温度及外加碳源对生物脱氮除磷过程的影响

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

操家顺, 侯梁浩, 方芳, 江心, 肖敏艳, 陈学明. 温度及外加碳源对生物脱氮除磷过程的影响[J]. 环境工程学报, 2013, 7(6): 2013-2018.
引用本文: 操家顺, 侯梁浩, 方芳, 江心, 肖敏艳, 陈学明. 温度及外加碳源对生物脱氮除磷过程的影响[J]. 环境工程学报, 2013, 7(6): 2013-2018.
shu
Cao Jiashun, Hou Lianghao, Fang Fang, Jiang Xin, Xiao Minyan, Chen Xueming. Effect of temperature and external carbon source on simultaneous nitrogen and phosphorus removal[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2013-2018.
Citation: Cao Jiashun, Hou Lianghao, Fang Fang, Jiang Xin, Xiao Minyan, Chen Xueming. Effect of temperature and external carbon source on simultaneous nitrogen and phosphorus removal[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2013-2018.
shu

温度及外加碳源对生物脱氮除磷过程的影响

  • 1.

    河海大学浅水湖泊综合治理与资源开发教育部重点实验室, 南京 210098

  • 2.

    河海大学环境学院, 南京 210098

  • 基金项目:

    国家自然科学基金资助项目(51008112)

    国家科技重大专项(2012ZX07101-003)

    省科技成果课题(BA2012055)

  • 中图分类号: X703.1

Effect of temperature and external carbon source on simultaneous nitrogen and phosphorus removal

  • 1.

    Key Laboratory of Integrated Regulation and Resource Development on Shallow Lakes, Ministry of Education, Hohai University, Nanjing 210098, China

  • 2.

    College of Environment, Hohai University, Nanjing 210098, China

  • Fund Project:

HTML全文

  • 摘要: 针对污水处理厂普遍面临的进水碳源不足及冬季低温时出水氮磷不能稳定达标的问题,研究了温度(21、15和10℃)和外加碳源(乙酸)对活性污泥缺氧条件下反硝化及释磷过程的影响。结果表明,在缺氧条件下投加乙酸,释磷与反硝化反应可同时进行,且乙酸投量的增加仅延长快速碳源反硝化阶段及缺氧释磷阶段的反应时间;温度降低为15℃和10℃时,快速碳源反硝化阶段反硝化速率及缺氧释磷速率较21℃分别降低了约29.2%、42.2%和26.1%、32.3%。当硝态氮目标去除量与磷酸盐目标释放量之比超过5时,乙酸的最优投量以满足反硝化要求为准,计算得出21、15和10℃时常州某城镇污水处理厂乙酸最优投加量计算值约为30、39和46 mg/L。
    Abstract: Due to the insufficient carbon source of the wastewater treatment plant and the failure to reach stable up-to-standard nitrogen and phosphorus in effluent at low temperatures in winter, the influences of temperature (21℃, 15℃ and 10℃) and external carbon source on denitrification and phosphorus releasing processes of activated sludge under anoxic condition were investigated. The results indicated that acetic acid was utilized simultaneously by denitrification and phosphorus release reaction. The increased acetic acid concentration of dosage only led to the increase in reaction time of denitrification (readily biodegradable chemical oxygen demand) and anoxic phosphorus release. The decrease in temperature had a great influence on denitrification and phosphorus release rates. Compared with that at 21℃, the denitrification rate at 15℃ and 10℃ decreased about 29.2% and 42.2%, respectively; the phosphorus release rate at 15℃ and 10℃ decreased about 26.1% and 32.3%, respectively. When the ratio of the nitrate to phosphate concentration was about 5, the optimal dosage of acetic acid was just to meet the requirements of nitrogen removal. The optimal dosage of acetic acid in a wastewater treatment plant in Changzhou was calculated to be 30, 39 and 46 mg/L at 21, 15 and 10℃, respectively.
  • [1] 孙慧, 郑兴灿, 孙永利, 等. 外加碳源对改良A2/O工艺反硝化除磷的影响. 中国给水排水, 2010,26(13):82-85 Sun H., Zheng X.C., Sun Y.L., et al. Effect of external carbon source on denitrifying phosphorus removal in modified A2/O process. China Water and Wastewater, 2010,26(13):82-85(in Chinese)
    [2] 郑兴灿, 李激, 孙永利, 等. 无锡芦村污水处理厂一级A达标难度分析与对策措施探讨. 给水排水, 2009,35(6):24-28 Zheng X.C., Li J., Sun Y.L., et al. Difficulty analysis and countermeasures discussion on the first class A effluent limits attainment of Lucun wastewater treatment plant in Wuxi city. Water and Wastewater Engineering, 2009,35(6):24-28(in Chinese)
    [3] 吴昌永, 彭永臻, 彭轶. A2/O工艺的反硝化除磷特性研究. 中国给水排水, 2008,24(15):11-14 Wu C.Y., Peng Y.Z., Peng Y. Study on characteristics of denitrifying phosphorus removal in A2/O process. China Water and Wastewater, 2008,24(15):11-14(in Chinese)
    [4] 杨巧林, 奚小英, 陈娜, 等. 外加碳源对污水厂异常进水时的强化脱氮效果. 给水排水, 2011,27(3):106-108 Yang Q.L., Xi X.Y., Chen N., et al. Enhanced nitrogen removal efficiency of external carbon source during abnormal influent in municipal wastewater treatment plant. Water and Wastewater Engineering, 2011,27(3):106-108(in Chinese)
    [5] Fernandez F.J., Castro M.C., Villasenor J., et al. Agro-food wastewaters as external carbon source to enhance biological phosphorus removal. Chemical Engineering Journal, 2011,166(2):559-567
    [6] Xie L., Chen J.R., Wang R., et al. Effects of carbon sources and COD/NO3--N ratio on anaerobic simultaneous denitrification and methanogenesis for high-strength wastewater treatment. Journal of Bioscience and Bioengineering, 2012,113(6):759-764
    [7] Merzouki M., Bemet N., Delgenes J.P., et al. Biological denitrifying phosphorus removal in SBR: Effect of added nitrate concentration and sludge retention time. Water Science and Technology, 2001,43(3):191-194
    [8] 国家环境保护局. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社, 2002
    [9] Meyer R.L., Zeng R.J., Giugliano V. Challenges for simultaneous nitrification, denitrifation, and phosphorus removal in microbial aggregates: Mass transfer limitation and nitrous oxide production. FEMS Microbiology Ecology, 2005,52(3):329-338
    [10] 曹相生, 钱栋, 孟雪征. 乙酸钠为碳源时的污水反硝化规律研究. 中国给水排水, 2011,27(21):76-79 Cao X.S., Qian D., Meng X.Z. Characteristics of denitrification process with sodium acetate as sole carbon source. China Water and Wastewater, 2011,27(21):76-79(in Chinese)
    [11] Lemos P.C., Serafim L.S. Synthesis of polyhydroxyalkanoates from different short-chain fatty acids by mixed cultures submitted to aerobic dynamic feeding. Journal of Biotechnology, 2006,122(2),226-238
    [12] 殷芳芳, 王淑莹, 侯红勋, 等. 碳源类型对低温条件下生物反硝化的影响. 环境科学, 2009,30(1):108-113 Yin F.F., Wang S.Z., Hou H.X., et al. Effects of carbon source types on denitrification performance at low temperature. Environmental Science, 2009,30(1):108-113(in Chinese)
    [13] 姜体胜, 杨琦, 尚海涛. 温度和pH值对活性污泥法脱氮除磷的影响. 环境工程学报, 2007,1(9):10-14 Jiang T.S., Yang Q., Shang H.T. Effects of temperature and pH on nitrogen and phosphorus removal by activated sludge. Chinese Journal of Environmental Engineering, 2007,1(9):10-14(in Chinese)
    [14] Guerrero J., Guisasola A., Baeza J.A. The nature of the carbon source rules the competition between PAO and denitrifiers in systems for simultaneous biological nitrogen and phosphorus removal. Water Research, 2011,45(16):4793-4802
    [15] 王辉, 沈耀良. 硝酸盐对反硝化除磷过程的影响分析. 环境工程学报, 2009,3(6):977-980 Wang H., Shen Y.L. Impact analysis of nitrate on denitrifying dephosphatation. Chinese Journal of Environmental Engineering, 2009,3(6):977-980(in Chinese)
    [16] Chuang S.H., Chang W.C., Huang Y.H., et al. Effects of different carbon supplements on phosphorus removal in low C/P ratio industrial wastewater. Bioresource Technology, 2011,102(9):5461-5465
    [17] Elefsiniotis P., Li D. The effect of temperature and carbon source on denitrification using volatile fatty acids. Biochemical Engineering Journal, 2006,28(2):148-155
    [18] Helmer C., Kunst S. Low temperature effects on phosphorus release and uptake by microorganisms in EBPR plants. Water Science and Technology, 1998,37(4-5):531-539
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2933
  • HTML全文浏览数:  1710
  • PDF下载数:  1413
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-03-11
  • 刊出日期:  2013-06-11
操家顺, 侯梁浩, 方芳, 江心, 肖敏艳, 陈学明. 温度及外加碳源对生物脱氮除磷过程的影响[J]. 环境工程学报, 2013, 7(6): 2013-2018.
引用本文: 操家顺, 侯梁浩, 方芳, 江心, 肖敏艳, 陈学明. 温度及外加碳源对生物脱氮除磷过程的影响[J]. 环境工程学报, 2013, 7(6): 2013-2018.
shu
Cao Jiashun, Hou Lianghao, Fang Fang, Jiang Xin, Xiao Minyan, Chen Xueming. Effect of temperature and external carbon source on simultaneous nitrogen and phosphorus removal[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2013-2018.
Citation: Cao Jiashun, Hou Lianghao, Fang Fang, Jiang Xin, Xiao Minyan, Chen Xueming. Effect of temperature and external carbon source on simultaneous nitrogen and phosphorus removal[J]. Chinese Journal of Environmental Engineering, 2013, 7(6): 2013-2018.
shu

温度及外加碳源对生物脱氮除磷过程的影响

  • 1.  河海大学浅水湖泊综合治理与资源开发教育部重点实验室, 南京 210098
  • 2.  河海大学环境学院, 南京 210098
  • 收稿日期:  2013-03-11
基金项目:

国家自然科学基金资助项目(51008112)

国家科技重大专项(2012ZX07101-003)

省科技成果课题(BA2012055)

摘要: 针对污水处理厂普遍面临的进水碳源不足及冬季低温时出水氮磷不能稳定达标的问题,研究了温度(21、15和10℃)和外加碳源(乙酸)对活性污泥缺氧条件下反硝化及释磷过程的影响。结果表明,在缺氧条件下投加乙酸,释磷与反硝化反应可同时进行,且乙酸投量的增加仅延长快速碳源反硝化阶段及缺氧释磷阶段的反应时间;温度降低为15℃和10℃时,快速碳源反硝化阶段反硝化速率及缺氧释磷速率较21℃分别降低了约29.2%、42.2%和26.1%、32.3%。当硝态氮目标去除量与磷酸盐目标释放量之比超过5时,乙酸的最优投量以满足反硝化要求为准,计算得出21、15和10℃时常州某城镇污水处理厂乙酸最优投加量计算值约为30、39和46 mg/L。
