旋流分离器油水分离效率的模拟研究

,  ,  ,

downloadPDF

上一篇

下一篇

周宁玉, 高迎新, 安伟, 杨敏. 旋流分离器油水分离效率的模拟研究[J]. 环境工程学报, 2012, 6(9): 2953-2957.
引用本文: 周宁玉, 高迎新, 安伟, 杨敏. 旋流分离器油水分离效率的模拟研究[J]. 环境工程学报, 2012, 6(9): 2953-2957.
shu
Zhou Ningyu, Gao Yingxin, An Wei, Yang Min. Numerical simulation of oil-water separation efficiency of a hydrocyclone[J]. Chinese Journal of Environmental Engineering, 2012, 6(9): 2953-2957.
Citation: Zhou Ningyu, Gao Yingxin, An Wei, Yang Min. Numerical simulation of oil-water separation efficiency of a hydrocyclone[J]. Chinese Journal of Environmental Engineering, 2012, 6(9): 2953-2957.
shu

旋流分离器油水分离效率的模拟研究

  • 1.

    中国科学院生态环境研究中心环境水质学国家重点实验室,北京 100085

  • 2.

    后勤工程学院,重庆 401331

  • 基金项目:

    国家自然科学基金资助项目(50921064, 2009D-5006-02-03)

  • 中图分类号: X703

Numerical simulation of oil-water separation efficiency of a hydrocyclone

  • 1.

    State Key Laboratory of Environmental Aquatic Chemistry, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China

  • 2.

    Logistic Engineering University, Chongqing 401331, China

  • Fund Project:

HTML全文

  • 摘要: 采用计算流体力学的方法,探讨了操作条件和物料特性对旋流分离器分离油水效率的影响。旋流器为单锥双入口,其主直径为50 mm,锥角为5.5°。模拟过程中,采用商业用软件'Fluent 6.3’中的雷诺应力模型和欧拉多相流模型来模拟不同条件下油水旋流分离器的分离性能。模拟结果表明,对于本研究的油水旋流分离器,最佳的分流比是10%,最佳的油滴浓度是0.5% (V/V)。在最佳的分流比和油滴浓度下,当进口流速为10.46 m/s时,油水旋流分离器可将15 μm的油滴去除80%以上,油滴的分离界限粒径d50 (50%的分离效率)为9.2 μm。在模拟的基础上,用统计软件STATISTICA 6.0对分离效率与操作条件和物料特性之间的关系进行拟合。通过拟合式预测的分离效率与实测值相吻合,误差小于15%。
    Abstract: The Eulerian multiphase model and Reynolds-stress model (RSM), validated with experimental data, were used to simulate the separation efficiency of an oil-water hydrocyclone under different conditions, using the computational fluid dynamics (CFD) software 'Fluent 6.3’. The hydrocyclone had a diameter of 50 mm, with two inlets and a single cone, the cone angle θ was 5.5°. The results show that for the oil-water hydrocyclone, the optimal flow rejection ratio was 10%, and the optimal oil droplet concentration was 0.5% (V/V). Under the conditions the hydrocyclone could remove >80% of 15 μm oil droplets, and the cut-off size for 50% separation efficiency was 9.2 μm, when the inlet velocity was 10.46 m/s. A mathematical correlation between separation efficiency and operating conditions/feed characteristics was derived based on the simulation results, with the aid of software STATISTICA for Windows version 6.0. The predicted oil-water separation efficiency using the mathematical correlation agreed well with the experimental results with a deviation below 15%.
  • [1] Belaidi A., Thew M. T., Mumaweera S.J. Hydrocyclone performance with complex oil-water emulsions in the feed. Can. J. Chem. Eng., 2003, 81 (6): 1159-1170
    [2] Huang S. Numerical simulation of oil-water hydrocyclone using Reynolds-stress model for eulerian multiphase flows. Can. J. Chem. Eng., 2005, 83 (5): 829-834
    [3] Husveg T., Rambeau O., Drengstig T., et al. Performance of a deoiling hydrocyclone during variable flow rates. Miner. Eng., 2007, 20 (3): 368-379
    [4] Gomez C., Caldenfey J., Wang S., et al. Oil/water separation in liquid/liquid hydrocyclones (LLHC): Part 1-experimental investigation. SPE J., 2002, 7 (2): 353-361
    [5] Young G. A. B., Wakley W. D., Taggart D. L., et al. Oil-water separation using hydrocyclones: An experimental search for optimum dimensions. J. Petrol. Sci. Eng., 1994, 11 (1): 37-50
    [6] Wang B., Yu A. B. Numerical study of the gas-liquid-solid flow in hydrocyclones with different configuration of vortex finder. Chem. Eng. J., 2008, 135 (1-2): 33-42
    [7] Petty C. A., Parks S. M. Flow structures within miniature hydrocyclones. Miner. Eng., 2004, 17(5): 615-624
    [8] Delgadillo J. A., Rajamani R. K. A comparative study of three turbulence-closure models for the hydrocyclone problem. Int. J. Miner. Process., 2005, 77 (5): 217-230
    [9] Murphy S., Delfos R., Pourquié M. J. B. M., et al. Prediction of strongly swirling flow within an axial hydrocyclone using two commercial CFD codes. Chem. Eng. Sci., 2007, 62(6): 1619-1635
    [10] Evans W. K., Suksangpanomrung A., Nowakowski A. F. The simulation of the flow within a hydrocyclone operating with an air core and with an inserted metal rod. Chem. Eng. J., 2008, 143 (1-3): 51-61
    [11] Narasimha M., Sripriya R., Banerjee P. K. CFD modelling of hydrocyclone—Prediction of cut size. Int. J. Miner. Process., 2005, 75(1-2): 53-68
    [12] Bhaskar K. U., Murthy Y. R., Ramakrishnan N., et al. CFD validation for flyash particle classification in hydrocyclones. Miner. Eng., 2007, 20 (3): 290-302
    [13] Wang B., Yu A. B. Numerical study of particle-fluid flow in hydrocyclones with different body dimensions. Miner. Eng., 2006, 19(10): 1022-1033
    [14] Zhou N. Y., Gao Y. X., An W., et al. Investigation of velocity field and oil distribution in an oil-water hydrocyclone using a particle dynamics analyzer. Chem. Eng. J., 2010: 157(1): 73-79
    [15] Nowakowski A. F., Kraipech W., Williams R. A., et al. The hydrodynamics of a hydrocyclone based on a three-dimensional multi-continuum model. Chem. Eng. J., 2000, 80(1-3): 275-282
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2458
  • HTML全文浏览数:  1338
  • PDF下载数:  1908
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-04-13
  • 刊出日期:  2012-09-14
周宁玉, 高迎新, 安伟, 杨敏. 旋流分离器油水分离效率的模拟研究[J]. 环境工程学报, 2012, 6(9): 2953-2957.
引用本文: 周宁玉, 高迎新, 安伟, 杨敏. 旋流分离器油水分离效率的模拟研究[J]. 环境工程学报, 2012, 6(9): 2953-2957.
shu
Zhou Ningyu, Gao Yingxin, An Wei, Yang Min. Numerical simulation of oil-water separation efficiency of a hydrocyclone[J]. Chinese Journal of Environmental Engineering, 2012, 6(9): 2953-2957.
Citation: Zhou Ningyu, Gao Yingxin, An Wei, Yang Min. Numerical simulation of oil-water separation efficiency of a hydrocyclone[J]. Chinese Journal of Environmental Engineering, 2012, 6(9): 2953-2957.
shu

旋流分离器油水分离效率的模拟研究

  • 1.  中国科学院生态环境研究中心环境水质学国家重点实验室,北京 100085
  • 2.  后勤工程学院,重庆 401331
  • 收稿日期:  2011-04-13
基金项目:

国家自然科学基金资助项目(50921064, 2009D-5006-02-03)

摘要: 采用计算流体力学的方法,探讨了操作条件和物料特性对旋流分离器分离油水效率的影响。旋流器为单锥双入口,其主直径为50 mm,锥角为5.5°。模拟过程中,采用商业用软件'Fluent 6.3’中的雷诺应力模型和欧拉多相流模型来模拟不同条件下油水旋流分离器的分离性能。模拟结果表明,对于本研究的油水旋流分离器,最佳的分流比是10%,最佳的油滴浓度是0.5% (V/V)。在最佳的分流比和油滴浓度下,当进口流速为10.46 m/s时,油水旋流分离器可将15 μm的油滴去除80%以上,油滴的分离界限粒径d50 (50%的分离效率)为9.2 μm。在模拟的基础上,用统计软件STATISTICA 6.0对分离效率与操作条件和物料特性之间的关系进行拟合。通过拟合式预测的分离效率与实测值相吻合,误差小于15%。
