臭氧生物活性炭工艺处理某多金属硫化矿浮选废水的小试研究

,  ,

downloadPDF

上一篇

下一篇

王自超, 刘兴宇, 宋永胜. 臭氧生物活性炭工艺处理某多金属硫化矿浮选废水的小试研究[J]. 环境工程学报, 2013, 7(5): 1723-1728.
引用本文: 王自超, 刘兴宇, 宋永胜. 臭氧生物活性炭工艺处理某多金属硫化矿浮选废水的小试研究[J]. 环境工程学报, 2013, 7(5): 1723-1728.
shu
Wang Zichao, Liu Xingyu, Song Yongsheng. Lab scale ozone-biological activated carbon reactor treatment of flotation wastewater from a nonferrous poly-metal ore mine[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1723-1728.
Citation: Wang Zichao, Liu Xingyu, Song Yongsheng. Lab scale ozone-biological activated carbon reactor treatment of flotation wastewater from a nonferrous poly-metal ore mine[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1723-1728.
shu

臭氧生物活性炭工艺处理某多金属硫化矿浮选废水的小试研究

  • 1.

    北京有色金属研究总院生物冶金国家工程实验室,北京 100088

  • 基金项目:

    "十一五"国家科技支撑计划项目(2009BAB45B01)

  • 中图分类号: TD952;X751

Lab scale ozone-biological activated carbon reactor treatment of flotation wastewater from a nonferrous poly-metal ore mine

  • 1.

    National Engineering Laboratory of Biohydrometallurgy, General Research Institute for Nonferrous Metals, Beijing 100088, China

  • Fund Project:

