微波辅助疏水膜的清洗

,  ,  ,

downloadPDF

上一篇

下一篇

尹子飞, 王军, 纪仲光, 侯得印. 微波辅助疏水膜的清洗[J]. 环境工程学报, 2013, 7(4): 1251-1255.
引用本文: 尹子飞, 王军, 纪仲光, 侯得印. 微波辅助疏水膜的清洗[J]. 环境工程学报, 2013, 7(4): 1251-1255.
shu
Yin Zifei, Wang Jun, Ji Zhongguang, Hou Deyin. Microwave assisted cleaning of hydrophobic membrane[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1251-1255.
Citation: Yin Zifei, Wang Jun, Ji Zhongguang, Hou Deyin. Microwave assisted cleaning of hydrophobic membrane[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1251-1255.
shu

微波辅助疏水膜的清洗

  • 1.

    中国矿业大学(北京)化学与环境工程学院,北京 100083

  • 2.

    中国科学院生态环境研究中心环境水质学国家重点实验室,北京 100085

  • 基金项目:

    国家科技部科研院所技术开发研究专项资金(2010EG111021)

    北京市财政资金资助项目(PXM2012_178203_000001)

    国家高技术研究发展计划(863)项目(2009AA063901)

  • 中图分类号: X712

Microwave assisted cleaning of hydrophobic membrane

  • 1.

    School of Chemical & Environmental Engineering, China University of Mining & Technology(Beijing), Beijing 100083,China

  • 2.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • Fund Project:

摘要

  • 摘要: 针对膜蒸馏过程中膜表面常见的CaSO4垢和腐殖酸混合垢,对微波强化疏水膜清洗的效果进行了研究。结果表明,对于膜表面的CaSO4垢,微波辅助清洗效率高于常规清洗,且在清洗液的温度和流速较低时,微波的强化清洗效果更为明显;对于膜表面的腐殖酸混合垢,微波辅助清洗后的初始通量恢复率为88.4%,比常规清洗高出10.8%,同时可以相对缓解疏水膜的亲水化。
    Abstract: Common pollutants of CaSO4 and humic acid on membrane surface in membrane distillation(MD) process were adopted to investigate the effect of microwave enhanced cleaning of hydrophobic membrane. The results show that for CaSO4 sediment on the surface of membrane, the efficiency of microwave assisted cleaning is higher than that of conventional cleaning, and the microwave enhancing effect is more obvious when the temperature and flow velocity of cleaning fluid are lower. As for humic acid sediment on the membrane surface, the initial flux recovery ratio is 88.4% through microwave assisted cleaning, which is 10.8% higher than that of conventional cleaning. And microwave assisted cleaning can alleviate hydrophilization relatively at the same time.
  • [1] 吴庸烈. 膜蒸馏技术及其应用进展.膜科学与术,2003,23(4):67-79,92 Wu Yonglie.Advance of membrane distillation technology and the application. Membrane Science and Technology, 2003,23(4):67-79,92(in Chinese)
    [2] 刘忠洲,续曙光,李锁定.微滤、超滤过程中的膜污染与清洗.水处理技术,1997,23(4):187-193 Liu Zhongzhou, Xu Shuguang, Li Suoding.membrane fouling and cleaning in UF and MF.Technology of Water Treatment, 1997,23(4):187-193(in Chinese)
    [3] 张国俊,刘忠洲.膜过程中膜清洗技术研究进展.水处理技术,2003,29(4):187-190 Zhang Guojun, Liu Zhongzhou. Progress in membrane cleaning techniques. Technology of Water Treatment, 2003,29(4):187-190(in Chinese)
    [4] 赵平,赵星洁,王爱兵,等.膜的化学清洗.河北化工,2005,(1):15-16,34 Zhao Ping, Zhao Xingjie,Wang Aibing,et al.Chemical cleaning of membrane.Hebei Chemical Industry, 2005,(1):15-16,34(in Chinese)
    [5] 孙洪贵,夏海平,蓝伟光.分离膜材料的污染与清洗.功能材料,2002,33(1):26-28,32 Sun Honggui, Xia Haiping, Lan Weiguang.Fouling and cleaning in membrane. Functional Materials, 2002,33(1):26-28,32(in Chinese)
    [6] Li J. X., Sanderson R. D., Jacobs E. P. Ultrasonic cleaning of nylon microfiltration membranes fouled by kraft paper mill effluent. Journal of Membrane Science, 2002,205(1-2):247-257
    [7] Chai X. J., Kobayashi T., Fujii N.Ultrasound-associated cleaning of polymeric membranes for water treatment. Separation and Purification Technology, 1999,15(2):139-146
    [8] Kim C. G.,Yoon T. I., Lee M. J. Characterization and control of foulants occurring from RO disc-tube-type, membrane treating, fluorine manufacturing, process wastewater.Desalination,2002,151(3):283-292
    [9] 杨俊红,孙明迪,邸倩倩,等.微波辅助对超滤膜清洗效果的影响. 中国工程热物理学会学术会议论文,郑州,2008 Yang Junhong, Sun Mingdi, Di Qianqian, et al.Effect of microwave assisted cleaning of ultrafiltration membrane. Academic Conference Papers of the Chinese Society of Engineering Thermophysics, Zhengzhou, 2008(in Chinese)
    [10] Masselin I., Chasseray X., Durand-Bourlier L., et al. Effect of sonication on polymeric membranes. Journal of Membrane Science, 2001,181(2):213-220
    [11] 张国俊,刘忠洲.超滤膜的超声波助清洗研究.环境科学,2003,24(6):130-134 Zhang Guojun, Liu Zhongzhou. Study on assistant cleaning of ultrasound for the ultrafiltration membrane. Environmental Science, 2003,24(6):130-134(in Chinese)
    [12] 王晓丽,高博,傅学起.超声波处理对微滤膜损伤的影响.膜科学与技术,2005,25(6):7-11 Wang Xiaoli, Gao Bo, Fu Xueqi.Study on the damage of polymeric microfiltration membrane with ultrasonic treatment. Membrane Science and Technology, 2005,25(6):7-11(in Chinese)
    [13] Chai X. J., Kobayashi T., Fujii N.Ultrasound effect on cross-flow filtration of Polyacrylonitrile ultrafiltration membranes. Journal of Membrane Science, 1988,148(1):129-135
    [14] 纪仲光,王军,侯得印,等.微波辅助真空膜蒸馏试验研究.第四届中国膜科学与技术报告会论文集,北京,2010.500-505 Ji Zhongguang, Wang Jun, Hou Deyin, et al.Experimental study on microwave assisted vacuum membrane distillation. Academic Conference Papers of the Fourth Chinese Membrane Science and Technology Conference, Beijing, 2010.500-505(in Chinese)
    [15] 高海瑞,王军,王永红,等.天然有机物及无机盐对膜蒸馏过程的影响.中国给水排水,2009,25(21):33-36,40 Gao Hairui, Wang Jun, Wang Yonghong, et al.Effects of natural organic matters and inorganic salts on membrane distillation process. China Water & Wastewater, 2009,25(21):33-36,40(in Chinese)
    [16] Srisurichan S., Jiraratananon R., Fane A. G.Humic acid fouling in the membrane distillation process. Desalination, 2005,174(1):63-72
