solutions. Environmental Science & Technology, 2011, 34(12H): 103-106 (in Chinese)
    [9] 李松, 王为东, 强志民, 等. 自动增氧型垂直流人工湿地处理农村生活污水实验研究. 农业环境科学学报, 2010, 29(8): 1566-1570 Li Song, Wang Weidong, Qiang Zhimin, et al. Self-aeration vertical flow constructed wetland for the treatment of rural domestic wastewater. Journal of Agro-Environment Science, 2010, 29(8): 1566-1570 (in Chinese)
    [10] Hu Y. S., Zhao Y. Q., Kumar J. L. G. Comprehensive analysis of step-feeding strategy to enhance biological nitrogen removal in alum sludge-based tidal flow constructed wetlands. Bioresource Technology, 2012, 111(5): 27-35
    [11] 国家环境保护总局. 水和废水监测分析方法 (第4版). 北京: 中国环境科学出版社, 2002
    [12] 宋玉丽, 吴树彪, 王飞, 等. 潮汐流-水平潜流组合人工湿地的污水处理效果. 中国农业大学学报, 2012, 17(4): 165-172 Song Yuli, Wu Shubiao, Wang Fei, et al. Purification capacities of hybrid tidal flow and horizontal subsurface flow constructed wetlands systems. Journal of China Agricultural University, 2012, 17(4): 165-172(in Chinese)
    [13] Hu Yuansheng, Zhao Xiaohong, Zhao Yaqian. Achieving high-rate autotrophic nitrogen removal via Canon process in a modified single bed tidal flow constructed wetland. Chemical Engineering Journal, 2014, 237(2): 329-335
    [14] Stefanakis A. I., Tsihrintzis V. A. Effects of loading, resting period, temperature, porous media, vegetation and aeration on performance of pilot-scale vertical flow constructed wetlands. Chemical Engineering Journal, 2012, 181-182(2): 416-430
    [15] 夏汉平. 人工湿地处理污水的机理与效率. 生态学杂志, 2002, 21(4): 52-59 Xia Hanping. Mechanisms and efficiencies on wastewater treatment with constructed wetlands: A review. Chinese Journal of Ecology, 2002, 21(4): 52-59(in Chinese)
    [16] 沈耀良, 王宝贞. 废水生物处理新技术: 理论与应用(第2版). 北京: 中国环境科学出版社, 2006
    [17] 张甲耀, 夏盛林, 崔克辉, 等. 潜流型人工湿地污水处理系统中芦苇的生长特性及净化能力. 水处理技术, 1998, 24(6): 363-367 Zhang Jiayao, Xia Shenlin, Cui Kehui, et al. Growth characteristic of reed in the subsurface flow constructed wetlands wastewater treatment system and its purification capability. Technology of Water Treatment, 1998, 24(6): 363-367(in Chinese)
    [18] 王晓娟, 张荣社. 人工湿地微生物硝化和反硝化强度对比研究. 环境科学学报, 2006, 26(2): 225-229 Wang Xiaojuan, Zhang Rongshe. Study on intensity of microorganism nitrification and denitrification in contructed wetlands. Acta Scientiae Circumstantiae, 2006, 26(2): 225-229(in Chinese)
    [19] 王功, 魏东洋, 方晓航, 等. 3种湿地填料对水体中氮磷的吸附特性研究. 环境污染与防治, 2012, 34 (11): 9-13 Wang Gong, Wei Dongyang, Fang Xiaohang, et al. Study on the adsorption characteristics of nitrogen and phosphorus on three substrates of constructed wetland. Environmental Pollution & Control, 2012, 34(11): 9-13(in Chinese)
    [20] 张胜华, 郭一飞, 靳慧霞. 水处理微生物学. 北京: 化学工业出版社, 2005
    [21] 籍国东, 倪晋仁. 人工湿地废水生态处理系统的作用机制. 环境污染治理技术与设备, 2004, 5(6): 71-75 Ji Guodong, Ni Jinren. Mechanisms of constructed wetland wastewater ecological treatment systems. Techniques and Equipment for Environmental Pollution Control, 2004, 5(6): 71-75(in Chinese)
    [22] 梁继东, 周启星, 孙铁珩. 人工湿地污水处理系统研究及性能改进分析. 生态学杂志, 2003, 22(2): 49-55 Liang Jidong, Zhou Qixing, Sun Tieheng. A research review and technical improvement analysis of constructed wetland systems for wastewater treatment. Chinese Journal of Ecology, 2003, 22(2): 49-55(in Chinese)
