以堇青石和二氧化钛为载体脱硝催化剂性能

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

席文昌, 刘清才, 杨剑, 贺媛媛, 黄锐, 袁鹏, 洪燕. 以堇青石和二氧化钛为载体脱硝催化剂性能[J]. 环境工程学报, 2013, 7(6): 2262-2266.
引用本文: 席文昌, 刘清才, 杨剑, 贺媛媛, 黄锐, 袁鹏, 洪燕. 以堇青石和二氧化钛为载体脱硝催化剂性能[J]. 环境工程学报, 2013, 7(6): 2262-2266.
shu
Xi Wenchang, Liu Qingcai, Yang Jian, He Yuanyuan, Huang Rui, Yuan Peng, Hong Yan. Performance of deNOx catalyst supported on cordierite-TiO2 carrier[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2262-2266.
Citation: Xi Wenchang, Liu Qingcai, Yang Jian, He Yuanyuan, Huang Rui, Yuan Peng, Hong Yan. Performance of deNOx catalyst supported on cordierite-TiO2 carrier[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2262-2266.
shu

以堇青石和二氧化钛为载体脱硝催化剂性能

  • 1.

    重庆大学材料科学与工程学院, 重庆 400044

  • 2.

    重庆远达催化剂制造有限公司, 重庆 401336

  • 3.

    中电投远达环保工程有限公司, 重庆 401122

  • 基金项目:

    国家高技术研究发展计划(863)项目(2010AA065001)

    科技人员服务企业行动(2009GJF10047)

    重庆市科技攻关项目(CSTC,2010AB7132)

  • 中图分类号: X511

Performance of deNOx catalyst supported on cordierite-TiO2 carrier

  • 1.

    School of Material Science and Engineering, Chongqing University, Chongqing 400044, China

  • 2.

    Chongqing Yuanda Catalyst Manufacturing Co. Ltd., Chongqing 401336, China

  • 3.

    China Power Investment Yuanda Environmental Protection Engineering Co. Ltd., Chongqing 401122, China

  • Fund Project:

摘要

  • 摘要: 采用改性堇青石和锐钛型二氧化钛为载体,以偏钨酸氨为WO3(助剂)的前驱体,以偏钒酸铵为V2O5(活性组分)的前驱体,通过混合、挤出、干燥和煅烧等工艺制备出蜂窝式SCR脱硝催化剂,采用N2-吸附仪(BET)、X-射线衍射分析仪(XRD)、模拟烟气活性分析装置和磨损装置,再通过催化剂样品的吸水率和收缩率对比分析。考察催化剂样品的比表面积、晶相结构、耐磨损性能、脱硝活性及其吸水率和收缩率变化。结果表明,以10%堇青石和二氧化钛为载体制备出的催化剂比表面积大,晶相结构以堇青石和锐钛矿型二氧化钛为主,其磨损率低,吸水率和收缩率变化小,脱硝率在80%以上时,与商业催化剂相比,反应温度窗口从300~400℃拓宽为250~460℃。
    Abstract: Using modified cordierite and anatase-TiO2 as the carrier, WO3 as the addition agent and V2O5 as the active component, V2O5-WO3/Cordierite-TiO2 honeycomb selective catalytic reduction (SCR) for DeNOx application was prepared though mixing, extrusion, drying and calcination process. The surface area and crystal structure of V2O5-WO3/Cordierite-TiO2 catalyst were studied by BET and XRD. The abrasion resistance, water-absorption ratio, shrinkage ratio and activity were investigated by simulated flue gas analyzer and abration equipment, then through the comparison of water absorption and shrinkage of the catalyst samples. The results indicated that BET of 1%V2O5-WO3/10%Cordierite-TiO2 was larger than commercial catalyst, main crystalline phase of it was cordierite and anatase-TiO2, the abration ratio, water-absorption and shrinkage ratio of it were lower. When denitrification rate of it was above 80%, the temperature window of its activity could be widened from 300~400℃ to 250~460℃, compared with commercial catalysts.
  • [1] Ha Heon Phil, Maddigapu Pratap Reddy, Pullur Anil Kumar.,et al. SO2 resistant antimony promoted V2O5/TiO2 catalyst for NH3-SCR of NOx at low temperatures. Applied Catalysis B: Environmental, 2008,78(3-4):301-308
    [2] Busca G. Chemical and mechanistic aspects of the selective catalytic reduction of NOx by ammonia over oxide catalysts: A review. Applied Catalysis B: Environmental, 1998,18(1-2):1-36
    [3] 赵宇峰, 赵博, 禚玉群,等. SO2对于铁基硫酸盐的NH3选择性还原NO催化活性的影响. 中国电机工程学报, 2011,23(31):27-33 Zhao Y. F., Zhao B., Zhuo Y. Q., et al. Influences of SO2 on the catalytic effect for selective catalytic reduction of NO by NH3 over iron-based sulfates. Proceedings of the CSEE, 2011,23(31):27-33(in Chinese)
    [4] 刘宣勇, 钱端芬, 谢建国,等. 堇青石蜂窝陶瓷烧成工艺的研究. 陶瓷工程, 1999,33(3):7-11 Liu X. Y., Qian D. F., Xie J. G., et al. Study of cordierite horeycomb ceramics firing process. Chinese Journal of Ceramic Engineering, 1999,33(3):7-11(in Chinese)
    [5] 张强, 许世森, 王志强. 选择性催化还原烟气脱硝技术进展及工程应用. 热力发电, 2004,33(4):1-6 Zhang Q., Xu S. S.,Wang Z. Q. Advancement and engineering application of flue gas denitrification technology by using SCR method. Thermal Power Generation, 2004,33(4):1-6(in Chinese)
    [6] Pio F. Present status and perspectives in de-NOx SCR catalysis. Applied Catalysis A: General, 2001,222(1-2):221-236
    [7] 何文深, 陈建军, 郑佐东. SCR蜂窝式脱硝催化剂抗磨损性能研究. 电力科技与环保, 2011,27(5):10-12 He W. S., Chen J. J., Zheng Z. D. Study of abrasion performance of SCR honeycomb catalysts. Power Science and Environmental Protection, 2011,27(5):10-12(in Chinese)
    [8] 李锋, 於承志, 张朋,等. 高尘烟气脱硝催化剂耐磨性能研究. 能源环境保护, 2011,39(12):73-75 Li F., Yu C. Z., Zhang P., et al. Study on abrasiebeness of catalyst used for denitrification in flue gas with high dust content. Energy Environmental Protection, 2011,39(12):73-75(in Chinese)
    [9] 曾令可, 王慧, 罗民华,等. 多孔功能陶瓷制备与应用. 北京:化学工业出版社,2006
    [10] Zhu X. W., Jiang D. L., Tan S. H. Reaction bonding of open cell SiC-Al2O3 composites. Materials Research Bulletin,2001,36(11):2003-2015
    [11] Then P. M., Day P. The catalytic converter ceramic substrate: An astonishing and enduring invention. Interceram, 2000,49(1):20-23
    [12] Li Landong, Zhang Fuxiang, Guan Naijia, et al. Metal-ZSM25/cordierite monolithic catalysts for purifying lean-burn engine exhaust. Chinese Journal of Catalysis,2006,27(1):41-44
    [13] Seong Moon Jung, Paul Grange. Characterization and reactivity of V2O5-WO3 supported on TiO2-SO42- catalyst for the SCR reaction. Applied Catalysis B: Environmental, 2001,32(1-2):123-131
    [14] Ingemar Odenbrand C. U., Ana Bahamonde, Pedro Avila, et al. Kinetic study of the selective reduction of nitric oxide over vanadia-tungsta-titania/sepiolite catalyst. Applied Catalysis B: Environmental, 1994,5(1-2):117-131
    [15] Motonobu Kobayashi, Ryoji Kuma, Sinyuki Masaki, et al. TiO2-SiO2 and V2O5/TiO2-SiO2 catalyst: Physico-chemical characteristics and catalytic behavior in selective catalytic reduction of NO by NH3. Applied Catalysis B: Environmental, 2005,60(3-4):173-179
    [16] Vipul Kumar, Nathan Lee, Cathetine Bothe Almquist. An investigation of the thermal stability and performance of wet-incipient WO3/V2O5/TiO2 catalysts and a comparison with flame aerosol catalysts of similar composition for the gas-phase oxidation of methanol. Applied Catalysis B: Environmental, 2006,69(1-2):101-114
    [17] Alemany J., Ferlazzo N., Forzatti P., et al. Oxidation of SO2 to SO3 over honeycomb DeNoxing catalysts. Ind. Eng. Chem. Res., 1993,32(5):826-834
    [18] Alemany L. J., Lietti L., Ferlazzo N., et. al. Reactivity and physicochemical characterization of V2O5-WO3-TiO2 De-NOx catalysts. Journal of Catalysis, 1995,155(1):117-130
    [19] Motonobu Kobayashi, Mitsuharu Hagi. V2O5-WO3/TiO2-SiO2-SO42-catalyst: Influence of active components and supports on activities in the selective catalytic reduction of NO by NH3 and in the oxidation of SO2. Applied Catalysis B: Environmental, 2006,63(1-2):104-113
    [20] 刘清雅, 刘振宇, 李成岳. NH3在选择性催化还NO过程中的吸附与活化. 催化学报, 2006,27(7):636-646 Liu Q. Y., Liu Z. Y., Li C. Y. Adsorption and activation of NH3 during selective catalytic reduction of NO by NH3. Chinese Journal of Catalysis, 2006,27(7):636-646(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2186
  • HTML全文浏览数:  928
  • PDF下载数:  1358
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-04-25
  • 刊出日期:  2013-06-11
席文昌, 刘清才, 杨剑, 贺媛媛, 黄锐, 袁鹏, 洪燕. 以堇青石和二氧化钛为载体脱硝催化剂性能[J]. 环境工程学报, 2013, 7(6): 2262-2266.
引用本文: 席文昌, 刘清才, 杨剑, 贺媛媛, 黄锐, 袁鹏, 洪燕. 以堇青石和二氧化钛为载体脱硝催化剂性能[J]. 环境工程学报, 2013, 7(6): 2262-2266.
shu
Xi Wenchang, Liu Qingcai, Yang Jian, He Yuanyuan, Huang Rui, Yuan Peng, Hong Yan. Performance of deNOx catalyst supported on cordierite-TiO2 carrier[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2262-2266.
Citation: Xi Wenchang, Liu Qingcai, Yang Jian, He Yuanyuan, Huang Rui, Yuan Peng, Hong Yan. Performance of deNOx catalyst supported on cordierite-TiO2 carrier[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2262-2266.
shu

