新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征

,  ,

downloadPDF

上一篇

下一篇

王佳佳, 马慧敏, 张田林. 新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征[J]. 环境工程学报, 2013, 7(4): 1378-1382.
引用本文: 王佳佳, 马慧敏, 张田林. 新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征[J]. 环境工程学报, 2013, 7(4): 1378-1382.
shu
Wang Jiajia, Ma Huimin, Zhang Tianlin. Synthesis of multifunctional chelating resin and its adsorption properties for Cd(II) in water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1378-1382.
Citation: Wang Jiajia, Ma Huimin, Zhang Tianlin. Synthesis of multifunctional chelating resin and its adsorption properties for Cd(II) in water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1378-1382.
shu

新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征

  • 1.

    中国矿业大学化工学院,徐州 221116

  • 2.

    淮海工学院化学工程学院,连云港 222005

  • 基金项目:

    江苏省高校自然科学研究重大资助项目(11KJA430008)

  • 中图分类号: X703.1

Synthesis of multifunctional chelating resin and its adsorption properties for Cd(II) in water

  • 1.

    School of Chemical Engineering & Technology, China University of Mining and Technology, Xuzhou 221116, China

  • 2.

    Institute of Chemical Engineering, Huaihai Institute of Technology, Lianyungang 222005, China

  • Fund Project:

摘要

  • 摘要: 研究了使用交联聚苯乙烯叔胺树脂为前驱体与5-氯甲基水杨醛经搅拌反应合成季铵盐型多功能螯合树脂及其对水中Cd(II)离子的吸附特征。结果表明,水杨醛单元成功地连接到树脂表面,其含量为1.89 mmol/g。通过浓度、pH值、时间等条件的变化对吸附性能进行研究,得到了25℃时Cd(II)的最佳吸附条件:Cd(II)离子浓度为600 μg/L,pH=6.0,吸附达平衡的时间约为4 min,树脂的最大吸附量为200.0 μg/g,吸附符合Langmuir等温式。pH=6.0时,对重金属离子Zn(II)、Cu(II)、Ni(II)、Hg(II)、Pb(II)和Cr(Ⅲ) 吸附能力强但选择性较差。
    Abstract: Multifunctional chelating resin was prepared via the reaction between cross-linked polystyrene-dimethylamine resin and 5-cholromethylsalicylaldehyde under stirring conditions. Adsorption properties for Cd(II) were described. Results showed that salicylaldehyde groups were successfully grafted on resin surface and the content of salicylaldehyde groups in the grafted resin was 1.89 mmol/g. The adsorptivity was discussed by the change of temperature, pH and time. The best adsorption conditions at 25℃ were obtained: the concentration of Cd(II) was 600 μg/L, pH=6.0,the equilibrium adsorption time was 4min, the maximum adsorption capacity was 200.0 μg/g and the adsorption fit best with the Langmuir model. It had a good adsorption properties for Zn(II), Cu(II), Ni(II), Hg(II), Pb(II) and Cr(III), but a poor adsorption selectivity at pH=6.0.
  • [1] Lebeau T., Bagot D., Jieziequel K., et al. Cadmium biosorption by free and immobilised microorganisms cultivated in a liquid soil extract medium: Effects of Cd, pH and techniques of culture. Sci. Total Environ., 2002,291(1-3):73-83
    [2] Salim R., Al-Subu M.M., Sahrhage E. Uptake of cadmium from water by beech leaves. J. Environ. Sci. Health A, 1992,27(3):603-627
    [3] 张玉梅. 含镉废水处理的试验研究. 环境工程, 1995,13(1):15-20 Zhang Y.M. Study on the treatment of cadmium containing wastewater. Environmental Engineering, 1995,13(1):15-20(in Chinese)
    [4] Madhava Rao M., Rameshb A., Purna Chandra Raoa G., et al. Removal of copper and cadmium from the aqueous solutions by activatedcarbon derived from Ceiba pentandra hulls. Journal of Hazardous Materials B, 2006,129(1-3):123-129
    [5] 张廷安, 杨欢, 赵乃仁,等. 用壳聚糖絮凝剂处理含镉(II)废水. 东北大学学报(自然科学版), 2001,22(5):547-549 Zhang Y. A., Yang H., Zhao N. R., et al. A study of the removal of Cd(II) in wastewater with chitosan as flocculation. Journal of Northeastern University (Natural Science), 2001,22(5):547-549(in Chinese)
    [6] 郑礼胜, 王士龙, 张虹,等. 用矿渣处理含镉水的探索试验. 化工环保, 1996,16(4):244-246
    [7] Majeda A. M. K., Yahya S. A., Wendy A. M. M. Remediation of wastewater containing heavy metalsusing raw and modified diatomite. Chemical Engineering Journal, 2004,99(2):177-184
    [8] 张秀英. 沸石的改性处理及吸附性能研究. 化工矿物与加工, 2006,35(12):11-12,16 Zhang X. Y. Study on modification of zeolite and its adsorption properties. Industrial Minerals and Processing, 2006,35(12):11-12,16(in Chinese)
    [9] 杨胜科, 费晓华. 海泡石处理含镉废水技术研究. 化工矿物与加工,2004,33(9):16-17,20 Yang S. K., Fei X. H. Study on effect factors of treating cadmium with meerschaum. Industrial Minerals and Processing, 2004,33(9):16-17,20(in Chinese)
    [10] 吕景才,赵元凤, 赵睿. 麦饭石对海水及水溶液中铜、锌、镉的吸附规律.中国水产科学, 2000,7(1):87-90 Lv J. C., Zhao Y. F., Zhao R. Absorption of copper, zinc and cadmium on MF(Granite) in sea water and aqueous solution. Journal of Fishery Sciences of China, 2000,7(1):87-90(in Chinese)
    [11] Lvarez-ayuso E. A., Garcia-sa Nchez A. Removal of heavy metals from wastewaters by naturaland Na-exchanged bentonites. Clays and Clay Minerals, 2003,51(5):475-480
    [12] 胥焕岩,彭明生,刘羽,等. 一种新型环境矿物材料在废水治理中的应用研究—硅质磷块岩吸附水溶液中镉离子的研究. 环境污染治理技术与设备, 2003,4(5):15-18 Xu H.Y., Peng M. S., Liu Y., et al. Application of a new environmental mineralogical material in wastewater treatment—Study on the sorption of aqueous cadmium ion with siliceous phosphorite. Techniques and Equipment for Environmental Pollution Control, 2003,4(5):15-18(in Chinese)
    [13] Chen Q. Bis(4-bromo-2-formylphenolato-κ2O,O’)zinc(II).Acta Cryst. E., 2006,62(1):56-57
    [14] Yu Q., Li C.Y., Yang X.E., et al. Aquabis (1-formyl-2-naphtholato-κ2O,O’) copper(II). Acta Cryst. E., 2006,62(2):391-393
