生物基质活性炭对挥发性有机物的吸附

,  ,  ,

downloadPDF

上一篇

下一篇

马晓东, 欧阳峰, 申东美, 曹小凯. 生物基质活性炭对挥发性有机物的吸附[J]. 环境工程学报, 2013, 7(6): 2296-2300.
引用本文: 马晓东, 欧阳峰, 申东美, 曹小凯. 生物基质活性炭对挥发性有机物的吸附[J]. 环境工程学报, 2013, 7(6): 2296-2300.
shu
Ma Xiaodong, Ouyang Feng, Shen Dongmei, Cao Xiaokai. Adsorption of VOCs using activated carbons prepared by biologic matters[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2296-2300.
Citation: Ma Xiaodong, Ouyang Feng, Shen Dongmei, Cao Xiaokai. Adsorption of VOCs using activated carbons prepared by biologic matters[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2296-2300.
shu

生物基质活性炭对挥发性有机物的吸附

  • 1.

    哈尔滨工业大学深圳研究生院, 深圳 518055

  • 基金项目:

    深圳市"双百计划"项目(2008)

  • 中图分类号: X511

Adsorption of VOCs using activated carbons prepared by biologic matters

  • 1.

    Shenzhen Graduate School, Harbin Institute of Technology, Shenzhen 518055, China

  • Fund Project:

摘要

  • 摘要: 以咖啡渣和柚子皮生物基质为原料用磷酸活化法制成活性炭,探讨了制备条件对活性炭制备的影响,并研究了其对正丁烷的吸附行为。磷酸活化过程中磷酸的用量为生物基质质量的1.5倍为宜,咖啡渣采用超声干燥法,柚子皮采用水热法制备。制备的活性炭对正丁烷均有较好的吸附能力,以柚子皮为原料、磷酸用量为原料质量两倍活化制成的活性炭吸附性能最佳,最大吸附量约为商用活性炭的2倍。吸附剂均能较好地与兰格缪尔曲线相拟合,计算了不同正丁烷覆盖度下的等量吸附热,其变化规律与吸附曲线变化规律相一致。
    Abstract: Activated carbons were prepared by phosphoric acid activation using coffee grounds and pomelo skins as base materials. The best mass ratio of phosphoric acid to base materials is 3 to 2 during the preparation process. Coffee grounds were treated by ultrasonic and drying, while pomelo skins were activated by hydrothermal treatment. All the as-prepared adsorbents had good capacity for n-butane adsorption. The maximum adsorption amount of n-butane for the best adsorbent was almost twice as much the commercial activated carbon. All the isotherms fitted well with Langmuir model. The isosteric heats at different coverages were also calculated through Clausius-Clapeyron equation. They shared the same laws with the variation of n-butane adsorption isotherms.
  • [1] 蒋卉. 挥发性有机物的控制技术及其发展. 资源开发与市场, 2006,22(4):315-317 Jiang Hui. Control technology and development of volatile organic compounds. Resource Development and Market, 2006,22(4):315-317(in Chinese)
    [2] 许全瑞, 沈美庆, 王军. 油烟污染及其排放控制技术. 中国稀土学报, 2003,21(z2):22-25 Xu Quanrui, Shen Meiqing, Wang Jun. Pollution and emission control technology of cooking fume. Journal of the Chinese Rare Earth Society, 2003,21(z2):22-25(in Chinese)
    [3] Roak S. E., Cabrera-Fonseca J., Milazzo M., et al. Catalytic oxidation of volatile organic liquids. Journal of Environmental Engineering, 2004,130(3):329-337
    [4] Ciambell I. G., Perathoner P., Perathoner S., et al. Environm-ental catalysis: Trends and outlook. Catalysis Today, 2002,75(1-4):3-15
    [5] Amor J. N. Environmental catalysis. Applied Catalysis B: Environmental, 1992,1(4):221-256
    [6] Foster K.L., Fuerman R.G., Economy J., et al. Adsorption characteristics of trace volatile organic compounds in gas streams onto activated carbon fibers. Chemistry of Materials, 1992,4(5):1068-1073
    [7] Dimotakis E. D., Cal M. P., Economy J., et al. Chemically treated activated carbon cloths for removal of volatile organic carbons from gas streams: Evidence for enhanced physical adsorption. Environmental Science and Technology, 1995,29(7):1876-1880
    [8] Vorontsov A.V., Savinov E.N., Smirniotis P.G. Vibrofluideized and fixed-bed photocatalytic reactors: case of gaseous acetone photooxidation. Chemical Engineering Science, 2000,55(21):5089-5098
    [9] Khan F.I., Ghoshal A.K. Removal of volatile organic compounds from polluted air. Journal of Loss Prevention in the Process Industries, 2000,13(6):527-545
    [10] Ruddy E.N., Carroll L.A. Select the best VOC control strategy. Chemical Engineering Progress, 1993,89(7):28-35
    [11] 徐效梅, 黄维秋, 赵书华, 等. 活性炭吸附VOC穿透曲线的研究. 能源环境保护, 2008,22(2):7-10 Xu Xiaomei, Huang Weiqiu, Zhao Shuhua, et al. Study on the activated carbon's adsorption breakthrough curves of VOC. Energy Environmental Protection, 2008,22(2):7-10(in Chinese)
    [12] 苑守瑞, 朱义年, 梁美娜. 氯化锌活化法制备柚子皮活性. 环境科学与技术, 2010,33(6E):22-25 Yuan Shourui, Zhu Yinian, Liang Meina. Preparation of activated carbon from grapefruit bran by activation with zinc chloride. Environmental Science and Technology, 2010,33(6E):22-25(in Chinese)
    [13] Boonamnuayvitaya V., Sae-ung S., Tanthapanichakoon W. Preparation of activated carbons from coffee residue for the adsorption of formaldehyde. Separation and Purification Technology, 2005,42(2):159-168
    [14] Namane A., Mekarzia A., Benrachedi K., et al. Determinati-on of the adsorption capacity of activated carbon made from coffee grounds by chemical activation with ZnCl2 and H3PO4. Journal of Hazardous Materials, 2005,119(1-3):189-194
    [15] Ogata F., Tominaga H., Yabutani H., et al. Removal of fluoride ions from water by adsorption onto carbonaceous materials produced from coffee grounds. Journal of Oleo Science, 2011,60(12):619-625
    [16] Hirata M., Kawasaki N., Nakamura T., et al. Adsorption of dyes onto carbonaceous materials produced from coffee grounds by microwave treatment. Journal of Colloid and Interface Science, 2002,254(1):17-22
    [17] Foo K. Y., Hameed B. H. Microwave assisted preparation of activated carbon from pomelo skin for the removal of anionic and cationic dyes. Chemical Engineering Journal, 2011,172(2):385-390
    [18] 李登勇, 吴超飞, 韦朝海, 等. 柚子皮生物碳质对4-氯硝基苯的吸附动力学及吸附平衡特征. 环境工程学报, 2010,4(3):481-486 Li Dengyong, Wu Chaofei, Wei Chaohai, et al. Kinetics and equilibrium of 4-nitrochlorobenzene adsorption on biological carbon prepared by pomelo peel. Chinese Journal of Environmental Engineering, 2010,4(3):481-486(in Chinese)
    [19] 沈士德, 徐娟. 柚皮粉对水中Cr(Ⅵ)的吸附性能研究. 环境工程学报, 2010,4(8):1841-1845 Shen Shide, Xu Juan. Research on adsorption of hexavalent chromium in water onto grapefruit husk powder. Chinese Journal of Environmental Engineering, 2010,4(8):1841-1845(in Chinese)
    [20] 周殷, 胡长伟, 李建龙. 柚子皮吸附水溶液中亚甲基蓝的机理研究. 环境科学研究, 2008,21(5):49-54 Zhou Yin, Hu Changwei, Li Jianlong. Study on the biosorption mechanism of methylene blue in aqueous solution using pomelo peel. Research of Environmental Sciences, 2008,21(5):49-54(in Chinese)
    [21] 辛勤, 罗孟飞. 现代催化研究方法. 北京: 科学出版社, 2009.21-22
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1665
  • HTML全文浏览数:  739
  • PDF下载数:  1223
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-06-11
  • 刊出日期:  2013-06-11
马晓东, 欧阳峰, 申东美, 曹小凯. 生物基质活性炭对挥发性有机物的吸附[J]. 环境工程学报, 2013, 7(6): 2296-2300.
引用本文: 马晓东, 欧阳峰, 申东美, 曹小凯. 生物基质活性炭对挥发性有机物的吸附[J]. 环境工程学报, 2013, 7(6): 2296-2300.
shu
Ma Xiaodong, Ouyang Feng, Shen Dongmei, Cao Xiaokai. Adsorption of VOCs using activated carbons prepared by biologic matters[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2296-2300.
Citation: Ma Xiaodong, Ouyang Feng, Shen Dongmei, Cao Xiaokai. Adsorption of VOCs using activated carbons prepared by biologic matters[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2296-2300.
shu

生物基质活性炭对挥发性有机物的吸附

  • 1. 哈尔滨工业大学深圳研究生院, 深圳 518055
  • 收稿日期:  2012-06-11
基金项目:

深圳市"双百计划"项目(2008)

摘要: 以咖啡渣和柚子皮生物基质为原料用磷酸活化法制成活性炭,探讨了制备条件对活性炭制备的影响,并研究了其对正丁烷的吸附行为。磷酸活化过程中磷酸的用量为生物基质质量的1.5倍为宜,咖啡渣采用超声干燥法,柚子皮采用水热法制备。制备的活性炭对正丁烷均有较好的吸附能力,以柚子皮为原料、磷酸用量为原料质量两倍活化制成的活性炭吸附性能最佳,最大吸附量约为商用活性炭的2倍。吸附剂均能较好地与兰格缪尔曲线相拟合,计算了不同正丁烷覆盖度下的等量吸附热,其变化规律与吸附曲线变化规律相一致。
