纳米铁对微生物燃料电池启动的影响

肖晓凤; 程迎; 王清萍; 陈祖亮

doi:10.12030/j.cjee.201612193

环境工程学报

纳米铁对微生物燃料电池启动的影响

, , ,

肖晓凤, 程迎, 王清萍, 陈祖亮. 纳米铁对微生物燃料电池启动的影响[J]. 环境工程学报, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

引用本文:

肖晓凤, 程迎, 王清萍, 陈祖亮. 纳米铁对微生物燃料电池启动的影响[J]. 环境工程学报, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

XIAO Xiaofeng, CHENG Ying, WANG Qingping, CHEN Zuliang. Effects of Fe nanoparticles on microbial fuel cells in startup process[J]. Chinese Journal of Environmental Engineering, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

Citation:

XIAO Xiaofeng, CHENG Ying, WANG Qingping, CHEN Zuliang. Effects of Fe nanoparticles on microbial fuel cells in startup process[J]. Chinese Journal of Environmental Engineering, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

纳米铁对微生物燃料电池启动的影响

1.
福建师范大学环境科学与工程学院福建省污染控制与资源循环利用重点实验室, 福州 350007
基金项目:
福建省自然科学基金资助项目（2015J01041）
中图分类号: X131.2

Effects of Fe nanoparticles on microbial fuel cells in startup process

1.
Fujian Key Laboratory of Pollution Control and Resource Reuse, School of Environmental Science and Engineering, Fujian Normal University, Fuzhou 350007, China
Fund Project:

摘要: 设置3组不同阳极底物的微生物燃料电池（microbial fuel cell，MFC）：无添加污泥（对照组）、含化学合成零价纳米铁的污泥（c-nZVI组）和含绿色合成零价纳米铁的污泥（g-nZVI组），拟探究不同来源零价纳米铁（nZVI）对MFC启动的影响。3组MFC经由5个周期启动，实验结果表明，在c-nZVI组和g-nZVI组的启功阶段，高浓度的绿色合成零价纳米铁和化学合成零价纳米铁均对MFC的输出电压产生抑制作用，当MFC成功启动后，零价纳米铁对MFC的输出电压影响不明显。此外，COD去除率、SEM和电化学表征数据表明，绿色合成零价纳米铁相比于化学合成零价纳米铁在电极表面富集程度、对电极表面性质改变以及产电菌活性的抑制作用更弱。
- 微生物燃料电池 /
- 零价纳米铁 /
- 污泥 /
- 抑制产电
Abstract: To explore the impact of different nano zero valent iron (nZVI) on microbial fuel cells (MFC) in the start-up phase, in this study, MFCs were setting up with different anodic substrates:sludge (control group), sludge containing chemical synthetic nZVI (c-nZVI group) and sludge containing green synthetic nZVI (g-nZVI group),respectively, and MFCs tested by five cycles. In the start-up process of g-nZVI group and c-nZVI group, a high concentration of nZVI could inhibit electricity generation, while nZVI made no essentially change in voltage output after MFC starting successfully. The results obtained from COD removal rate, SEM and electrochemical characterization showed that green synthesis of nZVI, was less likely to enrich on the electrode surface, change the surface electronic properties and suppress bacteria activity in anode to compare chemical synthetic nZVI.
- microbial fuel cell /
- nano zero valent iron(nZVI) /
- sludge /
- electricity inhibition

[1]	KELLY P T,HE Z. Nutrients removal and recovery in bioelectrochemical systems:A review[J]. Bioresource Technology, 2014,53:351-360
[2]	ALI I,AL-OTHMAN Z A,ALHARBI O M L. Uptake of pantoprazole drug residue from water using novel synthesized composite iron nano adsorbent[J]. Journal of Molecular Liquids, 2016,218:465-472
[3]	FANG Z,CHEN J,QIU X, et al. Effective removal of antibiotic metronidazole from water by nanoscale zero-valent iron particles[J]. Desalination, 2011,268(1/2/3):60-67
[4]	曾慎亮,翁秀兰,童玉贵,等. 绿色合成纳米铁同时去除水体中的Pb (Ⅱ)和Cd (Ⅱ)[J]. 环境科学学报, 2015,35(11):3538-3544
[5]	KUANG Y,WANG Q,CHEN Z, et al. Heterogeneous Fenton-like oxidation of monochlorobenzene using green synthesis of iron nanoparticles[J]. Journal of Colloid and Interface Science, 2014,410:67-73
[6]	JIANG X,HU J,LIEBER A M, et al. Nanoparticle facilitated extracellular electron transfer in microbial fuel cells[J]. Nano Letter, 2014,14(11):6737-6742
[7]	NEL A E, MÄDLER L, VELEGOL D, et al. Understanding bio-physicochemical interactions at the nano-bio interface[J]. Nature Materials, 2009, 8(7):543-557
[8]	LI Z, GREDEN K, ALVAREZ P J, et al. Adsorbed polymer and NOM limits adhesion and toxicity of nano scale zerovalent iron to E. coli.[J]. Environmental Science & Technology, 2010, 44(9):3462-3467
[9]	AUFFAN M,ROSE J,WIESNER M R, et al. Chemical stability of metallic nanoparticles:A parameter controlling their potential cellular toxicity in vitro[J]. Environmental Pollution, 2009,57(4):1127-1133
[10]	JIANG C,XU X,MEGHARAJ M, et al. Inhibition or promotion of biodegradation of nitrate by Paracoccus sp. in the presence of nanoscale zero-valent iron[J]. Science of The Total Environment, 2015,530-531:241-246
[11]	JIANG C,LIU Y,CHEN Z, et al. Impact of iron-based nanoparticles on microbial denitrification by Paracoccus sp. strain YF1[J]. Aquatic Toxicology, 2013,142:329-335
[12]	刘培文. 生物阴极MFC的构建及其性能研究与纳米材料对MFC的影响[D]. 福州:福建师范大学, 2015
[13]	MALVANKAR N S,LOVLEY D R. Microbial nanowires for bioenergy applications[J]. Current Opinion in Biotechnology, 2014, 27:88-95
[14]	AKHAVAN O,GHADERI E. Escherichia coli bacteria reduce graphene oxide to bactericidal graphene in a self-limiting manner[J]. Carbon, 2012, 50(5):1853-1860
[15]	WU D,SHEN Y,DING A, et al. Effects of nanoscale zero-valent iron particles on biological nitrogen and phosphorus removal and microorganisms in activated sludge[J]. Journal of Hazardous Materials, 2013, 262:649-655
[16]	KANG J,KIM T,TAK Y, et al. Cyclic voltammetry for monitoring bacterial attachment and biofilm formation[J]. Journal of Industrial and Engineering Chemistry, 2012, 18(2):800-807

