CABR处理分散式生活污水抗短期有机负荷潜能

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

冯华军, 汪美贞, 黄宝成, 张再平, 陈英, 张志宁, 沈东升. CABR处理分散式生活污水抗短期有机负荷潜能[J]. 环境工程学报, 2012, 6(11): 4053-4058.
引用本文: 冯华军, 汪美贞, 黄宝成, 张再平, 陈英, 张志宁, 沈东升. CABR处理分散式生活污水抗短期有机负荷潜能[J]. 环境工程学报, 2012, 6(11): 4053-4058.
shu
Feng Huajun, Wang Meizhen, Huang Baocheng, Zhang Zaiping, Chen Ying, Zhang Zhining, Shen Dongsheng. Resistance of carrier anaerobic baffled reactor for decentralized domestic sewage treatment to short-term organic shock loading[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 4053-4058.
Citation: Feng Huajun, Wang Meizhen, Huang Baocheng, Zhang Zaiping, Chen Ying, Zhang Zhining, Shen Dongsheng. Resistance of carrier anaerobic baffled reactor for decentralized domestic sewage treatment to short-term organic shock loading[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 4053-4058.
shu

CABR处理分散式生活污水抗短期有机负荷潜能

  • 1.

    浙江工商大学环境科学与工程学院,杭州 310035

  • 基金项目:

    浙江省高等学校创新团队支持计划资助项目(T200912)

    杭州市科技计划项目(20091633F07,20091633F11)

    浙江省科技厅重大科技专项(2010C13001)

  • 中图分类号: X703.1

Resistance of carrier anaerobic baffled reactor for decentralized domestic sewage treatment to short-term organic shock loading

  • 1.

    School of Environmental Science and Engineering,Zhejiang Gongshang University,Hangzhou 310035,China

  • Fund Project:

摘要

  • 摘要: 为考察填料式厌氧折流板反应器(CABR)处理分散式生活污水抗短期有机负荷冲击的稳定性,从宏观运行性能、中间产物累积以及微观微生物活性3个层次来研究不同温度下短期有机负荷冲击对CABR运行性能影响。结果表明:宏观运行性能指标TCOD沿程变化曲线在28℃时受到有机负荷冲击仍呈现"L"型,容积负荷去除率也由基准条件下0.27 kg/(m3·d)提高至0.73 kg/(m3·d),但随温度的下降,沿程曲线逐渐接近"\"型,容积负荷去除率的增加幅度也逐渐变小。中间产物积累指标中VFA/碱度比值小于0.11~0.14时,TCOD去除率可达80%以上;SMP/SCOD比值沿水流方向呈上升趋势表明CABR抗负荷冲击性能较佳。而微观微生物酶活性受基质浓度提高的促进效应和温度下降的抑制效应相互作用表现各异。总体而言,在高温(28℃)条件下,分散式生活污水的有机负荷冲击不会对CABR出水造成显著影响,但在中温(18℃)和低温(10℃)条件下,CABR抗有机负荷冲击的稳定性随温度的下降而下降。
    Abstract: In order to examine the stability of carrier anaerobic baffled reactor (CABR) treating decentralized domestic sewage at different operational temperatures, resistance performance of short-term organic shock load was investigated from three levels of the macroscopic performance, catabolic intermediate and microcosmic alternation. The results showed that, on macroscopic performance level, the TCOD removal curve throughout the CABR still took on "L" shape and the volumetric removal rate increased from 0.27 kg/(m3·d) to 0.73 kg/(m3·d) under short-term organic shock load at 28℃. But the TCOD removal curve was changed from "L" shape to "\" shape and the increased trend of volumetric removal rate became weaker as the temperature decreased. On catabolic intermediate level, the TCOD removal efficiency was above 80% as ratios of VFA/alkalinity less than 0.11~0.14. Ratios of SMP/SCOD increased along the CABR indicated excellent potentiality of shock resistance. On microcosmic alternation level, the microbial activity was determined by active effect of increased substrate concentration and negative effect of decreased temperature. To sum up, short-term organic shock loading has minor effects on the performance of CABR treating decentralized domestic sewage at high(28℃) temperature. But the stability of CABR under short-term organic shock loading declined as the temperature decreased at medium(18℃) and low (10℃) temperatures.
  • [1] Chua H.,Hu W. F.,Yu P. H. F.,et al. Responses of an anaerobic fixed-film reactor to hydraulic shock loadings. Bioresource Technology,1997,61(1): 79-83
    [2] Mini Bajaj,Claudia Gallert,Josef Winter. Treatment of phenolic wastewater in an anaerobic fixed bed reactor(AFBR)—Recovery after shock loading. Journal of Hazardous Materials, 2009,162(2-3): 1330-1339
    [3] Tarek Sabry. Application of the UASB inoculated with flocculent and granular sludge in treating sewage at different hydraulic shock loads. Bioresource Technology, 2008,99(10): 4073-4077
    [4] Feng H. J.,Hu L. F.,Mahmood Q.,et al. Anaerobic domestic wastewater treatment with bamboo carrier anaerobic baffled reactor. International Biodeterioration & Biodegradation,2008,62(3): 232-238
    [5] Orhon D.,Ates E.,Sozen S.,et al. Characterization and COD fractionation of domestic wastewaters. Environ. Poll.,1997, 95(2):191-204
    [6] 冯华军,冯小晏,薛飞,等. 浙江省典型地区生活污水水质的调查研究.科技通报, 2011, 27(3):436-440 Feng Huajun,Feng Xiaoyan,Xue Fei,et al. Sewage quality investigation research in typical region of Zhejiang province. Bulletin of Science and Technology, 2011. 27(3):436-440(in Chinese)
    [7] 国家环境保护总局.水和废水监测分析方法(第3版).北京:中国环境科学出版社,1997
    [8] Aquino S. F., Stuckey D. C. Production of soluble microbial products (SMP) in anaerobic chemostats under nutrient deficiency. Journal of Environmental Engineering-ASCE, 2003,129(11): 1007-1014
    [9] 朱南文,闵航,陈美慈,等. TTC-脱氢酶测定方法的探讨. 中国沼气, 1996, 14(2):3-5 Zhu Nanwen,Min Hang,Chen Meici,et al. The study of determination on TTC-Dehydrogenase activity. China Biogas. 1996, 14(2):3-5(in Chinese)
    [10] Sanchez E.,Borja R.,Travieso L.,et al. Effect of organic loading rate on the stability, operational parameters and performance of a secondary upflow anaerobic sludge bed reactor treating piggery waste. Bioresource Technology,2005,96(3): 335-344
    [11] Smeaton J. R.,Elliot W. H. Selective release of ribonuclease inhibitor from B.subtilis cells by cold shock treatment. Biochemical and Biophysical Research Communications,1967,26 (1): 75-81
    [12] Kuo W. C.,Parkin G. F. Characterization of soluble microbial products from anaerobic treatment by molecular weight distribution and nickel-chelating properties. Water Research, 1996,30 (4): 915-922
    [13] Barker D. J.,Salvi S. M. L.,Langenhoff A. A. M.,et al. Soluble microbial products in ABR treating low-strength wastewater. Journal of Environmental Engineering-ASCE, 2000, 126(3): 239-249
    [14] Barker D.J., Stuckey D.C.Modeling of soluble microbial products in anaerobic digestion: The effect of feed strength and composition. Water Environment Research,2001, 73(2): 173-184
    [15] 宋铁红,赵勇胜,崔玉波,等. 厌氧折流板反应器中酸化菌活性研究. 吉林大学学报(地球科学版),2006, 36(3): 429-432 Song Tiehong,Zhao Yongsheng,Cui Yubo,et al. Study on acidate bacteria activity in anaerobic baffled reactor. Journal of Jilin Unviersity(Earth Science),2006,36(3):429-432(in Chinese)
