曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

魏金山, 刘雪瑜, 刘晓玲, 郭继香, 向连城, 宋永会. 曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响[J]. 环境工程学报, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
引用本文: 魏金山, 刘雪瑜, 刘晓玲, 郭继香, 向连城, 宋永会. 曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响[J]. 环境工程学报, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
shu
Wei Jinshan, Liu Xueyu, Liu Xiaoling, Guo Jixiang, Xiang Liancheng, Song Yonghui. Effects of aeration and adding NaOH on phosphorus recovery from anaerobically digested swine wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
Citation: Wei Jinshan, Liu Xueyu, Liu Xiaoling, Guo Jixiang, Xiang Liancheng, Song Yonghui. Effects of aeration and adding NaOH on phosphorus recovery from anaerobically digested swine wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
shu

曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响

  • 1.

    中国环境科学研究院城市水环境科技创新基地, 北京 100012

  • 2.

    中国石油大学(北京)提高采收率研究院, 北京 100049

  • 基金项目:

    国家自然科学基金资助项目(51078339)

  • 中图分类号: X703

Effects of aeration and adding NaOH on phosphorus recovery from anaerobically digested swine wastewater

  • 1.

    Scientific and Technological Innovation Base for Urban Water Environmental Research, Chinese Research Academy of Environmental Sciences, Beijing 100012, China

  • 2.

    Enhanced Oil Recovery Institute, China University of Petroleum, Beijing 100049, China

  • Fund Project:

HTML全文

  • 摘要: 以养猪废水厌氧消化液为对象,通过批次实验比较曝气与投加NaOH 2种方式调节废水pH值对磷回收效率的影响,并进一步采用流化床反应器探讨NaOH调节条件下进水流量对氮磷回收的影响。实验结果表明:采用曝气可促使pH值在1 h内迅速升高至8.6;随着曝气时间不断延长,pH值缓慢增长,至12 h达9.1~9.2,此时正磷酸盐(PO43--P)回收率达87.25%。投加NaOH调节最佳pH值为9.5,PO43--P回收率为85.67%。容积为100 L的搅拌-上向流反应器实验结果表明,当进水流量分别为50、100和150 L/h,在100 L/h流量条件下达到最优,PO43--P回收率为80.22%。利用X射线衍射仪(XRD)和扫描电镜及能谱仪(SEM-EDS)对沉淀产物进行表征,可知沉淀产物中含有磷酸铵镁(MAP)和CaCO3。
    Abstract: This study compared the effects of aeration and the addition of sodium hydroxide (NaOH) on phosphorus (P) recovery from anaerobically digested swine wastewater. Experimental results showed that under the condition of aeration, pH value of solution rose rapidly to 8.6 within 1 h, following slow increase, and then stayed relatively stable at 9.1 to 9.2 after 12 h. The orthophosphate (PO43--P) recovery efficiency was 87.25%. In comparison, by adding NaOH, PO43--P recovery reached maximum at pH 9.5, and the recovery efficiency was 85.67%. In addition, a volume of 100 L stir & upward flowing reactor with NaOH addition for PH adjustment was employed to investigate the effect of influent flow rate (of 50,100 and 150 L/h) on PO43--P recovery. It was found that the optimal influent flow rate was 100 L/h, and 80.22% PO43--P recovery was reached. The results of X-ray diffraction, and scanning electron microscope with energy dispersive spectroscopy (SEM-EDS) showed that the recovered product was mainly composed of magnesium ammonium phosphate (MAP) and CaCO3.
  • [1] 陈蕊, 高怀友, 傅学起, 等. 畜禽养殖废水处理技术的研究与应用. 农业环境科学学报, 2006, 25(S): 374-377 Chen Rui, Gao Huaiyou, Fu Xueqi, et al. Study and application of treatment technology on wastewater from livestock farm. Journal of Agro-Environment Science, 2006, 25(S): 374-377(in Chinese)
    [2] 马泉智, 向连城, 宋永会, 等. 畜禽粪便沼液絮凝预处理及MAP法磷回收技术. 环境工程技术学报, 2013, 3(3): 202-207 Ma Quanzhi, Xiang Liancheng, Song Yonghui, et al. Technology development of flocculating pretreatment of livestock and poultry manure slurry and of phosphorus recovery by MAP crystallization. Journal of Environmental Engineering Technology, 2013, 3(3): 202-207(in Chinese)
    [3] 邓良伟, 蔡昌达, 陈铬铭, 等. 猪场废水厌氧消化液后处理技术研究及工程应用. 农业工程学报, 2002, 18(3): 92-94 Deng Liangwei, Cai Changda, Chen Geming, et al. Study and application of technology for post-treatment of an aerobically digested effluent of piggery wastewater. Transactions of the CSAE, 2002, 18(3): 92-94(in Chinese)
    [4] 万风, 王海燕, 周岳溪, 等. 养猪废水处理技术研究进展. 农业灾害研究, 2012, 2(1): 25-29 Wan Feng, Wang Haiyan, Zhou Yuexi, et al. Research progress on the processing technology of piggery wastewater. Journal of Agricultural Catastrophology, 2012, 2(1): 25-29(in Chinese)
    [5] Rahman M. M., Salleh M. A. M., Rashid U., et al. Production of slow release crystal fertilizer from wastewaters through struvite crystallization: A review. Arabian Journal of Chemistry, 2014, 7(1): 139-155
    [6] 刘健康. 高级水生生物学. 北京: 科学出版社, 1999: 326-338
    [7] Shu L., Schneider P., Jegatheesan V., et al. An economic evaluation of phosphorus recovery as struvite from digester supernatant. Bioresource Technology, 2006, 97(17): 2211-2216
    [8] 胡慧蓉, 郭安, 王海龙. 我国磷资源利用现状与可持续利用的建议. 磷肥与复肥, 2007, 22(2): 1-5 Hu Huirong, Guo An, Wang Hailong. Present status of China's phosphorus resource utilization & some suggestions for sustainable development. Phosphate & Compound Fertilizer, 2007, 22(2): 1-5(in Chinese)
    [9] 许俊香, 刘晓利, 王方浩, 等. 中国畜禽粪尿磷素养分资源分布以及利用状况. 河北农业大学学报, 2005, 28(4): 5-9 Xu Junxiang, Liu Xiaoli, Wang Fanghao, et al. The distribution of phosphorus resources and utilization of animal manure in China. Journal of Agricultural University of Hebei, 2005, 28(4): 5-9(in Chinese)
    [10] 袁鹏, 宋永会, 袁芳, 等. 磷酸铵镁结晶法去除和回收养猪废水中营养元素的实验研究. 环境科学学报, 2007, 27(7): 1127-1134 Yuan Peng, Song Yonghui, Yuan Fang, et al. Nutrient removal and recovery from swine wastewater by crystallization of magnesium ammonium phosphate. Acta Scientiae Circumstantiae, 2007, 27(7): 1127-1134(in Chinese)
    [11] Münch E. V., Barr K. Controlled struvite crystallisation for removing phosphorus from anaerobic digester sidestreams. Water Research, 2001, 35(1): 151-159
    [12] 张棋, 高娜, 赵首萍, 等. 鸟粪石结晶法回收废水中氮磷的研究进展. 四川环境, 2013, 32(1): 105-109 Zhang Qi, Gao Na, Zhao Shouping, et al. Advance of nitrogen-phosphorus recovery by struvite crystallization. Sichuan Environment, 2013, 32(1): 105-109(in Chinese)
    [13] 李士松. 基于MAP法海水混凝处理含氮磷废水的研究. 哈尔滨: 哈尔滨工程大学硕士学位论文, 2013 Li Shisong. Treatment of nitrogen and phosphorus wastewater using seawater coagulation based on MAP method. Harbin: Master Dissertation of Harbin Engineering University, 2013(in Chinese)
    [14] 曾庆玲, 沈春花. 鸟粪石结晶法回收氨氮影响因素的研究. 环境科学与技术, 2012, 35(1): 80-83 Zeng Qingling, Shen Chunhua. Experimental study on recovery of ammonia-nitrogen by struvite precipitation method. Environmental Science & Technology, 2012, 35(1): 80-83(in Chinese)
    [15] 贺君, 赵菲菲, 刘朋静, 等. 海水MAP法去除N、P废水实验研究. 环境科学与管理, 2011, 36(7): 73-75 He Jun, Zhao Feifei, Liu Pengjing, et al. Removal of nitrogen and phosphorus in wastewater by magnesium ammonium phosphate process with seawater. Environmental Science and Management, 2011, 36(7): 73-75(in Chinese)
    [16] Rahaman M. S., Mavinic D. S., Meikleham A., et al. Modeling phosphorus removal and recovery from anaerobic digester supernatant through struvite crystallization in a fluidized bed reactor. Water Research, 2014, 51: 1-10
    [17] 葛杰, 宋永会, 王毅力, 等. 流化床工艺在水处理中的应用研究进展. 环境工程技术学报, 2014, 4(1): 46-52 Ge Jie, Song Yonghui, Wang Yil?????????戠牐?孯??嵥?偳愠牯獦漠湡獰?卬??????坳慥污汲??????潦祬汵敩?????攭瑢?慤氠???獨獮敯獬楯湧杹?瑩桮攠?灡潳瑴敥湷瑡楴慥汲?晴潲牥?獴瑭牥畮癴椮琠敊?牵敲据潡癬攠牯祦?慅瑮?獩敲睯慮杭敥?瑴牡敬愠瑅浮敧湩瑮?睥潲物歮獧???湣癨楮牯潬湯浧敹測琠愲氰?吴攬挠栴渨漱氩漺朠礴??特?〨???至?????????????劳??林郁, 宋永会, 刘菲, 等. 利用白云石石灰去除与回收污泥厌氧消化液中氮和磷. 环境工程学报, 2014, 8(6): 2198-2204 Lin Yu, Song Yonghui, Liu Fei, et al. Nitrogen and phosphorus removal and recovery from anaerobic digestion supernatant of sewage sludge using dolomitic lime. Chinese Journal of Environmental Engineering, 2014, 8(6): 2198-2204(in Chinese)
    [18] 李小平, 魏泉源, 金明军, 等. CO2吹脱提升厌氧发酵液pH值研究. 中国沼气, 2010, 28(3): 3-7 Li Xiaoping, Wei Quanyuan, Jin Mingjun, et al. Increasing the fermentation slurry pH inside digester by CO2 stripping. China Biogas, 2010, 28(3): 3-7(in Chinese)
    [19] 汪慧贞, 王绍贵. pH值对污水处理厂磷回收的影响. 北京建筑工程学院学报, 2004, 20(4): 5-8 Wang Huizhen, Wang Shaogui. Effect of pH to the phosphorus recovery from WWTP. Journal of Beijing Institute of Civil Engineering and Architecture, 2004, 20(4): 5-8(in Chinese)
    [20] 郝晓地, 衣兰凯, 王崇臣, 等. 磷回收技术的研发现状及发展趋势. 环境科学学报, 2010, 30(5): 897-907 Hao Xiaodi, Yi Lankai, Wang Chongchen, et al. Situation and prospects of phosphorus recovery techniques. Acta Scientiae Circumstantiae, 2010, 30(5): 897-907(in Chinese)
    [21] 鲍小丹, 叶志隆, 马建华, 等. 鸟粪石法回收养猪废水中磷时pH对沉淀物组分的影响. 环境科学, 2011, 32(9): 2598-2603 Bao Xiaodan, Ye Zhilong, Ma Jianhua, et al. Effect of pH on precipitate composition during phosphorus recovery as struvite from swine wastewater. Environmental Science, 2011, 32(9): 2598-2603(in Chinese)
    [22] Song Y., Hahn H. H., Hoffmann E. The effect of carbonate on the precipitation of calcium phosphate. Environmental Technology, 2002, 23(2): 207-215
    [23] Nelson N. O., Mikkelsen R. L., Hesterberg D. L. Struvite precipitation in anaerobic swine lagoon liquid: Effect of pH and Mg:P ratio and determination of rate constant. Bioresource Technology, 2003, 89(3): 229-236
    [24] Ohlinger K. H., Young T. M., Schroeder E. D. Postdigestion struvite precipitation using a fluidized bed reactor. Journal of Environmental Engineering, 2000, 126(4):
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1909
  • HTML全文浏览数:  1638
  • PDF下载数:  336
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-01-18
  • 刊出日期:  2016-06-03
魏金山, 刘雪瑜, 刘晓玲, 郭继香, 向连城, 宋永会. 曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响[J]. 环境工程学报, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
引用本文: 魏金山, 刘雪瑜, 刘晓玲, 郭继香, 向连城, 宋永会. 曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响[J]. 环境工程学报, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
shu
Wei Jinshan, Liu Xueyu, Liu Xiaoling, Guo Jixiang, Xiang Liancheng, Song Yonghui. Effects of aeration and adding NaOH on phosphorus recovery from anaerobically digested swine wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
Citation: Wei Jinshan, Liu Xueyu, Liu Xiaoling, Guo Jixiang, Xiang Liancheng, Song Yonghui. Effects of aeration and adding NaOH on phosphorus recovery from anaerobically digested swine wastewater[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2265-2272. doi: 10.12030/j.cjee.201412250
shu