    [15] Papadopoulos C. D., Lalia Kantouri M., Jaud J., et al. Substitution effect on new Co(II) addition compounds with salicylaldehydes and the nitrogenous bases phen or neoc: Crystal and molecular structures of , and . Inorg. Chim. Acta, 2007,360(11):3581-3589
    [16] Zhang S. H., Li G. Z., Feng X. Z., et al. Bis (4,6-dibromo-2-formylphenolato-κ2 O, O’) bis(dimethyl sulfoxide-κO) nickel(II). Acta Cryst. E., 2007,63(5):1319-1320
    [17] Prasad R. N., Sharma K. M., Agrawal M. Mixed ligand complexes of alkaline earth metals: Part XII. Mg(II), Ca(II), Sr(II) and Ba(II) complexes with 5-chlorosalicylaldehyde and salicylaldehyde or hydroxyaromatic ketones. J. Serb. Chem. Soc., 2002,67(4):229-234
    [18] Prince A. A., Myron W., Xiu R.B. The fast removal of low concentration of cadmium(II) from aqueous media by chelating polymers with salicylaldehyde units. Journal of Hazardous Materials, 2009,170(1):22-26
    [19] Kamogawa H., Sugiyama K., Hanawa H., et al. Syntheses of polymerizable phenol derivatives having a carbonyl-containing group as a ring substituent. J. Polym. Sci.: Polym. Chem. Ed., 1976,14(2):511-514
    [20] Amoyaw P., Ingram C., Hsu F. L., et al. Poly for rapid removal of low concentrations of Pb(II). J. Appl. Polym. Sci., 2009,113(4):2096-2102
    [21] 张田林, 王佳佳, 倪镜涛. 5-氯甲基水杨醛的制备方法: CN102180779A, 2011
    [22] Langmuir I. The constitution and fundamental properties of solids and liquids. Part I. Solids. J. Am. Chem. Soc., 1916,38(11):2221-2295
    [23] Freundlich H. M. F. Vber die Adsorption in Lösungen. Z. Phys. Chem., 1906,57:385-471
    [24] Denizil A., Senel S., Alsancak G., et al. Mercury removal from synthetic solutions using poly(2-hydroxyethylmethacrylate) gel beads modified with poly(ethyleneimine). React. Funct. Polym., 2003,55(2):121-130
    [25] Wang C. C., Chang C. Y., Chen C. Y. Study on metal ion adsorption of bifunctional chelating/ion-exchange resins. Macromol. Chem. Phys., 2001,202(6):882-890
    [26] Reed B. E., Matsumoto M. R. Modeling cadmium adsorption by activated carbon using the Langmuir and Freundlich lsotherm expressions. Sep. Sci. Technol., 1993,28(13-14):2179-2195
    [27] Bahrami S., Bassi A.S., Yanful E. Polyethyleneimine-containing sol-gels as novel sorbents for the removal of cadmium from aqueous solutions. Can. J. Chem. Eng., 1999,77(5):931-935
    [28] Egawa H., Nakayama M., Nonaka T., et al. Recovery of uranium from sea water. IV. Influence of crosslinking reagent of the uranium adsorption of macroreticular chelating resin containing amidoxime groups. J. Appl. Polym. Sci., 1987,33(6):1993-2005
    [29] Delacour M. L., Gailliez E., Bacquet M., et al. Poly(ethylenimine) coated onto silica gels: Adsorption capacity toward lead and mercury. J. Appl. Polym. Sci., 1999,73(6):899-906
    [30] Kolthoff M. Treatise on Analytical Chemistry. New York: John Wiley, 1979.129
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2418
  • HTML全文浏览数:  1371
  • PDF下载数:  1655
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-04-17
  • 刊出日期:  2013-04-09
王佳佳, 马慧敏, 张田林. 新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征[J]. 环境工程学报, 2013, 7(4): 1378-1382.
引用本文: 王佳佳, 马慧敏, 张田林. 新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征[J]. 环境工程学报, 2013, 7(4): 1378-1382.
shu
Wang Jiajia, Ma Huimin, Zhang Tianlin. Synthesis of multifunctional chelating resin and its adsorption properties for Cd(II) in water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1378-1382.
Citation: Wang Jiajia, Ma Huimin, Zhang Tianlin. Synthesis of multifunctional chelating resin and its adsorption properties for Cd(II) in water[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1378-1382.
shu

新型多功能螯合树脂的合成及对水中Cd(II)离子的吸附特征

  • 1.  中国矿业大学化工学院,徐州 221116
  • 2.  淮海工学院化学工程学院,连云港 222005
  • 收稿日期:  2012-04-17
基金项目:

江苏省高校自然科学研究重大资助项目(11KJA430008)

摘要: 研究了使用交联聚苯乙烯叔胺树脂为前驱体与5-氯甲基水杨醛经搅拌反应合成季铵盐型多功能螯合树脂及其对水中Cd(II)离子的吸附特征。结果表明,水杨醛单元成功地连接到树脂表面,其含量为1.89 mmol/g。通过浓度、pH值、时间等条件的变化对吸附性能进行研究,得到了25℃时Cd(II)的最佳吸附条件:Cd(II)离子浓度为600 μg/L,pH=6.0,吸附达平衡的时间约为4 min,树脂的最大吸附量为200.0 μg/g,吸附符合Langmuir等温式。pH=6.0时,对重金属离子Zn(II)、Cu(II)、Ni(II)、Hg(II)、Pb(II)和Cr(Ⅲ) 吸附能力强但选择性较差。
