丁建东, 唱鹤鸣, 丁勇. 电镀污泥回收重金属的新工艺[J]. 环境工程学报, 2013, 7(5): 1969-1973.
引用本文: 丁建东, 唱鹤鸣, 丁勇. 电镀污泥回收重金属的新工艺[J]. 环境工程学报, 2013, 7(5): 1969-1973.
shu
Ding Jiandong, Chang Heming, Ding Yong. New technology for heavy metals recovery from electroplating sludge[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1969-1973.
Citation: Ding Jiandong, Chang Heming, Ding Yong. New technology for heavy metals recovery from electroplating sludge[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1969-1973.
shu

电镀污泥回收重金属的新工艺

  • 1.

    南通大学化学化工学院,南通 226019

  • 基金项目:

    南通大学自然科学基金资助项目(10Z016)

  • 中图分类号: X705

New technology for heavy metals recovery from electroplating sludge

  • 1.

    School of Chemistry and Chemical Engineering, Nantong University, Nantong 226019, China

  • Fund Project:

HTML全文

  • 摘要: 合理、经济地处理混合电镀污泥,回收其中有价值的金属具有重要意义。以不同的酸作为浸出剂对电镀污泥中的金属进行了浸出效果实验。结果表明,在相同条件下,各酸的浸出效果顺序为:硫酸>盐酸>王水>硝酸;液体水与固体电镀污泥比为3,干污泥为5 g,硫酸加入量为15 mL,时间1 h条件下,混合电镀污泥中金属铜锌的浸出率最大,达到97.38%。分别采用铁和铁锰合金还原剂常温还原低熔点重金属离子铜、锌,浸出液中99%以上含量的铜、锌沉淀,使低熔点重金属与黑色金属铁、锰、铬有效分离。低熔点混合重金属可以用来做铜合金添加剂使用,最后沉淀的混合黑色金属氢氧化物处理后可以用来做炼钢合金添加剂使用。
    Abstract: It is very significant that the valuable metals are recovered from electroplating sludge by reasonable and economic methods. The efficiency of multiple heavy metals extraction from hazardous electroplating sludge via different acid leaching was studied. Under the same conditions, the results showed that the best effect of leaching acid was sulfuric acid, then hydrochloric acid, aqua, nitrate. When 5 g of dried sludge at a 3:1 water/solid ratio, was mixed with 15 mL H2SO4 for 1 h, the highest leaching efficiency of Cu and Zn from electroplating sludge reached to 97.38%. Fe and Fe-Mn alloy were used as reducing agents to reduce low melting point heavy metal ions of Cu and Zn, at room temperature. The results indicated that more than 99% of Cu and Zn in leaching solution were precipitated. Cu and Zn were separated effectively from Fe, Mn and Cr. The low melting point metals can be used as copper alloy additive; the mixed hydroxides of Fe, Mn and Cr can be used as steel smelting additive after reasonable treatment.
  • [1] 曾彩明,王德汉,谢国樑,等.不同预处理对电镀污泥电动过程的影响. 环境工程学报, 2008,2(1):120-125 Zeng C. M., Wang D. H., Xie G. L., et al. Effect of different pretreatments on electro kinetic processes of electroplating sludge. Chinese Journal of Environmental Engineering, 2008,2(1):120-125 (in Chinese)
    [2] Rossini G., Bernardes A. M. Galvanic sludge metals recovery by pyrometallurgical and hydrometallurgical treatment. Journal of Hazardous Materials, 2006, 131(1-3): 210-216
    [3] Paula T., Souzae S., Nielson T. M., et al. Extraction and recovery of chromium from electroplating sludge. Journal of Hazardous Materials, 2006, 128(1):39-43
    [4] Kuchar D., Fukuta T., Onyango M. S., et al. Sulfidation treatment of copper-containing plating sludge towards copper resource recovery. Journal of Hazardous Materials, 2006, B138(5):86-94
    [5] 李盼盼,彭昌盛. 电镀污泥中铜和镍的回收工艺研究——污泥的酸浸出工艺.电镀与精饰, 2010,3(1):37-40 Li P. P., Peng C. S. Recovery technology of copper and nickel from electroplating sludge—Acid-leaching process of electroplating sludge. Plating and Finishing, 2010,3(1):37-40 (in Chinese)