以堇青石和二氧化钛为载体脱硝催化剂性能

  • 1.  重庆大学材料科学与工程学院, 重庆 400044
  • 2.  重庆远达催化剂制造有限公司, 重庆 401336
  • 3.  中电投远达环保工程有限公司, 重庆 401122
  • 收稿日期:  2012-04-25
基金项目:

国家高技术研究发展计划(863)项目(2010AA065001)

科技人员服务企业行动(2009GJF10047)

重庆市科技攻关项目(CSTC,2010AB7132)

摘要: 采用改性堇青石和锐钛型二氧化钛为载体,以偏钨酸氨为WO3(助剂)的前驱体,以偏钒酸铵为V2O5(活性组分)的前驱体,通过混合、挤出、干燥和煅烧等工艺制备出蜂窝式SCR脱硝催化剂,采用N2-吸附仪(BET)、X-射线衍射分析仪(XRD)、模拟烟气活性分析装置和磨损装置,再通过催化剂样品的吸水率和收缩率对比分析。考察催化剂样品的比表面积、晶相结构、耐磨损性能、脱硝活性及其吸水率和收缩率变化。结果表明,以10%堇青石和二氧化钛为载体制备出的催化剂比表面积大,晶相结构以堇青石和锐钛矿型二氧化钛为主,其磨损率低,吸水率和收缩率变化小,脱硝率在80%以上时,与商业催化剂相比,反应温度窗口从300~400℃拓宽为250~460℃。
