絮凝法回收印染废水中的聚乙烯醇

,  ,

downloadPDF

上一篇

下一篇

张玥, 王辉, 李朗晨. 絮凝法回收印染废水中的聚乙烯醇[J]. 环境工程学报, 2013, 7(3): 810-814.
引用本文: 张玥, 王辉, 李朗晨. 絮凝法回收印染废水中的聚乙烯醇[J]. 环境工程学报, 2013, 7(3): 810-814.
shu
Zhang Yue, Wang Hui, Li Langchen. Recovery of polyvinyl alcohol from dyeing wastewater by flocculation method[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 810-814.
Citation: Zhang Yue, Wang Hui, Li Langchen. Recovery of polyvinyl alcohol from dyeing wastewater by flocculation method[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 810-814.
shu

絮凝法回收印染废水中的聚乙烯醇

  • 1.

    中国海洋大学材料科学与工程研究院,青岛 266100

  • 基金项目:

    国家自然科学基金资助项目(51203143)

    青岛市科技发展计划项目(12-1-4-1-(27)-jch)

    中国海洋大学青年教师基金(201213002)

  • 中图分类号: X703

Recovery of polyvinyl alcohol from dyeing wastewater by flocculation method

  • 1.

    Institute of Materials Science and Engineering, Ocean University of China, Qingdao 266100, China

  • Fund Project:

