塔式自然通风好氧堆肥反应器的开发与应用

,  ,  ,

downloadPDF

上一篇

下一篇

王玉新, 任勇翔, 王晓昌, 陈威. 塔式自然通风好氧堆肥反应器的开发与应用[J]. 环境工程学报, 2014, 8(4): 1631-1636.
引用本文: 王玉新, 任勇翔, 王晓昌, 陈威. 塔式自然通风好氧堆肥反应器的开发与应用[J]. 环境工程学报, 2014, 8(4): 1631-1636.
shu
Wang Yuxin, Ren Yongxiang, Wang Xiaochang, Chen Wei. Development and application of a tower natural ventilation reactor for aerobic composting[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1631-1636.
Citation: Wang Yuxin, Ren Yongxiang, Wang Xiaochang, Chen Wei. Development and application of a tower natural ventilation reactor for aerobic composting[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1631-1636.
shu

塔式自然通风好氧堆肥反应器的开发与应用

  • 1.

    西安建筑科技大学, 西北水资源与环境生态教育部重点实验室, 西安 710055

  • 基金项目:

    国家自然科学基金重大国际合作项目（51021140002）

  • 中图分类号: X705

Development and application of a tower natural ventilation reactor for aerobic composting

  • 1.

    Xi'an University of Architecture and Technology, Key Laboratory of Northwestern Water Resource and Environment Ecology, Ministry of Education, Xi'an 710055, China

  • Fund Project:

摘要

  • 摘要: 针对现有堆肥反应器处理效率低、运行和维护成本较高及堆肥效率不稳定等问题，开发了塔式自然通风好氧堆肥反应器。从物料和热量平衡、通风量优化等方面对反应器进行研究。反应器主要包括反应器主体、通风管、物料承托筛板和温度监控系统等，具有运行及维护简单、能源耗费低等优点。在通风高度为3 m，初始物料投加量5.65 kg（干重比︰粪便/锯末= 1：2.5），含水率约60%时，对人粪便进行好氧堆肥实验。结果表明，堆体温度最高至62℃，并且在50℃以上高温保持5 d；TOC和COD均呈持续下降趋势，降解率分别为64.14%和56.45%；种子发芽指数为113.64%，完全达到腐熟标准。
    Abstract: Based on the results of material and heat balance as well as the optimization of wind pressure,a tower reactor was developed to make it more suitable for the aerobic composting.The reactor was mainly composed of a reactor main body,the ventilation pipe,material supporting plate and temperature monitoring system.The reactor had the advantages of the easy operation,simply maintenance and lower energy cost.Under the condition of 3 m of ventilation height,5.65 kg of initial material feeding,1:2.5 of feces-sawdust ratio in dry weight and 60% of moisture content,a study in pilot-scale sequencing batch feeding for human feces composting was carried out.As a result,a significant increasing in compost heap temperature of higher than 50℃ was found and the process maintained about 5 days.The TOC and COD decreased gradually with the final removal rates of 64.14% and 56.45%,respectively.In addition,the germination index was 113.64%,indicating that the maturity criteria were reached.
  • [1] 常勤学, 魏源送, 夏世斌.堆肥通风技术及进展.环境科学与技术, 2007, 30 (10):98-103, 107 Chang Qinxue, Wei Yuansong, Xia Shibin.Progress on technology of aeration in composting.Environmental Science & Technology, 2007, 30 (10):98-103, 107(in Chinese)
    [2] 罗维, 陈同斌, 高定, 等.混合堆肥过程中挥发性固体含量的层次效应及动态变化.环境科学, 2004, 25(3):155-159 Luo Wei, Chen Tongbin, Gao Ding, et al.Stratification of volatile solid content and its dynamics in the process of co-composting.Environmental Science, 2004, 25(3):155-159(in Chinese)
    [3] Roger Tim Hang.Compost Engineering Principles and Practice.Michigan:Ann Arbot Science Publishers Inc, 1980
    [4] 廖利, 宇鹏, 王松林, 等.太阳能好氧堆肥能量平衡计算分析.华中科技大学学报(城市科学版), 2005, 22(4):4-7 Liao Li, Yu Peng, Wang Songlin, et al.Calculation analysis on energy balance of aerobic composting with solar energy.Journal of Huazhong University of Science and Technology (Urban Science Edition), 2005, 22(4):4-7(in Chinese)
    [5] John Pichtel.Waste Management Practices:Municipal, Hazardous and Industrial.Boca Raton:CRC Press Inc., 2005
    [6] 蔡建成, 编译.堆肥工程与堆肥工厂.北京:机械工业出版社, 1990
    [7] 李鸣晓, 席北斗, 戴京, 等.两室堆肥生物反应装置研究.环境工程学报, 2008, 2 (8):1092-1097 Li Mingxiao, Xi Beidou, Dai Jing, et al.Research on a two room composting bioreactor.Chinese Journal of Environmental Engineering, 2008, 2(8):1092-1097(in Chinese)
    [8] 孙一坚.工业通风.北京:中国建筑工业出版社, 1984
    [9] 周亨达.工程流体力学.北京:冶金工业出版社, 1981
    [10] Lewis W.K., Gilliland E.R., Bauer W.C.Characteristics of fluidized particles.Industrial & Engineering Chemistry, 1949, 41(6):1104-1117
    [11] 席北斗, 李英军, 张晓萱, 等.垃圾堆肥工艺过程动态模拟及优化研究.环境污染治理技术与设备, 2005, 6(2):20-23 Xi Beidou, Li Yingjun, Zhang Xiaoxuan, et al.Study on dynamic simulation of composting processes for domestic solid wastes.Techniques and Equipment for Environmental Pollution Control, 2005, 6(2):20-23(in Chinese)
    [12] 赵镇南.传热学.北京:高等教育出版社, 2001
    [13] 中华人民共和国卫生部.GB7959-87粪便无害化卫生标准.北京:中国标准出版社, 1988
    [14] 沈越, 张健.生物固体自热好氧消化中粪大肠杆菌数量的变化研究.广东化工, 2013, 40(8):183-184 Shen yue, Zhang jian.Research on amount various of fecal coliform in bio-solids autothermal themophilic aerobic digestion.Guangdong Chemical Industry, 2013, 40(8):183-184(in Chinese)
    [15] García C., Hernández T., Costa F., et al.Phytotoxicity due to the agricultural use of urban wastes.Germination experiments.Journal of the Science of Food and Agriculture, 1992, 59(3):313-319
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1878
  • HTML全文浏览数:  1184
  • PDF下载数:  793
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-10-13
  • 刊出日期:  2014-03-28
王玉新, 任勇翔, 王晓昌, 陈威. 塔式自然通风好氧堆肥反应器的开发与应用[J]. 环境工程学报, 2014, 8(4): 1631-1636.
引用本文: 王玉新, 任勇翔, 王晓昌, 陈威. 塔式自然通风好氧堆肥反应器的开发与应用[J]. 环境工程学报, 2014, 8(4): 1631-1636.
shu
Wang Yuxin, Ren Yongxiang, Wang Xiaochang, Chen Wei. Development and application of a tower natural ventilation reactor for aerobic composting[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1631-1636.
Citation: Wang Yuxin, Ren Yongxiang, Wang Xiaochang, Chen Wei. Development and application of a tower natural ventilation reactor for aerobic composting[J]. Chinese Journal of Environmental Engineering, 2014, 8(4): 1631-1636.
shu

塔式自然通风好氧堆肥反应器的开发与应用

  • 1. 西安建筑科技大学, 西北水资源与环境生态教育部重点实验室, 西安 710055
  • 收稿日期:  2013-10-13
基金项目:

国家自然科学基金重大国际合作项目（51021140002）

摘要: 针对现有堆肥反应器处理效率低、运行和维护成本较高及堆肥效率不稳定等问题，开发了塔式自然通风好氧堆肥反应器。从物料和热量平衡、通风量优化等方面对反应器进行研究。反应器主要包括反应器主体、通风管、物料承托筛板和温度监控系统等，具有运行及维护简单、能源耗费低等优点。在通风高度为3 m，初始物料投加量5.65 kg（干重比︰粪便/锯末= 1：2.5），含水率约60%时，对人粪便进行好氧堆肥实验。结果表明，堆体温度最高至62℃，并且在50℃以上高温保持5 d；TOC和COD均呈持续下降趋势，降解率分别为64.14%和56.45%；种子发芽指数为113.64%，完全达到腐熟标准。
