谢敏, 高丹, 刘小波, 李芳, 黄聪. 利用给水厂污泥制备透水砖的实验研究[J]. 环境工程学报, 2013, 7(5): 1925-1928.
引用本文: 谢敏, 高丹, 刘小波, 李芳, 黄聪. 利用给水厂污泥制备透水砖的实验研究[J]. 环境工程学报, 2013, 7(5): 1925-1928.
shu
Xie Min, Gao Dan, Liu Xiaobo, Li Fang, Huang Cong. Experimental study on production of water permeable brick using waterworks sludge[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1925-1928.
Citation: Xie Min, Gao Dan, Liu Xiaobo, Li Fang, Huang Cong. Experimental study on production of water permeable brick using waterworks sludge[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1925-1928.
shu

利用给水厂污泥制备透水砖的实验研究

  • 1.

    长沙理工大学水利工程学院,长沙 410014

  • 基金项目:

    国家自然科学基金资助项目(51108043)

    湖南省科技计划项目(2010GK3207)

    国家级大学生创新实验项目

  • 中图分类号: X705

Experimental study on production of water permeable brick using waterworks sludge

  • 1.

    Institute of Hydraulic Engineering, Changsha University of Science and Technology, Changsha 410114, China

  • Fund Project:

HTML全文

  • 摘要: 以给水厂污泥、粉煤灰和普通砂为主要原料,添加一定量的粘结剂制备透水砖。探讨了污泥掺加量、烧结温度和成型压力对透水砖基本性能的影响,结果表明,当污泥掺量为30%～40%,添加30%～35%,粒径为1.0～1.4 mm普通砂颗粒时,在30 MP压力下成型、1 150℃下烧结制备出的成品抗压强度达36.53 MP,透水系数为1.08×10-2 cm/s,满足JC/T945-2005《透水砖》相关要求。
    Abstract: In the present study, combination of waterworks sludge, fly ash and common sand was prior used to generate water permeable bricks with adding a certain amount of binder. Subsequently, how the following parameters i.e. sludge adding rate, sintering and molding temperature affected the key characteristics of the proposed bricks were investigated in-depth. Finally, it can be obtained from the study that the generated bricks (compressive strength: 36.53 MP; permeability coefficient: 1.08×10-2 cm/s) could satisfy the product requirements (water permeable brick, JC/T945-2005) under the following production conditions: introducing 30%～40% of sludge, and 30%～35% of common sand with particle size ranging from 1.0 to 1.4 mm; constructing at 30 MP and sintering at 1 150℃ for 1 h.
  • [1] Miklas Scholz, Piotr Grabowiecki. Review of permeable pavement systems. Building and Environment, 2007, 42(11):3830-3836
    [2] 杨林, 张洪波, 曹建新. 硅锰渣制生态渗水砖. 新型建筑材料, 2007, (6):27-30 Yang Lin, Zhang Hongbo, Cao Jianxin. Preparation of ecology water penetrable brick using siliconmanganese slag. New Building Materials, 2007, (6):27-30 (in Chinese)
    [3] 饶玲丽, 曹建新, 张洪波,等. 粉煤灰透水砖的制备研究. 新型建筑材料, 2006, (7):48-50 Rao Lingli, Cao Jianxin, Zhang Hongbo, et al. Research on water permeable brick using fly ash. New Building Materials, 2006, (7):48-50(in Chinese)
    [4] Cheng-Fang Lin, Chung-Hsin Wu, Hsiu-Mai Ho, et al. Recovery of municipal waste incineration bottom ash and water treatment sludge to water permeable pavement materials. Waste Management, 2006, 26(9):970-978
    [5] 徐子芳, 张明旭, 闵凡飞. 固体废弃物低温烧制优等节能保温砖强度机理及热性能分析. 环境工程学报, 2008, 2(4):548-551 Xu Zifang, Zhang Mingxu, Min Fanfe. Thermal performance and strength mechanism analysis of using solid waste at low temperature to roast high-class heat insulation brick. Chinese Journal of Environmental Engineering, 2008, 2(4):548-551 (in Chinese)
    [6] 林子增,王军,张林生. 城市污泥为掺料烧结砖的生产性试验研究. 环境工程学报, 2009, 3(10):1875-1878 Lin Zizen, Wang Ju, Zhang Linsheng. Application of municipal sewage sludge in fired brick manufacture. Chinese Journal of Environmental Engineering, 2009, 3(10):1875-1878 (in Chinese)
    [7] 贺君, 王启山, 任爱玲. 给水厂与污水厂污泥制陶粒技术研究. 环境工程学报,2009, 3(9):1653-1657 He Jun, Wang Qishan, Ren Ailing. Technology research on waterworks sludge and sewage sludge for ceram site. Chinese Journal of Environmental Engineering, 2009, 3(9):1653-1657 (in Chinese)
    [8] 王圃,龙腾锐,李江涛,等. 城市给水厂污泥处理与能耗.重庆建筑大学学报, 2005, 27(4):77-80 Wang Pu, Long Tengrui, Li Jiangtao, et al. Sludge treatment and energy consumption of urban water plant. Journal of Chongqing Jianzhu University, 2005, 27(4):77-80 (in Chinese)
    [9] 任伯帜, 田胜海. 城市给水厂污泥用于烧制粉煤灰-粘土砖的试验.城市环境与城市生态,2003,16(5):13-15 Ren Bozhi, Tian Shenghai. Experimental study of sintering brick with sludge of the urban water supply plant and fly-ash clay. Urban Environmental and Urban Ecology, 2003, 16(5):13-15(in Chinese)
    [10] 贺君, 王启山, 任爱玲. 给水厂与污水厂污泥制陶粒技术研究. 环境工程学报,2009, 3(9):1653-1657 He Jun, Wang Qishan, Ren Ailing. Technology research on waterworks sludge and sewage sludge for ceram site. Chinese Journal of Environmental Engineering, 2009, 3(9):1653-1657 (in Chinese)
    [11] Korsnes R. I., Risnes R., Faldaas I., et al. End effects on stress dependent permeability measurements. Tectono-physics, 2006, 426(1-2):23
    [12] 李国昌, 王萍. 赤泥透水砖的制备及性能研究. 金属矿山, 2009,402 (12):154-157 Li Guochang, Wang Ping. Study on preparation and performances of the water permeable brick from red mud. Metal Mine, 2009, 402 (12): 154-157 (in Chinese)
    [13] 李国昌, 王萍. 工艺条件对多孔透水砖基本性能的影响研究. 新型墙体材料与施工, 2005, (1):15-18 Li Guochang, Wang Ping. Study on effects of processing parameters upon properties of porous water permeable br ick. New Wall Materials and Construction, 2005, (1):15-18 (in Chinese)
    [14] 张洪波. 利用硅锰渣研制生态渗水砖. 贵州: 贵州大学硕士学位论文, 2007 Zhang Hongbo. Preparation of ecology water penetrable brick using siliconmanganese slag. Guizhou: Master Dissertation of Guizhou University, 2007 (in Chinese)
    [15] 李如林. 伟晶石陶瓷透水砖的研制与性能研究. 大连:大连理工大学硕士学位论文,2008 Li Rulin. Preparation and properties of permeable pegmatite ceramic brick. Dalian: Master Dissertation of Dalian University of Science and Technology, 2008 (in Chinese)