    [23] 梁威, 胡洪营. 人工湿地净化污水过程中的生物作用. 中国给水排水, 2003, 19(10): 28-31 Liang Wei, Hu Hongying. Biological effect in the process of wastewater purification by using constructed wetland. China Water & Wastewater, 2003, 19(10): 28-31(in Chinese)
    [24] 张永勇, 张光义, 夏军, 等. 湿地污水处理机理的研究. 环境科学与技术, 2005, 28(S1): 165-167 Zhang Yongyong, Zhang Guangyi, Xia Jun, et al. The research of wastewater treatment mechanism in wetlands. Environmental Science & Technology, 2005, 28(S1): 165-167(in Chinese)
    [25] 冯培勇, 陈兆平, 靖元孝. 人工湿地及其去污机理研究进展. 生态科学, 2002, 21(3): 264-268 Feng Peiyong, Chen Zhaoping, Jing Yuanxiao. Review on constructed wetland and its mechanisms of wastewater treatment. Ecologic Science, 2002, 21(3): 264-268(in Chinese)
    [26] 籍国东, 孙铁珩, 李顺. 人工湿地及其在工业废水处理中的应用. 应用生态学报, 2002, 13(2): 224-228 Ji Guodong, Sun Tieheng, Li Shun. Constructed wetland and its application for industrial wastewater treatment. Chinese Journal of Applied Ecology, 2002, 13(2): 224-228(in Chinese)
    [27] 刘霄, 黄岁樑, 刘学功. 3种人工湿地基质对磷的吸附特性. 环境工程学报, 2012, 6(10): 3367-3372 Liu Xiao, Huang Suiliang, Liu Xuegong. Characteristics of phosphorous adsorption on three substrates used in constructed wetland. Chinese Journal of Environmental Engineering, 2012, 6(10): 3367-3372(in Chinese)
    [28] 贺凯, 卢少勇, 金相灿, 等. 五种填料对磷酸盐的等温吸附-解吸特性. 农业工程学报, 2008, 24(8): 232-235 He Kai, Lu Shaoyong, Jin Xiangcan, et al. Adsorption-desorption characteristics of phosphate by five kinds of substrates. Transactions of the CSAE, 2008, 24(8): 232-235(in Chinese)
    [29] 宋茂成, 钱茜. 人工湿地处理污水机理及影响因素. 污染防治技术, 2010, 23(6): 38-40 Song Maocheng, Qian Qian. Mechanism and influencing factors of sewage treatment by artificial wetland. Pollution Control Technology, 2010, 23(6): 38-40(in Chinese)
    [30] Akratos C. S., Tsihrintzis V. A. Effect of temperature, HRT, vegetation and porous media on removal efficiency of pilot-scale horizontal subsurface flow constructed wetlands. Ecological Engineering, 2007, 29(2): 173-191
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1819
  • HTML全文浏览数:  1253
  • PDF下载数:  1032
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-01-29
  • 刊出日期:  2014-12-03
熊家晴, 李东辉, 郑于聪, 尉中伟, 赵泽宁, 王晓昌. 潮汐流人工湿地对高污染河水的处理功效[J]. 环境工程学报, 2014, 8(12): 5179-5184.
引用本文: 熊家晴, 李东辉, 郑于聪, 尉中伟, 赵泽宁, 王晓昌. 潮汐流人工湿地对高污染河水的处理功效[J]. 环境工程学报, 2014, 8(12): 5179-5184.
shu
Xiong Jiaqing, Li Donghui, Zheng Yucong, Yu Zhongwei, Zhao Zening, Wang Xiaochang. Performance of tidal flow constructed wetland for treating highly polluted river water[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5179-5184.
Citation: Xiong Jiaqing, Li Donghui, Zheng Yucong, Yu Zhongwei, Zhao Zening, Wang Xiaochang. Performance of tidal flow constructed wetland for treating highly polluted river water[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5179-5184.
shu

潮汐流人工湿地对高污染河水的处理功效

  • 1. 西安建筑科技大学环境与市政工程学院, 西北水资源与环境生态教育部重点实验室, 西安 710055
  • 收稿日期:  2014-01-29
基金项目:

国家水体污染控制与治理科技重大专项(2012ZX07308-001-08)

摘要: 为了研究潮汐流人工湿地对高污染河流污染物的去除效果及其影响因素,实验构建了潮汐流人工湿地系统。运行春夏两季以来,系统对TN、NH3-N、TP、COD和BOD5的平均去除率分别为49.14%、48.34%、79.40%、81.52%和83.39%;其中系统对TN和NH3-N的去除受到温度的影响,且温度变化对NH3-N去除效果的影响大于TN;在实验周期内,系统对TN、TP、COD和BOD5的去除均受进水污染负荷的影响,但却有着较好的抗负荷冲击能力;潮汐流人工湿地能够显著提高系统内溶解氧,使其不再成为去除污染物的限制性因素。