    [6] 杨振宁,陈志传,高大明,等. 电镀污泥中铜镍回收方法及工艺的研究.环境污染与防治, 2008,30(7):58-61 Yang Z. N., Chen Z. C., Gao D. M., et al. Recovery of copper and nickel from electroplating sludge. Environmental Pollution and Control, 2008,30(7):58-61 (in Chinese)
    [7] 陈娴,程洁红,顾冬梅.还原焙烧-酸浸回收电镀污泥中的铜. 环境污染与防治, 2011,33(6):48-51 Chen X., Cheng J. H., Gu D. M. Recovery of copper from galvanic sludge by reductive roasting combined with acid leaching. Environmental Pollution and Control, 2011,33(6):48-51 (in Chinese)
    [8] Nazely D., Rosa M., Ane U., et al. Zinc recovery and waste sludge minimization from chromium passivation baths. Journal of Hazardous Materials, 2011,192(2):801-807
    [9] 张学鸿,王敦球,黄明,等.电镀污泥处理技术进展. 桂林工学院学报, 2004,24(4):505-505 Zhang X. H., Wang D. Q., Huang M., et al. Development of electroplating sludge technology. Journal of Guilin University of Technology, 2004,24(4):505-505 (in Chinese)
    [10] 季文佳,王琪,黄启飞,等. 电镀污泥中重金属含量差异性研究.环境工程,2010,28(增刊):265-267 Ji W. J., Wang Q., Huang Q. F., et al. Study on the content difference of heavy metals in electroplating sludge. Environmental Engineering, 2010,28(Spec):265-267 (in Chinese)
    [11] 石太宏, 陈可. 电镀重金属污泥的无害化处置和资源化利用.污染防治技术, 2007,2(2):48-52 Shi T. H., Chen K. The innoxious disposal and reuse of electroplating sludge containing heavy metals. Pollution Control Technology, 2007,2(2):48-52 (in Chinese)
    [12] 李海英,谢逢春,李春城,等. 线路板废弃污泥资源化、无害化处理新工艺.环境工程,2008, 26(6):88-90 Li H. Y., Xie F. C., Li C. C., et al. New technology for resource utilization and harmless treatment of waste circuit board sludge. Environmental Engineering, 2008,26(6):88-90 (in Chinese)
    [13] 朱耀华.电镀废水治理技术综述. 北京:中国环境科学出版社,1992.46
    [14] 吴宝明.电镀污泥的资源化研究. 南京:南京工业大学硕士学位论文,2005 Wu B. M. Study on the recycle treatment of electro plating sludge. Nanjing: Master Dissertation of Nanjing University of Technology, 2005 (in Chinese)
    [15] 杨家定.电镀污泥中铜、镍、铬、锌的回收利用研究. 化学工程与装备, 2008,(6):138-142 Yang J. D. Study of the recycle technology of the copper, nickel, chromium, zinc from the electroplating sludge. Chemical Engineering and Equipment, 2008,(6):138-142 (in Chinese)
    [16] 李红艺,刘伟京,陈勇.电镀污泥中铜和镍的回收和资源化技术. 中国资源综合利用, 2005,(12):7-10 Li H. G., Liu W. J., Chen Y. Study of the technology of reclaiming copper and nickel from electroplating sludge. China Resources Comprehensive Utilization, 2005,(12):7-10 (in Chinese)
    [17] 陈凡植, 陈庆邦,聂晓军,等.电镀污泥的综合利用实验研究. 化工进展,2001,(7):25-28 Chen F. Z., Chen Q. B., Nie X. J.,et al. Experiment study on comprehensive utilization of electroplating sludge. Chemical Industry and Engineering Progress, 2001,(7):25-28 (in Chinese)
    [18] 刘俊,赵一先,陈秋则,等.从电镀锌废渣中回收制备锌盐的研究. 上海环境科学, 2002,21(11):672-675 Liu J., Zhao Y. X., Chen Q. Z. Recovery of Zn from Zinc-plating residues. Shanghai Environmental Sciences, 2002,21(11):672-675 (in Chinese)
    [19] Silva J., Soares D., Paiva A., et al. Leaching behaviour of a galvanic sludge in sulphuric acid and ammoniacal media. Journal of Hazardous Materials, 2005, 121 (1): 195-202
    [20] Li C. C., Xie F. C., Ma Y., et al. Multiple heavy metals extraction and recovery from hazardous electroplating sludge waste via ultrasonically enhanced two-stage acid leaching. Journal of Hazardous Materials, 2010, 178 (1/2/3):823-833
