常温低基质厌氧氨氧化反应器启动及其稳定性

,  ,  ,  ,

downloadPDF

上一篇

下一篇

鲍林林, 赵建国, 李晓凯, 李冬, 张杰. 常温低基质厌氧氨氧化反应器启动及其稳定性[J]. 环境工程学报, 2013, 7(3): 981-986.
引用本文: 鲍林林, 赵建国, 李晓凯, 李冬, 张杰. 常温低基质厌氧氨氧化反应器启动及其稳定性[J]. 环境工程学报, 2013, 7(3): 981-986.
shu
Bao Linlin, Zhao Jianguo, Li Xiaokai, Li Dong, Zhang Jie. Start-up and stability of Anammox bioreactor at normal temperature and low substrate concentration[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 981-986.
Citation: Bao Linlin, Zhao Jianguo, Li Xiaokai, Li Dong, Zhang Jie. Start-up and stability of Anammox bioreactor at normal temperature and low substrate concentration[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 981-986.
shu

常温低基质厌氧氨氧化反应器启动及其稳定性

  • 1.

    河南师范大学环境学院,黄淮水环境与污染防治教育部重点实验室,河南省环境污染 控制重点实验室,新乡 453007

  • 2.

    哈尔滨工业大学市政环境工程学院,哈尔滨 150090

  • 基金项目:

    河南省重大公益性科研项目(081100910300)

    河南省基础与前沿技术研究计划项目(102300410195,102300410197)

  • 中图分类号: X703

Start-up and stability of Anammox bioreactor at normal temperature and low substrate concentration

  • 1.

    Henan Key Laboratory of Environmental Pollution Control, Key Laboratory for Yellow River and Huaihe River Water Environment and Pollution Control, Ministry of Education, School of Environment, Henan Normal University, Xinxiang 453007, China

  • 2.

    School of Municipal and Environmental Engineering, Harbin Institute of Technology, Harbin 150090, China

  • Fund Project:

摘要

  • 摘要: 以上向流生物滤池为反应器,以实验室内氧化沟回流污泥为接种污泥,采用先培育好氧生物膜,后转为厌氧环境培育厌氧氨氧化生物膜的方式,成功实现了常温低基质浓度下厌氧氨氧化反应器的启动。控制反应器进水pH为7.50~7.80,NH4+-N为30~40 mg/L,NO2--N为35~50 mg/L,温度为20~25℃。224 d以后,反应器启动成功。在稳定运行阶段,出水亚硝氮和氨氮的平均浓度分别为1.4 mg/L和4.6 mg/L,平均去除率分别为95.3%和90.1%,去除比例为1~1.8∶1,主要集中在1.4~1.5∶1,亚硝氮和氨氮去除的容积负荷分别为104.2 mg/(L·d)和146.0 mg/(L·d)。
    Abstract: In this study, lab-scale up-flow biofilter reactor fed with the oxidation ditch backflow sludge was used to start-up the anaerobic ammonium oxidation (Anammox) process under normal temperature and low substrate concentration. Firstly, aerobic nitration biofilm was cultivated, and then Anammox biofilm was cultivated under anaerobic condition. The influent pH of 7.50~7.80, NH4+-N of 30~40 mg/L, NO2--N of 35~50 mg/L and temperature of 20~25℃ were controlled in this study. After 224 days of operation, the Anammox reactor was started up successfully. In the stable operation stage, the average concentration of effluent NO2--N and NH4+-N were 1.4 mg/L and 4.6 mg/L, respectively, the removal rate of NO2--N and NH4+-N were 95.3% and 90.1%, respectively. The removal proportion of NO2--N/NH4+-N was 1~1.8∶1 and the main focused on 1.4~1.5∶1. The removal volume loading rate of NO2--N and NH4+-N were 104.2 mg/(L·d) and 146.0 mg/(L·d), respectively.
  • [1] Mulder A., Van de Graaf A. A., Robertson L. A., et al. Anaerobic ammonium oxidation discovered in a denitrifying fluidized bed reactor. FEMS Microbiology Ecology, 1995, 16(3): 177-183
    [2] Van de Graaf, Mulder A., de Bruijin P. Autotrophic growth of anaerobic ammonium oxidation microorganism in a fluidized bed reactor. Microbiology, 1996, 142(8): 2187-2196
    [3] 沈平,左剑恶,杨洋.接种不同污泥的厌氧氨氧化反应器的启动和运行.中国沼气, 2004, 22(3):3-7 Sheng Ping,Zuo Jiane,Yang Yang.A study on start-up and operation of anaerobic ammonia oxidation reactors inoculated with different seed sludge. China Biogas, 2004, 22(3):3-7(in Chinese)
    [4] 葛林燕, 黄勇, 袁怡. 厌氧氨氧化反应器的启动运行分析.环境污染与防治, 2008, 30(5): 83-87 Ge Linyan,Huang Yong,Yuan Yi.Literature review of start-up and performance of ANAMMOX bioreactors. Environmental Pollution & Control, 2008, 30(5): 83-87(in Chinese)
    [5] 唐崇俭, 郑平, 陈建伟等. 不同接种物启动Anammox反应器的性能研究. 中国环境科学, 2008, 28(8): 683-688 Tang Chongjian,Zheng Ping,Chen Jianwei,et al.Performance of Anammox bioreactors started up with different seeding sludges. China Environmental Science, 2008, 28(8): 683-688(in Chinese)
    [6] Broda E. Two kinds of lithotrphs missing in nature. Journal of Basic Microbiology, 1977, 17(6): 491-493
    [7] Wouter R. L., van der Star, Wiebe R.Abma, et al. Startup of reactors for anoxic ammonium oxidation: Experiences from the first full-scale anammox reactor in Rotterdam. Water Research, 2007, 41(18): 4149-4163
    [8] U. van Dongen, Jetten M. S. M., C. M. van Loosdrecht. The SHARON-ANAMMOX process for treatment of ammonium rich wastewater. Water Science and Technology, 2001, 44(1): 153-160
    [9] Furukawa K., Tokitoh H., Lieu P. K. Single-stage nitrogen removal using anammox and partial nitritation(SNAP) for treatment of synthetic landfill leachate. Jpn. J. Water Treat. Biol., 2005, 41(2): 103-112
    [10] 郑平, 徐向阳, 胡宝兰. 新型生物脱氮理论与技术. 北京:科学出版社,2004
    [11] Strous M., Heijnen J. J., Kuenen J. G., et al. The sequencing batch Reactor as a power tool for the study of slowly growing anaerobic ammonium-oxidizing microorganisms. Appl. Microbiol. Biotechnol., 1998, 50(5): 589-596
    [12] Abma W. R., Schutltz C. E., Mulder J. W. Full scale granular sludge ANAMMOX Process. Water Sci. Technol., 2007, 55(8/9): 27-33
    [13] 许玫英, 方卫, 张丽娟, 等. 生物脱氮新技术在垃圾渗滤液工程化处理中的应用.环境科学, 2007, 28(3): 607-612 Xu Meiying, Fang Wei, Zhang Lijuan, et al. Application of new biological nitrogen removal technologies in full-scale treatment of landfill leachate. Environmental Science, 2007, 28(3): 607-612(in Chinese)
    [14] 张鸿郭, 周少奇. 垃圾渗滤混合液启动ANAMMOX反应器研究.工业安全与环保, 2006, 32(5): 7-9 Zhang Hongguo, Zhou Shaoqi. Study on start-up of ANAMMOX bioreactor using mixture of leachate. Industrial Safety and Environmental Protection, 2006, 32(5): 7-9(in Chinese)
    [15] 张树德, 刘欣, 郑志军, 等. 低基质质量浓度条件下ANAMMOX生物滤池脱氮效果研究.北京工业大学学报, 2009, 35(4): 504-508 Zhang Shude, Liu Xin, Zheng Zhijun,et al. Nitrogen removal efficiency of ANAMMOX biofilter at low substrate concentration. Journal of Beijing University of Technology, 2009, 35(4): 504-508(in Chinese)
    [16] 陈永, 李捷, 张树德, 等. 温度对ANAMMOX滤池的影响. 重庆大学学报(自然科学版), 2007, 30(7): 92-95 Chen Yong,Li Jie,Zhang Shude,et al.Effects of Temperature on the Performance of ANAMMOX Biofilter. Journal of Chongqing University (Natural Science), 2007, 30(7): 92-95(in Chinese)
    [17] 国家环境保护总局.水和废水监测分析方法(第4版). 北京: 中国科学出版社, 2002
    [18] Jin Rencun, Zheng Ping, Hu Anhui, et al. Performance comparison of two anammox reactor:SBR and UBF. Chemical Engineering Joural, 2008, 138(1-3): 224-230
    [19] Wang Tao, Zhang Hanmin, Yang Fenglin, et al. Start-up of the Anammox process from the conventional activated sludge in a membrane bioreactor. Bioresource Technology, 2009, 100(9): 2501-2506
    [20] 唐崇俭,郑平,金仁村,等. Anammox反应器运行稳定性及其机理研究. 四川大学学报(工程科学版), 2009, 41(2): 113-119 Tang Chongjian, Zheng Ping, Jin Rencun, et al. Stability and mechanism of anammox bioreactors. Journal of Sichuan University (Engineering Science), 2009, 41(2): 113-119(in Chinese)
    [21] Christian F., Marc B., Philipp H. Biological treatment of ammonium-rich wastewater by partial nitritation and subsequent anaerobic ammonium oxidation(anammox) in a pilot plant. Journal of Biotechnology, 2002, 99(3): 295-306
    [22] Strous M., Van Gerven, Kuenen J. G. Effect of aerobic and microaerobic conditions on anaerobic ammonium-oxidizing(anammox) sludge. Appl. Environ. Microbial., 1997, 63(6): 2446-2448
    [23] Strous M., Kuenen J. G., Jetten M. S. M. Key physiology of anaerobic ammonium oxidation. Appl. Environ. Microbial., 1999, 65(7): 3248-3250
    [24] Nutchanat Chamchoi, Suwanchai Nitisoravut. Anammox enrichment from different conventional sludges. Chemosphere, 2007, 66(11): 2225-2232
    [25] Sen Qiao, Yuki Kawakubo, Yingjun Cheng, et al. Identification of bacteria coexisting with anammox bacteria in an upflow column type reactor. Biogradation, 2009, 20(1): 117-124
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1909
  • HTML全文浏览数:  1047
  • PDF下载数:  1110
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-12-15
  • 刊出日期:  2013-03-18
鲍林林, 赵建国, 李晓凯, 李冬, 张杰. 常温低基质厌氧氨氧化反应器启动及其稳定性[J]. 环境工程学报, 2013, 7(3): 981-986.
引用本文: 鲍林林, 赵建国, 李晓凯, 李冬, 张杰. 常温低基质厌氧氨氧化反应器启动及其稳定性[J]. 环境工程学报, 2013, 7(3): 981-986.
shu
Bao Linlin, Zhao Jianguo, Li Xiaokai, Li Dong, Zhang Jie. Start-up and stability of Anammox bioreactor at normal temperature and low substrate concentration[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 981-986.
Citation: Bao Linlin, Zhao Jianguo, Li Xiaokai, Li Dong, Zhang Jie. Start-up and stability of Anammox bioreactor at normal temperature and low substrate concentration[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 981-986.
shu