期刊类型引用(4)

1.	张海丹，张凡志，方仙明，梁震，张光学. 330 MW机组煤粉锅炉耦合油污泥低负荷燃烧数值模拟与试验研究. 热力发电. 2024(03): 153-160 . 百度学术
2.	廖长君，苏建，梁家宇，戴书剑，刘松豪，廖春雨，卢友志. 高浓度石油污染土壤与竹粉共热解实验研究. 山东化工. 2022(10): 212-214 . 百度学术
3.	马蒸钊，谢江浩，邵天泽，肖成磊，刘涛. 基于FLIC的油泥焚烧产物模拟研究. 可再生能源. 2020(02): 158-163 . 百度学术
4.	刘天波，李晋，王庆宏. 炼化企业罐底油泥处理技术研究进展. 安全、健康和环境. 2020(03): 1-4 . 百度学术

其他类型引用(8)

点击查看大图

计量

文章访问数: 2015
HTML全文浏览数: 1547
PDF下载数: 517
施引文献: 12

肖晓凤, 程迎, 王清萍, 陈祖亮. 纳米铁对微生物燃料电池启动的影响[J]. 环境工程学报, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

引用本文:

肖晓凤, 程迎, 王清萍, 陈祖亮. 纳米铁对微生物燃料电池启动的影响[J]. 环境工程学报, 2017, 11(9): 5233-5238. doi: 10.12030/j.cjee.201612193

Citation:

纳米铁对微生物燃料电池启动的影响

1. 福建师范大学环境科学与工程学院福建省污染控制与资源循环利用重点实验室, 福州 350007

收稿日期: 2017-04-12

基金项目:

福建省自然科学基金资助项目（2015J01041）

关键词:

摘要: 设置3组不同阳极底物的微生物燃料电池（microbial fuel cell，MFC）：无添加污泥（对照组）、含化学合成零价纳米铁的污泥（c-nZVI组）和含绿色合成零价纳米铁的污泥（g-nZVI组），拟探究不同来源零价纳米铁（nZVI）对MFC启动的影响。3组MFC经由5个周期启动，实验结果表明，在c-nZVI组和g-nZVI组的启功阶段，高浓度的绿色合成零价纳米铁和化学合成零价纳米铁均对MFC的输出电压产生抑制作用，当MFC成功启动后，零价纳米铁对MFC的输出电压影响不明显。此外，COD去除率、SEM和电化学表征数据表明，绿色合成零价纳米铁相比于化学合成零价纳米铁在电极表面富集程度、对电极表面性质改变以及产电菌活性的抑制作用更弱。

English Abstract

Effects of Fe nanoparticles on microbial fuel cells in startup process

1. Fujian Key Laboratory of Pollution Control and Resource Reuse, School of Environmental Science and Engineering, Fujian Normal University, Fuzhou 350007, China

Received Date: 2017-04-12

Fund Project:

Keywords:

Abstract: To explore the impact of different nano zero valent iron (nZVI) on microbial fuel cells (MFC) in the start-up phase, in this study, MFCs were setting up with different anodic substrates:sludge (control group), sludge containing chemical synthetic nZVI (c-nZVI group) and sludge containing green synthetic nZVI (g-nZVI group),respectively, and MFCs tested by five cycles. In the start-up process of g-nZVI group and c-nZVI group, a high concentration of nZVI could inhibit electricity generation, while nZVI made no essentially change in voltage output after MFC starting successfully. The results obtained from COD removal rate, SEM and electrochemical characterization showed that green synthesis of nZVI, was less likely to enrich on the electrode surface, change the surface electronic properties and suppress bacteria activity in anode to compare chemical synthetic nZVI.
