魏健, 宋永会, 赵乐, 田智勇, 徐东耀. 响应面法优化Fenton预处理干法腈纶废水[J]. 环境工程学报, 2013, 7(5): 1695-1701.
引用本文: 魏健, 宋永会, 赵乐, 田智勇, 徐东耀. 响应面法优化Fenton预处理干法腈纶废水[J]. 环境工程学报, 2013, 7(5): 1695-1701.
shu
Wei Jian, Song Yonghui, Zhao Le, Tian Zhiyong, Xu Dongyao. Optimization of Fenton process for pretreatment of dry-spun acrylic fiber wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1695-1701.
Citation: Wei Jian, Song Yonghui, Zhao Le, Tian Zhiyong, Xu Dongyao. Optimization of Fenton process for pretreatment of dry-spun acrylic fiber wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1695-1701.
shu

响应面法优化Fenton预处理干法腈纶废水

  • 1.

    北京师范大学水科学研究院,北京 100875

  • 2.

    中国环境科学研究院城市水环境科技创新基地,北京 100012

  • 3.

    中国矿业大学(北京)化学与环境工程学院,北京 100083

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2012ZX07202-002)

    中法国际科技合作项目(2010DFB90590)

  • 中图分类号: X703.1

Optimization of Fenton process for pretreatment of dry-spun acrylic fiber wastewater with response surface methodology

  • 1.

    College of Water Science, Beijing Normal University, Beijing 100875, China

  • 2.

    Department of Urban Water Environmental Research, Chinese Research Academy of Environmental Sciences, Beijing 100012, China

  • 3.

    College of Chemical and Environmental Engineering, China University of Mining and Technology, Beijing 100083, China

  • Fund Project:

HTML全文

  • 摘要: 采用Fenton法预处理难降解干法腈纶废水,选取H2O2用量、Fe2+用量、初始pH和反应温度4个因素为变量,COD去除率为响应值进行中心组合设计。利用响应面法对实验结果进行分析,建立了以COD去除率为响应值的二次多项式模型并进行了显著性检验,分析了各因素单独及交互作用对COD去除率的影响,确定了最佳反应条件,并考察了最佳条件下处理前后废水可生化性和毒性变化。结果表明,所选取的4个因素影响COD去除率的主次顺序依次为:H2O2用量、Fe2+用量、初始pH和反应温度;在H2O2浓度为90.0 mmol/L、Fe2+浓度为23.9 mmol/L、初始pH值为3.4、温度为38.5℃的最佳条件下,COD去除率为53.8%,与模型预测值51.9%吻合度较高,偏差仅为3.66%;最佳条件下处理后废水可生化性显著提高,生物毒性明显降低,适宜于后续的生化处理。
    Abstract: The Fenton process was employed in the pretreatment of bio-refractory dry-spun acrylic fiber (DAF) wastewater. H2O2 dosage, Fe2+ dosage, initial pH and reaction temperature were selected as the variables and COD removal efficiency as the response in the central composite design (CCD). Response surface methodology (RSM) was used for the analysis of the experimental results based on CCD. A second-order polynomial regression equation was developed to describe the COD removal efficiency and was validated by significance test. The single and interactive effects of the operational parameters were investigated using response surface analysis and the optimum reaction conditions were determined. Furthermore, the biodegradability and toxicity of the raw and treated DAF wastewater were also analyzed. The results showed that the effect of factors on COD removal was in the order of H2O2 dosage > Fe2+ dosage > initial pH value > reaction temperature. Under the optimum reaction conditions (H2O2 dosage of 90.0 mmol/L, Fe2+ dosage of 23.9 mmol/L, initial pH value of 3.4 and reaction temperature of 38.5℃), the COD removal efficiency was 53.8%, which was highly consistent with value 51.9% predicted by the model equation, with a deviation of 3.66%. After Fenton pretreatment under the optimum reaction conditions, the biodegradability of wastewater was significantly improved and the toxicity largely decreased, which was suitable for biological treatment.
  • [1] 汪宏渭,孙在柏,孙国华.干法腈纶废水处理技术.化工环保,2005,25(2):128-131 Wang H. W., Sun Z. B., Sun G. H. Study on the treatment process for dry-spun polyacrylonitrile fiber wastewater. Environmental Protection of Chemical Industry, 2005, 25(2): 128-131 (in Chinese)
    [2] 杨崇臣,田智勇,宋永会,等.膜生物反应器(MBR)处理干法腈纶废水.环境科学研究,2010, 23(7): 912-917 Yang C. C., Tian Z. Y., Song Y. H., et al. Wastewater treatment of dry-spun acrylic fiber by membrane bioreactor. Research of Environmental Science, 2010, 23(7): 912-917 (in Chinese)
    [3] 赵朝成,陆晓华,刘海洪,等.腈纶废水生化处理研究.工业水处理,2004, 24(5): 42-45 Zhao C. C., Lu X. H., Liu H. H., et al. Study on the biological treatment of acrylic fiber wastewater. Industrial Water Treatment, 2004, 24(5): 42-45 (in Chinese)
    [4] Zhang C., Wang J., Zhou H., et al. Anodic treatment of acrylic fiber manufacturing wastewater with boron-doped diamond electrode: A statistical approach. Chemical Engineering Journal, 2010, 161(1-2): 93-98
    [5] Santos M. S. F., Alves A., Madeira L. M. Paraquat removal from water by oxidation with Fenton's reagent. Chemical Engineering Journal, 2011, 175(1): 279-290
    [6] Chu L., Wang J., Dong J., et al. Treatment of coking wastewater by an advanced Fenton oxidation process using iron power and hydrogen peroxide. Chemosphere, 2012, 86(4): 409-414
    [7] Wang H. Y., Hu Y. N., Cao G. P., et al. Degradation of propylene glycol wastewater by Fenton's reagent in a semi-continuous reactor. Chemical Engineering Journal, 2011, 170(1): 75-81
    [8] Popuri S. R., Chang C. Y., Xu J. A study on different addition approach of Fenton's reagent for DCOD removal ABS wastewater. Desalination, 2011, 277(1-3): 141-146
    [9] Prato-Garcia D., Buitrón G. Evaluation of three reagent dosing strategies in a photo-Fenton process for the decolorization of azo dye mixtures. Journal of Hazardous Materials, 2012, 217-218(1): 293-300
    [10] Sun J. H., Shi S. H., Lee Y. F., et al. Fenton oxidative decolorization of the azo dye Direct Blue 15 in aqueous solution. Chemical Engineering Journal, 2009, 155(3): 680-683
    [11] He P. J., Zhong Z., Zhang H., et al. PAEs and BPA removal in landfill leachate with Fenton process and its relationship with the DOM composition. Science of the Total Environment, 2009, 407(17): 4928-4933
    [12] Vedrenne M., Vasquez-Medrano R., Prato-Garcia D., et al. Characterization of detoxification of a mature landfill leachate using a combined coagulation-flocculation/photo Fenton treatment. Journal of Hazardous Materials, 2012, 205-206(1): 208-215
    [13] Mason R. L., Gunst R. F., Hess J. J. Statistical Design and Analysis of Experiments with Application to Engineering and Science. The United States of America: John Wiley and Sons Publication, 2003
    [14] 刘春明,董秀芹,张敏华.响应面法优化超临界水氧化降解喹啉废水.环境工程学报,2012,6(10):3569-3572 Liu C. M., Dong X. Q., Zhang M. H. Optimization of supercritical water oxidation of quinolone wastewater by response surface methodological analysis. Chinese Journal of Environmental Engineering, 2012, 6(10): 3569-3572 (in Chinese)
    [15] Bianco B., Michelis I. D., Vegliò F. Fenton treatment of complex industrial wastewater: Optimization of process conditions by surface response method. Journal of Hazardous Materials, 2011, 186(2-3): 1733-1738
    [16] Hermosilla D., Merayo N., Ordóez R., et al. Optimization of conventional Fenton and ultraviolet-assisted oxidation process for the treatment of reverse osmosis retentate from a paper mill. Waste Management, 2012, 32(6): 1236-1243
    [17] Cruz-González K., Torres-Lopez O., García-León A.M., et al. Optimization of electro-Fenton/BDD process for decolorization of a model azo dye wastewater by means of response surface methodology. Desalination, 2012, 286(1): 63-68
    [18] 国家环境保护总局.水和废水监测分析方法.(第4版). 北京:中国环境科学出版社, 2002
    [19] Martins R. C., Rossi A. F., Quinta-Ferreira R. M., et al. Fenton's oxidation process for phenolic wastewater remediation and biodegradability enhancement. Journal of Hazardous Materials, 2010, 180(1-3): 716-721
    [20] Kallel M., Belaid C., Mechichi T., et al. Removal of organic load and phenolic compounds from olive mill wastewater by Fenton oxidation with zero-valent iron. Chemical Engineering Journal, 2009, 150(2-3): 391-395
    [21] Lai B., Zhou Y. X., Qin H. K., et al. Pretreatment of wastewater from acrylonitrile-butadiene-styrene (ABS) resin manufacturing by microelectrolysis. Chemical Engineering Journal, 2012, 179(1): 1-7