常温低基质厌氧氨氧化反应器启动及其稳定性

  • 1. 河南师范大学环境学院,黄淮水环境与污染防治教育部重点实验室,河南省环境污染 控制重点实验室,新乡 453007
  • 2. 哈尔滨工业大学市政环境工程学院,哈尔滨 150090
  • 收稿日期:  2011-12-15
基金项目:

河南省重大公益性科研项目(081100910300)

河南省基础与前沿技术研究计划项目(102300410195,102300410197)

摘要: 以上向流生物滤池为反应器,以实验室内氧化沟回流污泥为接种污泥,采用先培育好氧生物膜,后转为厌氧环境培育厌氧氨氧化生物膜的方式,成功实现了常温低基质浓度下厌氧氨氧化反应器的启动。控制反应器进水pH为7.50~7.80,NH4+-N为30~40 mg/L,NO2--N为35~50 mg/L,温度为20~25℃。224 d以后,反应器启动成功。在稳定运行阶段,出水亚硝氮和氨氮的平均浓度分别为1.4 mg/L和4.6 mg/L,平均去除率分别为95.3%和90.1%,去除比例为1~1.8∶1,主要集中在1.4~1.5∶1,亚硝氮和氨氮去除的容积负荷分别为104.2 mg/(L·d)和146.0 mg/(L·d)。