HTML全文

  • 摘要: 某多金属硫化矿选矿厂浮选废水水量大,目前该厂对浮选废水的处理方法为尾矿库砂滤治理,但该方法存在效率低、周期长、回用影响选矿指标等众多弊端。为高效低成本的处理浮选废水,结合浮选废水的特点(低COD、难降解、高pH),开展了臭氧氧化-生物活性炭吸附工艺处理选矿废水的小试研究。选矿废水中各残留有机药剂及pH对浮选指标的影响研究表明,废水中残留有机药剂及pH对浮选指标均有不同程度的影响。臭氧氧化-生活活性炭吸附工艺处理选矿废水的小试研究表明,水力停留时间为4 h、反应器臭氧浓度为33.3 mg/L,可获得COD去除率57%、pH降低到8的废水处理效果。将处理后的废水回用于选矿,基本消除残留药剂及pH对浮选指标的影响。本研究提供了一种处理浮选废水的新思路,对臭氧生物活性炭工艺处理浮选废水的工业应用具备参考价值。
    Abstract: The quantity of wastewater from a multi-metal sulfide ore mineral processing process is large. Current treatment of the wastewater is by the sand filter of tailing pond. Such treatment is low efficiency, long HRT and has adverse impact on the flotation process. In this study, a lab scale ozone-biological activated carbon (BAC) reactor was used to treat flotation wastewater. Results showed that pH and residual organic regent were the key factors which affected the floation when such wastewater was directly reused. After treating by ozone-BAC reactor at hydraulic retention time of 4 h, ozone concentration of 33.3 mg/L, the COD removal increased to 57% and pH reduced to 8. Then the treated wastewater was reused on flotation, the results show that it has the same effect as fresh water. This study provides a novel method for treating flotation wastewater, meanwhile it may have referential value for industrial applications of such technology.
  • [1] 谢光炎,孙水裕,宁寻安,等. 选矿废水的回用处理研究与实践. 环境污染治理技术与设备, 2002, 3(2): 67-70 Xie Guangyan, Sun Shuiyu, Ning Xunan, et al. Treatment and reuse of wastewater from a sulphide ore flotation plant. Techniques and Equipment for Environmental Pollution Control, 2002, 3(2): 67-70(in Chinese)
    [2] 郭恩彦. 臭氧-生物活性炭组合工艺深度处理循环养殖废水效果研究. 上海:上海海洋大学硕士学位论文, 2009 Guo Enyan. Study on effect of O3-BAC combined process for advanced treatment of RAS wastewater. Shanghai: Master Dissertation of Shanghai Ocean University (in Chinese)
    [3] 张文启,饶品华,陈思浩,等. 焦化废水臭氧-生物活性炭的深度处理技术. 上海工程技术大学学报, 2011, 25(2): 101-103 Zhang Wenqi, Rao Pinhua, Chen Sihao, et al. Advancing treatment technology of coking wastewater by O3-BAC process. Journal of Shanghai University of Engineering Science, 2011,25(2): 101-103(in Chinese)
    [4] 李月兰,谭五丰. 高级氧化技术处理工业废水的研究进展. 广东化工, 2010, 37(7): 70-71
    [5] 陈洪斌,庞小东,高廷耀,等. 炼油厂污水回用处理研究. 环境科学学报, 2002, 22(5): 570-575 Chen Hongbin, Pang Xiaodong, Gao Tigyao, et al. Study on reuse treatment of oil refinery wastewater. Acta Science Circumstantiae, 2002, 22(5): 570-575( in Chinese)
    [6] 薛向东,金奇庭. 水处理中的高级氧化技术. 环境保护, 2001, (6): 13-15 Xue Xiangdong, Jin Qiting. Advanced oxidation technology for water treatment. Environmental Protection, 2001, (6): 13-15(in Chinese)
    [7] 王爱平. 活性炭对溶液中重金属的吸附研究. 昆明:昆明理工大学硕士学位论文, 2003 Wang Aiping. Study on adsorption of activated carbon in the heavy metal ions solution. Kunming: Master Dissertation of Kunming University of Science and Technology (in Chinese)
    [8] Claudio D. I. Biological treatment and ozone oxidation: Integration or coupling? Bioresource Technology, 2012, 106: 63-68
    [9] Nieto J. C., Jiménez-Colmenero F., Peláez M. C. Effect of ozone on bacterial flora in poultry during refrigerated storage. International Journal of Refrigeration, 1984, 7(6): 389-392
    [10] Takeuchi Y., Mochidzuki K., Matsunobu N., et al. Removal of organic substances from water by ozone treatment followed by biological activated carbon treatment. Water Science and Technology, 1997, 35(7): 171-178
    [11] 赵东风,刘海波,陆晓华. 炼化废水处理回用臭氧生物炭工艺中试研究. 工业水处理, 2003, 23(6): 39-41 Zhao Dongfeng, Liu Haibo, Lu Xiaohua. Pilot study of oil refining wastewater reuse by ozone-biological activated carbon process. Industrial Water Treatment, 2003,23(6):39-41(in Chinese)
    [12] 周大佐,邱凌峰. 臭氧-生物活性炭技术在微污染水处理中的应用. 重庆环境科学, 1998, 20(2): 41-43 Zhou Dazuo, Qiu Lingfeng. Application of Ozone-BAC technique in drinking water prcess. Chongqing Environmental Science, 1998,20(2): 41-43(in Chinese)
    [13] 简丽,张彭义,毕海. 臭氧光催化降解地下水中天然有机物的研究. 环境污染治理技术与设备, 2006, 7(8): 18-22 Jian Li, Zhang Pengyi, Bi Hai. Degradation of natural organic matter in groundwater by O3/TiO2/UV. Techniques and Equipment for Environmental Pollution Control, 2006,7(8): 18-22(in Chinese)
    [14] 吴强. 臭氧-生物活性炭工艺在大型饮用净水厂中的应用研究. 广州:华南理工大学硕士学位论文, 2006 Wu Qiang. Applied research of O3-BAC process in large-scale drinking water treatment plant. Guangzhou: Master Dissertation of South China University of Technology (in Chinese)
    [15] 陈妍清. 臭氧生物活性炭工艺去除污染物的特性研究. 南京:东南大学硕士学位论文, 2006 Chen Yanqing. Special research on the removal pollutant by ozonation and BAC filtration. Nanjing: Master Dissertation of Southeast University (in Chinese)
    [16] Xu B., Gao N., Sun X., et al. Characteristics of organic material in Huangpu River and treatability with the O3-BAC process. Separation and Purification Technology, 2007, 57(2): 348-355
    [17] 李冬梅,谢晖,李炳,等. 氨氮浓度对活性炭深度处理工艺选择的影响. 环境工程学报, 2007, 1(6): 65-68 Li Dongmei, Xie Hui, Li Bing, et al. Effects of ammonia nitrogen concentration on the selection of advanced treatment process with activated carbon. Chinese Journal of Environmental Engineering, 2007, 1(6): 65-68(in Chinese)
    [18] 姚宏,马放,田盛,等. 臭氧-固定化生物活性炭滤池深度处理石化废水的试验研究. 环境污染治理技术与设备, 2005, 6(5): 83-86 Yao Hong, Ma Fang, Tian Sheng, et al. The pilot-plant study on advanced treatment of petrochemical wastewater by ozone-immobilized biological activated carbon filter. Techniques and Equipment for Enviromental Pollution Control, 2005, 6(5): 83-86(in Chinese)
    [19] 甘莉,蒋以元,张昱,等. 直接过滤-臭氧-生物活性炭工艺用于城市污水二级处理出水深度处理的研究. 环境污染治理技术与设备, 2006, 7(10): 65-68 Gan Li, Jiang Yiyuan, Zhang Yu, et al. Advanced treatment of secondary effluent of WWPT by sand filter-ozone-biological activated carbon. Techniques and Equipment for Environmental Pollution Control, 2006, 7(10): 65-68(in Chinese)
    [20] 姜元臻,李瑞华,任源,等. 活性炭纤维上4-氯酚及焦化废水尾水的O3催化氧化降解实验研究. 环境工程学报, 2008, 2(7): 896-901 Jiang Yuanzhen, Li Ruihua, Ren Yuan, et al. Study on catalytic ozonation of 4-chlorophenoland coking wastewater on activated carbon fiber. Chinese Journal of Environmental Engineering, 2008, 2(7):896-901(in Chinese)
    [21] 欧阳魁. 臭氧法处理硫化矿选矿废水的新工艺及其机理研究. 长沙:中南大学硕士学位论文, 2009 Ouyang Kui. Study on new technology's treatment and mechanism of processing wastewater use ozone treatment. Changsha: Master Dissertation of Central South University (in Chinese)
    [22] 国家环境保护总局. 水和废水监测分析方法(第4版). 中国环境科学出版社, 2002
    [23] EPA. Standard methods for the examination of water and wastewater. Washington,DC:American Public Health Association, 1989
    [24] 鲁军,刘勇弟,魏兴义. 臭氧氧化法处理氰化亚铜废水的研究. 长沙:全国臭氧技术应用研讨与产品展示会,2002
    [25] 王长友,祁金兵,张玲玲,等. 臭氧氧化法处理金矿氰化废水的试验研究. 辽宁化工, 2004, 33(8): 446-447
