电增强载铝活性炭纤维吸附除氟的效果与影响因素

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

胡欣琪, 杨硕, 张旭, 杨亚杰, 贾建丽, 程明博, 徐冬春. 电增强载铝活性炭纤维吸附除氟的效果与影响因素[J]. 环境工程学报, 2013, 7(3): 951-956.
引用本文: 胡欣琪, 杨硕, 张旭, 杨亚杰, 贾建丽, 程明博, 徐冬春. 电增强载铝活性炭纤维吸附除氟的效果与影响因素[J]. 环境工程学报, 2013, 7(3): 951-956.
shu
Hu Xinqi, Yang Shuo, Zhang Xu, Yang Yajie, Jia Jianli, Cheng Mingbo, Xu Dongchun. Effect and impact factors of fluoride removal by electricity enhanced adsorption on Al-loaded activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 951-956.
Citation: Hu Xinqi, Yang Shuo, Zhang Xu, Yang Yajie, Jia Jianli, Cheng Mingbo, Xu Dongchun. Effect and impact factors of fluoride removal by electricity enhanced adsorption on Al-loaded activated carbon fiber[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 951-956.
shu

电增强载铝活性炭纤维吸附除氟的效果与影响因素

  • 1.

    清华大学环境学院,北京100084

  • 2.

    中国矿业大学化学与环境工程学院,北京100083

  • 3.

    北京燕龙供水有限公司,北京102200

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2009ZX07425-006)

  • 中图分类号: X703.1

Effect and impact factors of fluoride removal by electricity enhanced adsorption on Al-loaded activated carbon fiber

  • 1.

    School of Environment,Tsinghua University,Beijing 100084, China

  • 2.

    School of Chemical and Environmental Engineering, China University of Mining and Technology,Beijing 100083, China

  • 3.

    Beijing Yanlong Water Supply Co. Ltd.,Beijing 102200,China

  • Fund Project:

摘要

  • 摘要: 以含氟地下水为研究对象,采用自制电促吸附除氟反应器,开展电增强载铝活性炭纤维吸附除氟的动态实验,研究了不同电压、极板间距、地下水碱度和流速对吸附除氟效果的影响。实验结果表明,在负载炭纤维毡的电极一端加正电,可以提高除氟效果。当电压为1.6 V时除氟效果较好,单位面积炭毡处理达标水量为56.7 L/m2;极板间距设置为4 mm时电吸附反应器除氟效果最佳;通过调节pH改变地下水碱度,当地下水pH调节为5.5时,电吸附反应器除氟效果较未调节前提高50%;当采用3对电极板,流速为1.88 m/h时,达到最高表面处理负荷2 073.6 L/(m2·d);探究了反应器的反洗再生方式,并连续进行了吸附再生的动态实验;穿透的反应器以Al2(SO4)3溶液为再生液并采用反向加电1.6 V的方式,可以达到较好的再生效果,实现连续动态运行。
    Abstract: In this study, the self-made electrosorption reactor was adopted to remove fluoride by electricity enhanced adsorption on Al-loaded activated carbon fiber(ACF) from fluoride groundwater.The effects of voltage, electrode gap, alkalinity of groundwater and flow rate on water defluoridation and the regeneration of reactor were investigated, then the experiment of reactor adsorption-regeneration was performed continuously. The results show that positive electricity in electrode with ACF promotes defluoridation. The fluoride were removed effectively at positive polarization of 1.6 V, and standard water volume treated by unit area of ACF could be up to 57.6 L/m2. When distance between the electrode plate was set to 4 mm, the reactor could reach a high performance in defluoridation. The defluoridation effect is better at low pH, water volume treated by unit area of ACF is 50% improved when pH is 5.5. With 3 pairs of electrodes, flow rate of 1.88 m/h, the reactor can reach maximal surface treatment loading of 2 073.6 L/(m2·d). The saturated reactor can be regenerated effectively with Al2(SO4)3 solution and reverse polarization, then well operated continuously.
  • [1] 王峰,张昱,杨敏,等.活性氧化铝对饮用水中氟离子的吸附行为.中国农业大学学报, 2003,8(4):63-65 Wang F.,Zhang Y.,Yang M.,et al.Study on adsorption of fluoride ion in drinking water with activated alumina. Journal of China Agricultural University, 2003,8(4):63-65(in Chinese)
    [2] Tripathy S.,Bersillon L.Removal of fluoride from drinking water by adsorption onto alum-impregnated activated alumina. Separation and Purification Technology, 2006,50(3):310-317
    [3] Maliyekkal M.,Shukla S.,Philip L.,et al.Enhanced fluoride removal from drinking water by magnesia-amended activated alumina granules. Chemical Engineering Journal, 2008,140 (1-3):183-192
    [4] Lounici H.,Belhocinea D.,Grib H.,et al.Fluoride removal with electro-activated alumina. Desalination, 2004,161(3):287-293
    [5] 李永富,孟范平,姚瑞华.饮用水除氟技术开发应用现状.水处理技术, 2010,36(7):10-13,19 Li Y.F., Meng F.P.,Yao R.H.Development and application of fluoride removal in drinking water. Technology of Water Treatment, 2010,36(7): 10-13,19(in Chinese)
    [6] 詹予忠,李玲玲,汪永威,等.磷酸铝吸附除水中氟的研究.离子交换与吸附, 2006,22(6):527-535 Zhang Y.Z., Li L.L., Wang S.W.,et al.A study on removal of fluorides from water by adsorption onto aluminum phosphate. Ion Exchange and Adsorption, 2006,22(6):527-535(in Chinese)
    [7] 谢虹,贾文波,吴志刚.活性氧化铝除氟剂的除氟性能研究.华中科技大学学报(医学版), 2005,34(5):644-646 Xie H.,Jia W.B.,Wu Z.G.Performance of activated aluminum oxide as a fluorine-removal agent.Journal of Huazhong University of Science and Technology (Medical Sciences), 2005,34(5):644-646(in Chinese)
    [8] 陈福明. 一种去除水中离子的新方法.化工学报, 1999,50(1):114-117 Chen F.M.A new method for removing ions from water.Journal of Chemical Industry and Engineering, 1999,50(1):114-117(in Chinese)
    [9] 孙晓慰,朱国富.电吸附水处理技术及设备.工业水处理, 2002,22(8):1-3 Sun X.W.,Zhu G.F.Electro-adsorption technology and EST equipment.Industrial Water Treatment, 2002,22(8):1-3(in Chinese)
    [10] Farmer J.C., Fix D.V., Mack G.V., et al.21st International SAMPE Technical Conference.SAMPE,1995.294-304
    [11] Farmer J.C., Fix D.V., Mack G.V.,et al.Capacitive deionization of NH4ClO4 solutions with carbon aerogel electrodes.Journal of Applied Electrochemistry, 1996,26(10):1007-1018
    [12] Farmer J.C., Bahowick S.M., Harrar J.E., et al.Electrosorption of chromium ions on carbon aerogel electrodes as a means of remediating ground water.Energy and Fuels, 1997,11(2):337-347
    [13] 吴梅芬,金宇宁,赵国华.活性碳纤维的电吸附性能.建筑材料学报, 2011,14(1):140-144 Wu M. F., Jin Y. N., Zhao G. H. Electrosorption performance of activated carbon fibers(ACF). Journal of Building Materials,2011,14(1):140-144(in Chinese)
    [14] 刘裴文, 肖举强, 王萍,等.含氟水处理过程的"吸附交换"机理.离子交换与吸附, 1991,7(5):378-382 Liu P.W., Xiao J.Q., Wang Ping, et al.The mechanism of adsorption-exchange on treatment process of fluoride-containing water.Ion Exchange and Adsorption, 1991,7(5):378-382(in Chinese)
    [15] 李荻.电化学原理.北京:北京航空航天大学出版社, 2008.189-199
    [16] 刘海静,张鸿涛,孙晓慰.电吸附法去除地下水中离子的试验研究.中国给水排水, 2003,19(11):36-38 Liu H.J.,Zhang H.T.,Sun X.W.Experimental studies on electrosorption in groundwater ???桳攠湲?剭????畧?塃????瀠灗污楴捥慲琠楡潮湤猠?慡湳摴?牷敡獴敥慲爬挠栲‰瀰爳漬朱爹攨猱猱?漺昳?攭氳攸挨瑩牮漠獃潨物灮瑥楳潥温?偢牲漾杛爱攷獝猠?槏渎??标攡洬椕珗瓠爬祉???グる?????????ゾ????椮滐??栖槥測攠猲攰?7,36(4):34-37 Feng J.M.,Yang C.C.,Lü Z.Z.,et al.Design and calculation of a new kind of electromagnetic field sea-water desalter.Journal of Salt and Chemical Industry, 2007,36(4):34-37(in Chinese)
    [17] 饶伟,李定国.双电层吸附离子的动力学研究.海军工程大学学报, 2009,21(4)108-112 Rao W., Li D.G.Dynamics research on ion adsorption of electric double layer.Journal of Naval University of Engineering, 2009,21(4)108-112(in Chinese)
    [18] 刘瑞霞,汤鸿霄.负载镧纤维吸附剂对氟离子的吸附性能.环境科学, 2000,4(8):34-37 Liu R.X., Tang H.X. Adsorptive properties of fluoride ion on lanthanumloaded fibrous sorbent. Environmental Science,2000,4(8):34-37(in Chinese)
    [19] 杨硕,梁文艳,黎亮,等.活性碳三维电极电促吸附去除水中氟离子的研究.环境工程学报, 2010,4(7):1448-1452 Yang S.,Liang W.Y.,Li Liang, et al.Studies on three-dim ensional electrode of granular activated carbons on the removal of fluoride in drinking water.Chinese Journal of Environmental Engineering, 2010,4(7):1448-1452(in Chinese)
    [20] Yanhe H.,Xie Q.,Shuo C.Electrochemically enhanced adsorption of aniline on activated carbon fibers.Separation and Purification Technology, 2006,50(3):365-372
    [21] Welgemoed T.J.,Schutte C.F.Capacitive deionization technologyTM:An alternative desalination solution.Desalination, 2005,183(1-3):327-340
    [22] 杨慧云.电容去离子技术中活性碳纤维电极体系的研究.北京:北京工商大学硕士学位论文,2006 Yang H.Y. Study on the activated carbon fiber electrodes of capacitive deionization technology. Beijing: Master Dissertation of Beijing Technology and Business University,2006(in Chinese)
    [23] Singh G.,Clifford D.A.The Equilibrium Fluoride Capacity of Activated Alumina.EPA Report,600/S2-81-082.July,1981
    [24] 凌波.活性氧化铝除氟及再生方法的研究.第20届国际氟研究协会学术讨论会论文集.北京:中华人民共和国卫生部地氟病专家委员会,世界卫生组织,中国国家自然科学基金委员会,1994.222
    [25] 高锡珍,靳宏志.水洗在活性氧化铝氟解吸过程中的作用.湿法冶金, 2000,19(4):1-5 Gao X.Z., Jin H.Z. Effect of water washing on desorption of fluoride from activated alumina.Hydrometallurgy of China, 2000,19(4):1-5(in Chinese)
    [26] 陈榕,胡熙恩.电吸附技术的应用与研究.化学进展, 2006,18(1):80-8
