韩云平, 刘俊新, 郭雪松. 剪切应力对活性污泥絮体特征的影响[J]. 环境工程学报, 2013, 7(5): 1601-1606.
引用本文: 韩云平, 刘俊新, 郭雪松. 剪切应力对活性污泥絮体特征的影响[J]. 环境工程学报, 2013, 7(5): 1601-1606.
shu
Han Yunping, Liu Junxin, Guo Xuesong. Influence of shear stress on characteristics of activated sludge flocs[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1601-1606.
Citation: Han Yunping, Liu Junxin, Guo Xuesong. Influence of shear stress on characteristics of activated sludge flocs[J]. Chinese Journal of Environmental Engineering, 2013, 7(5): 1601-1606.
shu

剪切应力对活性污泥絮体特征的影响

  • 1.

    中国科学院生态环境研究中心,北京 100085

  • 基金项目:

    国家自然科学基金资助项目(51138009)

  • 中图分类号: X703.1

Influence of shear stress on characteristics of activated sludge flocs

  • 1.

    Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • Fund Project:

HTML全文

  • 摘要: 采用具有自动控制系统可周期性改变搅拌速度的生物反应器处理生活污水,研究了剪切应力周期变化对活性污泥絮体特征及功能菌群分布的影响。结果表明,在相同的运行条件下,运行初期的污泥形态不规则,结构疏松,其内部各功能菌群丰度差异较大,污泥絮体粒径受剪切应力影响较大,最大和最小剪切应力下污泥平均粒径相差30 μm;随着反应器运行时间的延长,活性污泥絮体的粒径减小;到达运行稳定期,污泥粒径较小,但结构紧实,最大和最小剪切应力下污泥平均粒径相差仅为6 μm,说明剪切应力对污泥粒径的影响减弱,其主要作用在于维持污泥絮体相对稳定的三维结构及相对平衡的功能菌群分布。此外,处理效果研究也表明,稳定的污泥结构有助于污染物去除效率的提高。
    Abstract: The characteristics of activated sludge and distribution of functional flora were studied in different shear stress and periods in the bioreactor of sewage treatment with automatic control system to change the stirring speed periodically. The results showed that,under the same operational conditions, the characteristics of initial activated sludge were irregular form, loose structure and widely different abundance of functional flora. The influence of shear stress on the sludge size was violent, and gap of mean size was 30 μm between maximum and minimum shear stress. Along with the bioreactor operation, the mean size of activated sludge decreased. In stable period, the size of sludge flocs was smaller, but its structure was tight. The gap of mean size was only 6 μm between maximum and minimum shear stress. Results showed that the shear stress played an important role in maintaining stable 3-D structure and relative mean distribution of functional flora in stable phase. Research of treatment effect also showed that stable characteristic of activated sludge floc helped to removal efficiency of pollutants.
  • [1] 王超, 郑晓英. 剪切应力对好氧颗粒污泥形态结构和微生物活性的影响机制研究.环境科学, 2008, 29(8): 2235-2241 Wang C., Zheng X. Y. Effect of shear stress on morphology, structure and microbial activity of aerobic granules. Environmental Science, 2008, 29(8): 2235-2241(in Chinese)
    [2] Wu J., Zhou H. M., Li H. Z. Impacts of hydrodynamic shear force on nucleation of flocculent sludge in anaerobic reactor. Water Research, 2009, 43(12): 3029-3036
    [3] Liu Y., Tay J. H. The essential role of hydrodynamic shear force in the formation of biofilm and granular sludge. Water Research, 2002, 36(7): 1653-1665
    [4] Liu Q. S., Liu Y., Tay J. H., et al. Responses of sludge flocs to shear strength. Process Biochemistry, 2005, 40(10): 3213-3217
    [5] Tay J. H., Liu Q. S., Liu Y. The effects of shear force on the formation, structure and metabolism of aerobic granules. Applied Microbiological and Biotechnology, 2002, 57(1): 227-233
    [6] 冯骞, 薛朝霞, 汪翙, 等. 水流剪切力对活性污泥特性影响的试验研究.河海大学学报(自然科学版), 2006, 34(4): 374-377 Feng Q., Xue Z. X., Wang H., et al. Experimental study on influence of hydrodynamic shear stress on characteristics of activated sludge. Journal of Hohai University (Natural Sciences), 2006, 34(4): 374-377(in Chinese)
    [7] Chung H.Y., Ju S.P., Lee D.J. Hydrodynamic drag force exerted on activated sludge floc at intermediate Reynolds number. Journal of Colloid and Interface Science, 2003, 263(2): 498-505
    [8] Jin B., Lant P. Flow regime, hydrodynamics, floc size distribution and sludge properties in activated sludge bubble column, air-lift and aerated stirred reactors. Chemical Engineering Science, 2004, 59(12): 2379-2388
    [9] 陈津端, 钟乐, 易诚, 等. 絮状污泥降解过程的动力致因分析.湖南科技大学学报(自然科学版), 2009, 24(2): 108-111 Chen J. D., Zhong L., Yi C., et al. Analysis of the dynamic factors in the degradation process of flocculent sludge. Journal of Hunan University of Science & Technology (Natural Science), 2009, 24(2): 108-111(in Chinese)
    [10] 刘永奇, 王国才, 周雪梅, 等. 变频调速技术在搅拌器中的优化应用.机械研究与应用, 2007, 20(5): 58-59 Liu Y. Q., Wang G. C., Zhou X.M., et al. Optimized application of frequency conversion velocity modulation technology in mixer. Mechanical Research & Application, 2007, 20(5): 58-59(in Chinese)
    [11] 王惠民, 赵振兴. 工程流体力学. 南京: 河海大学出版社,2005
    [12] Manz W., Amann R., Ludwig W., et al. Phylogenetic oligodeoxynucleotide probes for the major subclasses of proteobacteria-problems and solutions. Systematic and Applied Microbiology, 1992, 15(4): 593-600
    [13] Satoh H., Okabe S., Yamaguchi Y., et al. Evaluation of the impact of bioaugmentation and biostimulation by in situ hybridization and microelectrode. Water Research, 2003, 37(9): 2206-2216
    [14] 邓黛青, 李光明, 周仰原, 等. FISH荧光原位杂交技术在污水生物脱氮研究中的应用. 微生物学通报, 2006, 33(2): 132-136 Deng D. Q., Li G. M., Zhou Y. Y., et al. Application of fluorescence in situ hybridization in research on biological removal of nitrogen from wastewater. Microbiology China, 2006, 33(2): 132-136(in Chinese)
    [15] 郑雅楠, 滝川哲夫, 郭建华, 等. SBR 法常、低温下生活污水短程硝化的实现及特性. 中国环境科学, 2009, 29(9): 935-940 Zheng Y. N., Takigawa A., Guo J. H., et al. Partial nitrification via nitrite at ordinary and low temperatures in an SBR treating domestic wastewater. China Environmental Science, 2009, 29(9): 935-940(in Chinese)
    [16] 胡绍伟, 杨凤林, 刘思彤, 等. 膜曝气生物膜反应器同步硝化反硝化研究. 环境科学, 2009, 30(2): 416-420 Hu S. W., Yang F. L., Liu S. D., et al. Simultaneous nitrification and denitrification of membrane aerated biofilm reactor. Environmental Science, 2009, 30(2): 416-420(in Chinese)
    [17] 国家环境保护总局. 水和废水监测分析方法(第4版). 北京: 中国环境科学出版社,2002