摘要

  • 摘要: 采用絮凝法以硼酸为絮凝剂,硫酸同氢氧化钠反应形成的硫酸钠为盐析剂,对含聚乙烯醇的印染废水进行回收处理。通过检测絮凝后溶液中聚乙烯醇含量分析了硼酸投加量、硫酸投加量、温度和pH值等因素对其回收率的影响。结果表明,当硼酸投加量为0.5 g,硫酸投加量为5 mL,pH值为9,温度为50℃时,聚乙烯醇的回收率可达98.6%,且COD去除率为93%。
    Abstract: The recovery of polyvinyl alcohol (PVA) from dyeing wastewater by flocculation method is investigated. The obtained sodium sulfate through acid alkali relation was used as salt agent. The boric acid was used as flocculation agent. The influencing factors of PVA recovery were analyzed through the detection of PVA content in flocculation solution. Optimal conditions of the recovery were as follows: boric acid dosage of 0.5 g, sulfuric acid of 5 mL, pH value of 9, and temperature of 50℃. PVA recovery rate is as high as 98.6% and the COD elimination rate is 93% under the optimal conditions.
  • [1] 周永元.浆料的现状与发展.棉纺织技术,2008,28(7):389-394 Zhou Y.Y. Current situation add progress of sizing agent. Cotton Manufacturing Technology,2008,28(7):389-394 (in Chinese)
    [2] 杨晓雄,闻荻江.聚乙烯醇对环境影响的研究进展.苏州科技学院学报 (工程技术版),2005,18(1):9-13 Yang X. X.,Wen D.J. Development on environmental influence of PVA. Journal of University of Science and Technology of Suzhou (Engineering and Technology),2005,18(1):9-13 (in Chinese)
    [3] 廖红东,袁丽,童春义等,基于聚乙烯醇/Fe203纳米颗粒的纤维素酶固定化,高等学校化学学报,2008,29(8):1564-1568 Liao H.D., Yuan L., Tong C.Y.,et al. Immobilization of cellulase based on polyvinyl alcohol/Fe203 nanoparticles. Chemical Journal of Chinese University,2008,29(8):1564-1568 (in Chinese)
    [4] 邵耀锋,韦昌健.膜法技术在复杂水质处理上的应用.水工业市场,2008,(6):24-28 Shao Y.F., Wei C.J. Application on complicated water quality by membrane method.Mater-Industry Market,2008,(6):24-28 (in Chinese)
    [5] 刘廷惠.超滤回收聚乙烯醇退浆水的研究.环境化学,1984,3(5):9-12 Liu T.H. Recovery of polyvinyl alcohol from desizing wastewater by ultrafiltration method. Environmental Chemistry, 1984,3(5):9-12 (in Chinese)
    [6] 张治宏,王彩花,王晓昌.高级氧化技术在印染废水处理中的研究进展.工业安全与环保,2008,(34):8-12 Zhang Z.H., Wang C.H., Wang X.C. Progress on advanced oxidation in dyeing wastewater. Industry Security & Environmental Protection,2008,(34):8-12 (in Chinese)
    [7] 陈友波.PVA浆料的退除工艺. 印染,2006, (3):13-15 Chen Y.B. Desizing process of PVA size. Dyeing,2006,(3):13-15 (in Chinese)
    [8] 董声雄,龚琦,赵素英等.超滤法分离PVA退浆水的研究. 纺织学报,2004,25(2):73-85 Dong S.X., Gong Q.,Zhao S.Y., et al. Polyvinyl alcohol recovery by ultratiltration. Journal of Textile Research,2004,25 (2):73-85 (in Chinese)
    [9] 徐泽林,康娟,陶阳宇,等.离子膜电解法预处理聚乙烯醇退浆废水研究.给水排水,2007,23(1): 69-76 Xu Z.L., Kang J., Tao Y.Y., et al. Research on pretreatment of polyvinyl-alcohol desizing wastewater by ion-exchange membrane electrolysis.China Water & Wasterwater,2007,23(1):69-76 (in Chinese)
    [10] Xu L.,Li W.,Lu S.Q., et al. Treating dyeing waste water by ceramic membrane in cross flow microfiltration. Desalination,2002,149 (2):199-203
    [11] Anaw S. P.,Ratana J.,Piyanoot L. Treatment of effluents from textile-rinsing operations by thermally stable nanofiltration membrane. Desalination,2004,160 (1):75-81
    [12] Lopes C. N., Petrus C. C., Rielia H. G. Color and COD retention by nanofiltration membranes, Desalination.2005, 172 (1):77-83
    [13] Lee J. W., Choi S. P., Shim W. G., et al Submerged microfiltration membrane coupled with alum coagulation/powdered activated carbon adsorption for complete decolorization of reactive dyes. Water Research,2006,40 (3):435-444
    [14] 陈伟,佟玲,陈文清,等.膜分离技术在印染废水分质处理与分段回用中的应用.环境污染与防治,2008,30(7):62-66 Chen W., Tong L., Chen W.Q., et al Membrane separation technologies for segregated pretreatment and resource recycling of printing and dyeing wastewaters. Environmental Pollution & Prevention,2008,30 (7):62-66 (in Chinese)
    [15] 徐竟成,魏巧玲,郑涛,等.印染退浆废水PVA处理技术.印染,2009, (8):50-52 Xu J.C., Wei Q.L., Zheng T., et al. Treatment technology of polyvinyl alcohol in desizing wastewater. Dyeing,2009,(8):50-52 (in Chinese)
    [16] 郭丽,奚旦立,马春燕.退浆废水中聚乙烯醇回收技术的研究.净水技术,2008,27 (1):58-60 Guo L., Xi D.L., Ma C.Y. Study on recovery method of polyvinyl alcohol in desizing wastewate. Water Purification Technology,2008,27 (1):58-60 (in Chinese)
    [17] 郭丽, 黄承武,奚旦立,等.退浆废水中聚乙烯醇的回收.石油化工腐蚀与防护,2007,24 (6):59-61 Guo L., Huang C.W., Xi D.L.,et al. Study of recovery of polyvinyl alcohol from desizng wastewater. Corrosion & Protection in Petrochemical Industry,2007,24 (6):59-61 (in Chinese)
    [18] 徐竟成,郑涛.分光光度法测定印染废水中聚乙烯醇的含量.化工环保,2004,(24):387-388 Xu J.C., Zheng T. Measurement on polyvinyl alcohol in dyeing wastewater. Chemical Engineering and Environmental Protection, 2004,(24):387-388 (in Chinese)
    [19] 伍开宝.纺织印染废水中聚乙烯醇的分光光度法测定,化学工程与装备,2008,(6):114-115 Wu K.B. Determination of PVA content by spectrophotometer in desizing wastewater. Journal of Chemical Engineering & Equipment,2008,(6):114-11 (in Chinese)
    [20] 顾润南,林苗.退浆废水中聚乙烯醇(PVA)含量的测定.东华大学学报 (自然科学版),2005,31(2):106-109 Gu R.N., Lin M. Determination of PVA content in desizing wastewater. Journal of Donghua University(Nature Science), 2005,31(2):106-109 (in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2661
  • HTML全文浏览数:  1405
  • PDF下载数:  1152
  • 施引文献:  0
出版历程
  • 收稿日期:  2012-02-24
  • 刊出日期:  2013-03-18
张玥, 王辉, 李朗晨. 絮凝法回收印染废水中的聚乙烯醇[J]. 环境工程学报, 2013, 7(3): 810-814.
引用本文: 张玥, 王辉, 李朗晨. 絮凝法回收印染废水中的聚乙烯醇[J]. 环境工程学报, 2013, 7(3): 810-814.
shu
Zhang Yue, Wang Hui, Li Langchen. Recovery of polyvinyl alcohol from dyeing wastewater by flocculation method[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 810-814.
Citation: Zhang Yue, Wang Hui, Li Langchen. Recovery of polyvinyl alcohol from dyeing wastewater by flocculation method[J]. Chinese Journal of Environmental Engineering, 2013, 7(3): 810-814.
shu

絮凝法回收印染废水中的聚乙烯醇

  • 1. 中国海洋大学材料科学与工程研究院,青岛 266100
  • 收稿日期:  2012-02-24
基金项目:

国家自然科学基金资助项目(51203143)

青岛市科技发展计划项目(12-1-4-1-(27)-jch)

中国海洋大学青年教师基金(201213002)

摘要: 采用絮凝法以硼酸为絮凝剂,硫酸同氢氧化钠反应形成的硫酸钠为盐析剂,对含聚乙烯醇的印染废水进行回收处理。通过检测絮凝后溶液中聚乙烯醇含量分析了硼酸投加量、硫酸投加量、温度和pH值等因素对其回收率的影响。结果表明,当硼酸投加量为0.5 g,硫酸投加量为5 mL,pH值为9,温度为50℃时,聚乙烯醇的回收率可达98.6%,且COD去除率为93%。
