不同垃圾渗滤液组合处理工艺中DOM的变化特征

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

董天宝, 霍守亮, 张靖天, 席北斗, 昝逢宇, 赵永志. 不同垃圾渗滤液组合处理工艺中DOM的变化特征[J]. 环境工程学报, 2013, 7(3): 937-945.
引用本文: 董天宝, 霍守亮, 张靖天, 席北斗, 昝逢宇, 赵永志. 不同垃圾渗滤液组合处理工艺中DOM的变化特征[J]. 环境工程学报, 2013, 7(3): 937-945.
shu
Dong Tianbao, Huo Shouliang, Zhang Jingtian, Xi Beidou, Zan Fengyu, Zhao Yongzhi. Characteristics of dissolved organic matters from different landfill leachate treatment processes[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 937-945.
Citation: Dong Tianbao, Huo Shouliang, Zhang Jingtian, Xi Beidou, Zan Fengyu, Zhao Yongzhi. Characteristics of dissolved organic matters from different landfill leachate treatment processes[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 937-945.
shu

不同垃圾渗滤液组合处理工艺中DOM的变化特征

  • 1.

    沈阳航空航天大学能源与环境学院,沈阳 110136

  • 2.

    中国环境科学研究院,北京 100012

  • 3.

    安徽师范大学环境科学学院,芜湖 241000

  • 4.

    北京环卫集团环境研究发展有限公司,北京 100101

  • 基金项目:

    国家自然科学基金资助项目(40901248)

    "十一五"国家科技支撑计划项目(2009BADC2B01)

  • 中图分类号: X703

Characteristics of dissolved organic matters from different landfill leachate treatment processes

  • 1.

    College of Energy and Environment, Shenyang Aerospace University, Shenyang 110136, China

  • 2.

    Chinese Research Academy of Environmental Science, Beijing 100012, China

  • 3.

    College of Environmental Science, Anhui Normal University, Wuhu 241000, China

  • 4.

    ESG Environmental Engineering Co. Ltd., Beijing 100101, China

  • Fund Project:

摘要

  • 摘要: 为了快速表征垃圾渗滤液处理过程中有机物的特性变化,分别采用紫外光谱和三维荧光光谱对2种垃圾渗滤液处理工艺不同单元溶解性有机物(DOM)的变化进行了系统分析。结果表明,二级RO和厌氧+好氧+MBR+NF+RO工艺对渗滤液COD和NH3-N的去除率分别为98.7%、99.0%和98.8%、98.6%。随着处理过程的进行,2个处理工艺中DOM的SUVA254、E253/E203分别由0.74、0.33和0.46、0.12下降至0.015、0.014和0.010、0.012,有机物的芳香性和不饱和性下降,脂肪链芳香烃化合物开始增加。不同处理阶段渗透液DOM三维荧光光谱表明,随着处理过程的进行,类富里酸和类蛋白物质的含量逐渐下降,芳构化程度开始降低。其中二级RO系统对渗滤液中类富里酸物质的去除效果较好,而厌氧-好氧-MBR-NF-RO工艺中,类酪氨酸物质主要通过微生物降解去除,NF和RO膜对类富里酸和类腐殖酸物质的截留效果较好。
    Abstract: The ultraviolet spectra and fluorescence spectra are used to rapidly reveal the variation of dissolved organic matter (DOM) characteristics in two combination processes including two-pass RO (process A) and anaeration +aeration +MBR+ NF+ RO (process B) for landfill leachate treatment. The results indicated that the removal rates of COD and NH3-N were 98.7% and 99.0% for process A, and 98.8% and 98.6% for process B, respectively. The ultraviolet spectra analysis showed that aromatic and unsaturated compounds slightly decreased and the stability of aromatic compounds with aliphatic chain was weaken in those processes. These results were confirmed by the values of SUVA254 and E253/E203 decreasing from 0.74 and 0.33 to 0.015 and 0.014 in process A, and from 0.46 and 0.12 to 0.010 and 0.012 in process B. Moreover, the 3DEEM of DOM indicated that the concentrations of fulvic-like and protein-like compounds decreased and the degree of aromatization was reduced. The further analysis suggested that a good removal efficiency of fulvic-like compounds by two-pass RO system was achieved in process A. Tyrosine-like compounds were mainly removed by microbial degradation, and a good retention effect of fulvic-like compounds and humic-like compounds could be obtained by NF-RO in process B.
  • [1] 张旭,冯炘,解玉红. MBR+双膜法(NF/RO)处理垃圾渗滤液的工程实例.天津理工大学学报, 2010, 26(4):31-35 Zhang Xu, Feng Xin, Xie Yuhong. A project of MBR+two-membrane process for landfill leachate treatment. Journal of Tianjin University of Technology, 2010, 26(4):31-35 (in Chinese)
    [2] 覃芳慧,吴彦瑜,叶秀雅,等.组合工艺处理填埋场渗滤液中溶解性有机污染物的去除特性.环境工程学报, 2010, 4(12):2709-2713 Qin Fanghui, Wu Yanyu, Ye Xiuya, et al. Removal characteristics of dissolved organic matters in landfill leachate by combined process. Chinese Journal of Environmental Engineering, 2010, 4(12):2709-2713(in Chinese)
    [3] 楼紫阳,欧远洋,赵由才,等.老港填埋场新鲜渗滤液性质研究.环境污染与防治, 2004, 26(1):8-11 Lou Ziyang, Ou Yuanyang, Zhao Youcai, et al. Study on the characterization of raw leachate in Laogang landfill. Environmental Pollution and Control, 2004, 26(1):8-11(in Chinese)
    [4] He P. J., Xue J. F., Shao L. M.,et al. Dissolved organic matter (DOM) in recycled leachate of bioreactor landfill.Water Research, 2006, 40(7):1465-1473
    [5] Ki H. K., Hyun S. S., Heekyung P. Characterization of humic substances present in landfill leachates with different landfill ages and its implications.Water Research, 2002, 36(16):4023-4032
    [6] Fan H. J.,Shu H. Y.,Yang H. S., et al. Characteristics of landfill leachates in central Taiwan.Science of the Total Environment, 2006, 361(1-3):25-37
    [7] Nanny M. A., Ratasuk N. Characterization and comparison of hydrophobic neutral and hydrophobic acid dissolved organic carbon isolated from three municipal landfill leachates. Water Research, 2002, 36(6):1572-1584
    [8] Persson L.,Alsberg T.,Ledin A., et al. Transformations of dissolved organic matter in a landfill leachate-A size exclusion chromatography/mass spectrometric approach.Chemosphere, 2006, 64(7):1093-1099
    [9] 欧阳二明,张锡辉,王伟.常规净水工艺去除有机物效果的三维荧光光谱分析法.光谱学与光谱分析, 2007, 27(7):1373-1376 Ou Yang Erming, Zhang Xihui, Wang Wei. Study on the effects of organic removal by traditional purification process with three-dimensional excitation emission matrix fluorescence spectroscopy. Spectroscopy and Spectral Analysis, 2007, 27(7):1373-1376(in Chinese)
    [10] 吉芳英,谢志刚,黄鹤,等.垃圾渗滤液处理工艺中有机污染物的三维荧光光谱.环境工程学报, 2009, 3(10):1783-1788 Ji Fangying, Xie Zhigang, Huang He, et al. Three dimensional excitation-emission fluorescence spectra of dissolved organic matter in landfill leachates treatment process. Chinese Journal of Environmental Engineering, 2009, 3(10):1783-1788(in Chinese)
