高碱度水库水混凝过程中残留铝控制

,  ,  ,  ,

downloadPDF

上一篇

下一篇

郭婷婷, 刘锐平, 易秀, 陈桂霞, 胡承志. 高碱度水库水混凝过程中残留铝控制[J]. 环境工程学报, 2013, 7(3): 836-842.
引用本文: 郭婷婷, 刘锐平, 易秀, 陈桂霞, 胡承志. 高碱度水库水混凝过程中残留铝控制[J]. 环境工程学报, 2013, 7(3): 836-842.
shu
Guo Tingting, Liu Ruiping, Yi Xiu, Chen Guixia, Hu Chengzhi. Control of residual aluminum during coagulation in treatment of reservoir source water with high alkalinity[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 836-842.
Citation: Guo Tingting, Liu Ruiping, Yi Xiu, Chen Guixia, Hu Chengzhi. Control of residual aluminum during coagulation in treatment of reservoir source water with high alkalinity[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 836-842.
shu

高碱度水库水混凝过程中残留铝控制

  • 1.

    中国科学院生态环境研究中心环境水质学国家重点实验室,北京 100085

  • 2.

    长安大学环境科学与工程学院, 西安 710064

  • 3.

    华北水利水电学院环境与市政工程学院,郑州 450011

  • 基金项目:

    国家"水体污染控制与治理"科技重大专项(2009ZX07419-005)

    北京市教育委员会共建项目专项资助

  • 中图分类号: X524

Control of residual aluminum during coagulation in treatment of reservoir source water with high alkalinity

  • 1.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • 2.

    School of Environmental Science & Engineering, Chang’an University,Xi’an 710064, China

  • 3.

    School of Environmental and Civil Engineering, North China University of Water Resources and Electric Power, Zhenzhou 450011, China

  • Fund Project:

摘要

  • 摘要: 针对高碱度水库水源的某水厂残留铝超标问题,选取碱化度(B)与Alb含量不同的3种铝盐絮凝剂,研究不同投量与pH值下混凝效果与残留铝浓度水平。结果表明,碱化度和Alb含量显著影响混凝效果。DOC和浊度的去除率随着3种絮凝剂AlCl3(B=0)、PACl-1(B=1.2)、PACl-2(B=2.2)投量增大而升高。3种絮凝剂投量在1.5~2.0 mg/L(以铝计)范围内,总铝和溶解铝含量最低。对于该水厂自制的絮凝剂PACl-2,可通过降低絮凝剂碱化度,或将水的pH值降低至7~7.5之间,以此可以提高PACl-2混凝效果,而且可以降低出厂水残留铝浓度。考虑工程应用可行性,可优先考虑调整絮凝剂生产工艺。
    Abstract: To minimize the residual aluminum (Al) levels in the effluent of a drinking water treatment plant (DWTP) with reservoirs source water of high alkalinity,the coagulation performances and the residual Al concentrations using three flocculants,with different basicity (B) and Alb content,were investigated under varibale Al doses and pH. The results indicate that the basicity and Alb content significantly affect coagulation behaviors.The removal efficiency of DOC and turbidity increases with elevated doses of AlCl3 (B=0), PACl-1 (B = 1.2), and PACl-2 (B = 2.2). The concentrations of total Al and dissolved Al are the lowest at Al doses of 1.5~2.0 mg/L for three flocculants.As for the PACl-2, which is prepared by this DWTP, both strategies of decreasing the basicity of flocculant and adjusting the solution pH to 7~7.5 are useful to enhance the coagulation performances and to decrease the residual Al levels. Moreover, the adjustment of flocculant preparation is preferred in the future application.
  • [1] 黄岁樑,臧常娟,杜胜蓝,等. pH、溶解氧、叶绿素a 之间相关性研究.Ⅰ:养殖水体. 环境工程学报,2011,5 (6):7-8 Huang Suiliang,Zang Changjuan,Du Shenglan,et al.Study on the relationships among pH, dissolved oxygen and chlorophyll a Ⅰ: Aquaculture water. Chinese Journal of Environmental Engineering,2011,5(6):1201-1208(in Chinese)
    [2] 崔福义,胡明成,张燕,等. 我国部分城市饮用水中铝含量调查. 中国给水排水,2002,18 Cui F.Y., Hu M.C., Zhang Y., et al. Investigation on aluminum concentration in drinking water in part of China’s cities. China Water Wastewater, 2002,18:5-8(in Chinese)
    [3] 蒋绍阶,梁建军. 净水中残余铝的危害与控制. 重庆建筑大学学报,1999,21(6): 121-123 Jiang Shaojie, Liang Jianjun. Hazard and control of residual aluminum in drinking water. Journal of Chongqing Jianzhu University,1996,21(6),121-123(in Chinese)
    [4] Srinivasan P.T.,Viraraghavan T.,Surbramanian K.S. Aluminum in drinking water: An overview. Water SA,1999,25 (1):47-56
    [5] Berthon G. Aluminum speciation in relation to aluminum bioavailability,metabolism and toxicity. Coord. Chem. Rev.,2002, 228 (2):319-341
    [6] 汪光焘.城市供水行业2000年技术进步发展规划.北京:中国建筑工业出版社,1999
    [7] 崔福义,李名锐,王志红,等.饮用水中铝的危害、来源及现状.哈尔滨建筑大学学报,1997,30(6):51-54 Cui Fuyi,Li Mingrui,Wang Zhihong,et al. The harm,resource and status of aluminum in drinking water. Journal of Harbin University of Civil Engineering and Architecture,1997,30(6):51-54 (in Chinese)
    [8] Shi B.,Wei Q., Wang D.,et al. Coagulation of humic acid: the performance of preformed and non-preformed Al species. Colloids Surf. A, 2007,296(7):141-148
    [9] Zhonglian Yang,Bao Yu Gao, Qin Yan Yue,et al. Effect of pH on the coagulation performance of Al-based coagulants and residual aluminum speciation during the treatment of humic acid-kaolin synthetic water. Journal of Hazardous Materials,2010,178 (2): 596-603
    [10] Steve Kvech,Marc Edwards. Solubility controls on aluminum in drinking water at relatively low and high pH. Water Research,2002,36(2): 4356-4368
    [11] 胡承志. 富含Al13与活性氯絮凝剂的电解制备及性能研究. 北京:中国科学院生态环境研究中心博士学位论文, 2006 Hu Chengzhi. Electrochemical preparation and examination of a coagulant containing high content of Al13 and active chlorine. Beijing: Doctor Dissertation of Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences,2006 (in Chinese)
    [12] Yan M.,Wang D.,Qu J.,et al. Relative importance of hydrolyzed Al(Ⅲ) species (Ala, Alb, and Alc) during coagulation with polyaluminum chloride: A case study with the typical micro-polluted source waters. J. Colloid Interface Sci.,2007,316 (7):482-489
    [13] Bertsch P.M., Thomas G. W., Barnhisel R. I. Characterization hydroxy-aluminum solutions by aluminum-27 nuclear magnetic resonance spectroscopy. Soil Sci.Soc.Am.J,1986, 50(6):825-830
    [14] He Zhao, Huijuan Liu,Jiuhui Qu. Effect of pH on the aluminum salts hydrolysis during coagulation process:Formation and decomposition of polymeric aluminum species. Journal of Colloid and Interface Science,2009,330 (9):105-112
    [15] Chengzhi Hu,Huijuan Liu,Jiuhui Qu,et al. Coagulation behavior of aluminum salts in eutrophic water:Significance of Al13 species and pH control. Environment Science & Technology,2006,40(1):325-331
    [16] 赵赫. 混凝去除消毒副产物前驱体的形态匹配机制研究. 北京:中国科学院生态环境研究中心博士学位论文,2009 Zhao He. Mechanism of disinfection byproduct precursors control by aluminum coagulation based on speciation matching. Beijing: Doctor Dissertation of Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences,2009 (in Chinese)
    [17] 王志红,崔福义. pH值和水温对残余铝的影响试验研究. 广东工业大学学报, 2003,20(3):71-75 Wang Zhihong, Cui Fuyi. Correlation of water temperature and ph value with residual aluminum in water plant. Journal of Guangdong University of Technology, 2003,20(3):71-75(in Chinese)
    [18] 汤鸿霄. 无机高分子絮凝理论与絮凝剂. 北京:中国建筑工业大学出版社,2006
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2586
  • HTML全文浏览数:  1116
  • PDF下载数:  1324
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-05-04
  • 刊出日期:  2013-03-18
郭婷婷, 刘锐平, 易秀, 陈桂霞, 胡承志. 高碱度水库水混凝过程中残留铝控制[J]. 环境工程学报, 2013, 7(3): 836-842.
引用本文: 郭婷婷, 刘锐平, 易秀, 陈桂霞, 胡承志. 高碱度水库水混凝过程中残留铝控制[J]. 环境工程学报, 2013, 7(3): 836-842.
shu
Guo Tingting, Liu Ruiping, Yi Xiu, Chen Guixia, Hu Chengzhi. Control of residual aluminum during coagulation in treatment of reservoir source water with high alkalinity[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 836-842.
Citation: Guo Tingting, Liu Ruiping, Yi Xiu, Chen Guixia, Hu Chengzhi. Control of residual aluminum during coagulation in treatment of reservoir source water with high alkalinity[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 836-842.
shu

高碱度水库水混凝过程中残留铝控制

  • 1.  中国科学院生态环境研究中心环境水质学国家重点实验室,北京 100085
  • 2.  长安大学环境科学与工程学院, 西安 710064
  • 3.  华北水利水电学院环境与市政工程学院,郑州 450011
  • 收稿日期:  2012-05-04
基金项目:

国家"水体污染控制与治理"科技重大专项(2009ZX07419-005)

北京市教育委员会共建项目专项资助

摘要: 针对高碱度水库水源的某水厂残留铝超标问题,选取碱化度(B)与Alb含量不同的3种铝盐絮凝剂,研究不同投量与pH值下混凝效果与残留铝浓度水平。结果表明,碱化度和Alb含量显著影响混凝效果。DOC和浊度的去除率随着3种絮凝剂AlCl3(B=0)、PACl-1(B=1.2)、PACl-2(B=2.2)投量增大而升高。3种絮凝剂投量在1.5~2.0 mg/L(以铝计)范围内,总铝和溶解铝含量最低。对于该水厂自制的絮凝剂PACl-2,可通过降低絮凝剂碱化度,或将水的pH值降低至7~7.5之间,以此可以提高PACl-2混凝效果,而且可以降低出厂水残留铝浓度。考虑工程应用可行性,可优先考虑调整絮凝剂生产工艺。