曝气与投加NaOH对养猪废水厌氧消化液磷回收的影响

  • 1.  中国环境科学研究院城市水环境科技创新基地, 北京 100012
  • 2.  中国石油大学(北京)提高采收率研究院, 北京 100049
  • 收稿日期:  2015-01-18
基金项目:

国家自然科学基金资助项目(51078339)

摘要: 以养猪废水厌氧消化液为对象,通过批次实验比较曝气与投加NaOH 2种方式调节废水pH值对磷回收效率的影响,并进一步采用流化床反应器探讨NaOH调节条件下进水流量对氮磷回收的影响。实验结果表明:采用曝气可促使pH值在1 h内迅速升高至8.6;随着曝气时间不断延长,pH值缓慢增长,至12 h达9.1~9.2,此时正磷酸盐(PO43--P)回收率达87.25%。投加NaOH调节最佳pH值为9.5,PO43--P回收率为85.67%。容积为100 L的搅拌-上向流反应器实验结果表明,当进水流量分别为50、100和150 L/h,在100 L/h流量条件下达到最优,PO43--P回收率为80.22%。利用X射线衍射仪(XRD)和扫描电镜及能谱仪(SEM-EDS)对沉淀产物进行表征,可知沉淀产物中含有磷酸铵镁(MAP)和CaCO3。