    [11] 何小松,席北斗,魏自民,等.三维荧光光谱研究垃圾渗滤液水溶性有机物与汞相互作用.分析化学研究报告, 2010, 38(10):1417-1422 He Xiaosong, Xi Beidou, Wei Zimin, et al. Three-dimensional excitation emission matrix fluorescence spectroscopic characterization of complexation between mercury(Ⅱ) and dissolved organic matter extracted from landfill leachate. Chinese Journal of Analytical Chemistry, 2010, 38(10):1417-1422(in Chinese)
    [12] Huo S. L.,Xi B. D., He L. S.,et al. Characteristics of dissolved organic matters (DOM) in leachate with different landfill ages. Journal of Environmental Science, 2008, 20(4):492-498
    [13] Baker A., Curry M. Fluorescence of leachates from three contrasting landfills. Water Research, 2004, 38(10):2605-2613
    [14] Baker A. Thermal fluorescence quenching properties of dissolved organic matter. Water Research, 2005, 39(18):4405-4412
    [15] 郝瑞霞,曹可心,赵钢,等. 用紫外光谱参数表征污水中溶解性有机污染物. 北京工业大学学报, 2006, 32(12):1062-1066 Hao Ruixia, Cao Kexin, Zhao Gang, et al. Ultraviolet absorption spectrum characterization apporoach for quantitative analysis of dissolved organic contaminants in sewage. Jouanal of Beijing University of Technoloy, 2006, 32(12):1062-1066(in Chinese)
    [16] 张甲珅,曹军,陶澍. 土壤水溶性有机物的紫外光谱特征及地域分异. 土壤学报, 2003, 40(1):118-122 Zhang Jiashen, Cao Jun, Tao Shu. Spatial variation of UV-VIS spectroscopy of water soluble organic carbon in Eastern China. Acta. Pedologica. Sinica., 2003, 40(1):118-122(in Chinese)
    [17] Simonsson M., Kaiser K., Danielsson R., et al. Estimating nitrate, dissolved organic carbon and DOC fractions in forest floor leachates using ultraviolet absorbance spectra and multivariate analysis. Geoderma, 2005, 124(1-2):157-168
    [18] 张宏忠,方少明,松全元,等. 吸收光谱法在垃圾渗滤液膜处理技术中的应用研究. 光谱学与光谱学分析, 2006, 26(8):1449-1453 Zhang Hongzhong, Fang Shaoming, Song Quanyuan, et al. Study on the application of absorption spectrum to the treatment of landfill leachate by membrane technology. Spectroscopy and Spectral Analysis, 2006, 26(8):1449-1453(in Chinese)
    [19] Nishijima W., Speitel Jr G. E. Fate of biodegradable dissolved organic carbon produced by ozonation on biological activated carbon. Chemosphere, 2004, 56(2):113-119
    [20] 张军政,杨谦,席北斗,等.垃圾填埋渗滤液溶解性有机物组分的光谱学特性研究. 光谱学与光谱分析, 2008, 28(11):2583-2587 Zhang Junzheng, Yang Qian, Xi Beidou, et al., Study on spectral characteristic of dissolved organic matter fractions extracted from municipal solid waste landfill leachate. Spectroscopy and Spectral Analysis, 2008, 28(11):2583-2587(in Chinese)
    [21] Clobe P. G. Characterization of marine and terrestrial DOM in seawater using excitation-emission matrix spectroscopy. Marine Chemistry, 1996, 51(4):325-346
    [22] Wu F. C., Midorikawa T., Tanoue E. Fluorescence properties of organic ligands for copper in lake Biwa and its rivers. Geochemical Journal, 2001, 35(5):333-346
    [23] Wu F. C., Tanoue E. Isolation and partial characterization of dissolved copper-complexing ligands in streamwaters. Environmental Science and Technology, 2001, 35(18):3646-3652
    [24] Baker A. Fluorescence properties of some farm wastes:Implication for water quality monitoring.Water Research, 2002, 36(1):189-195
    [25] Chen W., West Erhoff P., Leenheer J. A., et al. Fluorescence excitation-emission matrix regional integration to quantify spectra for dissolved organic matter. Environmental Science and Technology, 2003, 37(24):5701-5710
    [26] 赵庆良,卜琳,杨俊晨,等. 腐蚀电池-Fenton处理垃圾渗滤液溶解性有机物光谱特征.环境科学, 2011, 32(8):2378-2384 Zhao Qingliang, Bu Lin, Yang Junchen, et al. Spectroscopy properties of dissolved organic matter in landfill leachate during corrosion cell-Fenton post-treatment. Environmental Science, 2011, 32(8):2378-2384(in Chinese)
    [27] Hudson N., Baker A., Ward D., et al. Can fluorescence spectrometry be used as a surrogate for the Biochemical Oxygen Demand(BOD) test in water quality assessment? An example from South West England.Science of the Total Environment, 2008, 391(1):149-158
    [28] Swietlik J.,Sikorska E. Application of fluorescence spectroscopy in the studies of natural organic matter fractions reactivity with chlorine dioxide and ozone.Water Research, 2004, 38(17):3791-3799
    [29] Senesi N., Miano T., Provenzano M. R., et al. Characterization, differentiation, and classification of humic substances by fluorescence spectroscopy.Soil Science, 1991, 152(4):259-271
