张海霞, 李爱民, 鞠茂伟. 小型好氧堆肥设备处理有机垃圾[J]. 环境工程学报, 2013, 7(5): 1939-1944.
引用本文: 张海霞, 李爱民, 鞠茂伟. 小型好氧堆肥设备处理有机垃圾[J]. 环境工程学报, 2013, 7(5): 1939-1944.
shu
Zhang Haixia, Li Aimin, Ju Maowei. Organic matters degradation in small-scale aerobic compost treatment facilities[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1939-1944.
Citation: Zhang Haixia, Li Aimin, Ju Maowei. Organic matters degradation in small-scale aerobic compost treatment facilities[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1939-1944.
shu

小型好氧堆肥设备处理有机垃圾

  • 1.

    河北工程大学城市建设学院, 邯郸 056038

  • 2.

    大连理工大学环境学院 工业生态与环境工程教育部重点实验室, 大连 116024

  • 基金项目:

    邯郸市科学技术研究与发展计划项目(1223109092-5)

  • 中图分类号: X705

Organic matters degradation in small-scale aerobic compost treatment facilities

  • 1.

    College of City of Construction, Hebei University of Engineering, Handan 056038, China

  • 2.

    Key Laboratory of Industrial Ecology and Environmental Engineering, Ministry of Education, School of Environmental Science and Technology, Dalian University of Technology, Dalian 116024, China

  • Fund Project:

HTML全文

  • 摘要: 针对我国生活垃圾的特点, 提出了厨余等有机生活垃圾单独收集,在产生源头进行好氧堆肥处理。研制了好氧堆肥设备,由加热装置、通风装置、冷凝水收集和回灌装置,以及与该生物堆肥设备配套的生物过滤除臭装置、自控系统和数据采集软件几部分构成。自控系统由氧气、温度、湿度三路传感器以及2个控制器构成, 并与加热装置、通风装置连接, 能满足物料加热、供氧和散热的要求。本研究通过为期30 d的试运行实验表明,物料快速升温并稳定保持在高温阶段(50～60℃),物料中的氧气浓度保持在14%～16%范围内。在堆肥实验结束时,物料的含水率降至36.4%,有机质含量降至49%,另外,通过好氧速率指标也可判定物料达到腐熟。
    Abstract: In view of the characteristics of MSW, with high water content and high organic content, sorting collection of kitchen waste and adopting source reduction treatment by aerobic biological technology were introduced. In this study, biological treatment device design, making, and experimental study were carried out. The aerobic biological treatment device was consisted of the following components: heating system, ventilation system, water collection and recirculation systems, bio-filter deodorizing device, and automatic control system. Automatic control system comprised of oxygen, temperature, humidity sensors, and two controllers, which connect with heating and ventilation systems. The automatic control system could satisfy the heat, oxygen, heat requirements of the materials in the device. The composting experiment for 30 days showed that the temperature of feed-in material remained at 50～60℃ and oxygen content was 14%～16% during the operation period. At the end of the composting experiment, the moisture content and organic matter content of the material decreased to 36.4% and 49%, respectively. Additionally, oxygen consumption rate also indicated that the composted material attained maturity at the end of the experiment.
  • [1] 席北斗, 刘鸿亮, 孟伟, 等. 高效复合微生物菌群在垃圾堆肥中的应用. 环境科学,2001, 22(5): 122-125 Xi Beidou, Liu Hongliang, Meng Wei, et al. Composting process of municipal solid waste with high effective complex microbial community. Environmental Science, 2001, 22(5): 122-125 (in Chinese)
    [2] 石磊, 赵由才, 李兵. 小型有机垃圾生化处理机的开发与应用进展. 中国沼气,2004, 22(3): 15-18 Shi Lei, Zhao Youcai, Li Bing. Development and application of small-scale organic waste bio-treatment device. China Biogas, 2004, 22(3): 15-18 (in Chinese)
    [3] 叶邵燕. 南宁市垃圾渗滤液对地表水的影响. 职业与健康,2010, 26(9):1034-1035 Ye Shaoyan. Effect of landfill leachate on surface water in Nanning city. Occupation and Health, 2010, 26(9): 1034-1035(in Chinese)
    [4] Benedict A. H., Epstein E., English J. N. Municipal sludge composting technology evaluation. Journal of the Water Pollution Control Federation, 1986, 58 (4): 279-289
    [5] Pereira-Neto J. T., Stentiford E. , Mara D. D. Low cost controlled composting of refuse and sewage sludge. Water Science and Technology, 1987, 19(5-6): 839-845
    [6] Haug R. T. Composting process design criteria: PartⅢ-Aeration. Biocycle, 1986, 27(9): 53-57
    [7] Leton T. G., Stentiford E. . Control of aeration in static pile composting. Waste Management & Research, 1990, 8(4): 299-306
    [8] Sesay A. A., Lasaridi K. E., Stentiford E. . Aerated static pile composting of municipal solid waste (MSW): A comparison of positive pressure aeration with hybrid positive and negative aeration. Waste Management & Research, 1998, 16 (3): 264-272
    [9] 胡天觉,曾光明,袁兴中. 城市固体有机废物堆肥实验装置设计.环境污染治理技术与设备, 2002, 3(2): 71-75 Hu Tianjue, Zeng Guangming, Yuan Xingzhong. Design of composting experimental device of municipal organic solid waste. Techniques and Equipment For Environment Pollution Control, 2002, 3(2): 71-75 (in Chinese)
    [10] 石文军, 杨朝晖, 肖勇, 等. 全程高温好氧堆肥快速降解城市生活垃圾. 环境科学学报, 2009, 29(10): 2126-2133 Shi Wenjun, Yang Zhaohui, Xiao Yong, et al. Composting of municipal solid waste by continuous high-temperature aerobic composting. Acta Scientiae Circumstantiae, 2009, 29(10): 2126-2133 (in Chinese)
    [11] 李承强, 魏源送,樊耀波, 等. 堆肥腐熟度的研究进展. 环境科学进展, 1999, 7(6): 1-12 Li Chengqiang, Wei Yuansong, Fan Yaobo, et al. Advances in study of compost maturity. Advances in Environmental Science, 1999, 7(6): 1-12 (in Chinese)
    [12] 聂永丰. 三废处理工程技术手册(固体废物卷). 北京:化学工业出版社, 2000
    [13] 郑玉琪, 陈同斌, 孔建松, 等. 利用耗氧速率判断好氧堆肥腐熟度的探讨. 环境科学学报, 2004, 24(5): 930-935 Zheng Yuqi, Chen Tongbin,Kong Jiansong, et al. Maturity assessment by oxygen consumption rate in aerobic composting. Acta Scientiae Circumstantiae, 2004, 24(5): 930-935 (in Chinese)
    [14] Wu L., Ma L. Q., Martinez G. A. Comparison of methods for evaluating stability and maturity of biosolids compost. Journal of Environmental Quality, 2000, 29(2): 424-432
    [15] Campitelli P., Ceppi S. Chemical, physical and biological compost and vermicompost characterization: A chemometric study. Chemom. Intell. Lab. Syst., 2008, 90(1): 64-71
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2260
  • HTML全文浏览数:  1383
  • PDF下载数:  1053
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-10-18
  • 刊出日期:  2013-05-22
张海霞, 李爱民, 鞠茂伟. 小型好氧堆肥设备处理有机垃圾[J]. 环境工程学报, 2013, 7(5): 1939-1944.
引用本文: 张海霞, 李爱民, 鞠茂伟. 小型好氧堆肥设备处理有机垃圾[J]. 环境工程学报, 2013, 7(5): 1939-1944.
shu
Zhang Haixia, Li Aimin, Ju Maowei. Organic matters degradation in small-scale aerobic compost treatment facilities[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1939-1944.
Citation: Zhang Haixia, Li Aimin, Ju Maowei. Organic matters degradation in small-scale aerobic compost treatment facilities[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1939-1944.
shu

小型好氧堆肥设备处理有机垃圾

  • 1. 河北工程大学城市建设学院, 邯郸 056038
  • 2. 大连理工大学环境学院 工业生态与环境工程教育部重点实验室, 大连 116024
  • 收稿日期:  2012-10-18
基金项目:

邯郸市科学技术研究与发展计划项目(1223109092-5)

摘要: 针对我国生活垃圾的特点, 提出了厨余等有机生活垃圾单独收集,在产生源头进行好氧堆肥处理。研制了好氧堆肥设备,由加热装置、通风装置、冷凝水收集和回灌装置,以及与该生物堆肥设备配套的生物过滤除臭装置、自控系统和数据采集软件几部分构成。自控系统由氧气、温度、湿度三路传感器以及2个控制器构成, 并与加热装置、通风装置连接, 能满足物料加热、供氧和散热的要求。本研究通过为期30 d的试运行实验表明,物料快速升温并稳定保持在高温阶段(50～60℃),物料中的氧气浓度保持在14%～16%范围内。在堆肥实验结束时,物料的含水率降至36.4%,有机质含量降至49%,另外,通过好氧速率指标也可判定物料达到腐熟。
