低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放

,  ,  ,  ,

downloadPDF

上一篇

下一篇

苏会波, 林海龙, 武国庆, 靖苏铜, 石则强. 低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放[J]. 环境工程学报, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
引用本文: 苏会波, 林海龙, 武国庆, 靖苏铜, 石则强. 低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放[J]. 环境工程学报, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
shu
Su Huibo, Lin Hailong, Wu Guoqing, Jing Sutong, Shi Zeqiang. Condensate water and pollutants emission from ethanol gasoline and regular gasoline in low-temperature environment[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
Citation: Su Huibo, Lin Hailong, Wu Guoqing, Jing Sutong, Shi Zeqiang. Condensate water and pollutants emission from ethanol gasoline and regular gasoline in low-temperature environment[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
shu

低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放

  • 1.

    中粮营养健康研究院, 国家能源生物液体燃料研发中心, 北京 102209

  • 2.

    交通运输部公路科学研究院, 北京 100088

  • 基金项目:

    国家高技术研究发展计划(863)项目(2012AA022304)

  • 中图分类号: X511

Condensate water and pollutants emission from ethanol gasoline and regular gasoline in low-temperature environment

  • 1.

    COFCO Nutrition and Health Institute, National Energy R&D Center for Liquid Biofuels, Beijing 102209, China

  • 2.

    Research Institute of Highway, Ministry of Transport, Beijing 100088, China

  • Fund Project:

HTML全文

  • 摘要: 对低温环境中乙醇汽油和普通汽油的冷凝水、CO、HC、NOx和CO2排放特性进行了研究,并对5种排放物的形成机理和排放趋势进行了分析。ECE工况(-20、-10和0 ℃)和怠速工况(-30、-20、-10和0 ℃)下,乙醇汽油和普通汽油的冷凝水排放量主要受含氢量、车辆构造和外界环境的共同影响。ECE工况中冷凝水的总体排放趋势是随着温度降低而增加,乙醇汽油的总排水量持平或略低于普通汽油。-10 ℃时乙醇汽油的高含氧量能促进燃烧速度和燃烧效率,减少CO和HC排放,增加NOx排放;0 ℃时低温环境和乙醇的高汽化潜热会影响可燃混合气形成和燃烧速度,降低缸壁温度,增加CO和HC排放。
    Abstract: The emissions characteristics and trends of condensate water, carbon monoxide (CO), hydrocarbon (HC), nitrogen oxides (NOx), and carbon dioxide (CO2) from ethanol gasoline and regular gasoline in a low-temperature environment were studied, and the formation mechanisms were analyzed. Under ECE conditions (-2, -10 and 0 ℃) and idling conditions (-30, -20, -10 and 0 ℃), the condensate water discharge of ethanol gasoline and regular gasoline were mainly affected by the hydrogen content, vehicle structure, and external environment. Generally, condensate water in ECE conditions increased as temperatures decreased, while the total water amount from ethanol gasoline was equivalent to or less than that from regular gasoline. At -10 ℃, the high oxygen content in ethanol gasoline could promote the velocity and combustion of combustion, which could then decrease CO and HC emissions, as well as increase NOx emissions. At 0 ℃, the high latent heat of vaporization and low environment temperature could affect the formation and combustion velocity of the inflammable mixture, which could increase CO and HC emissions.
  • [1] Guo Song, Hu Min, Zamora M. L., et al. Elucidating severe urban haze formation in China. Proceedings of the National Academy of Sciences of the United States of Ameirca, 2014, 111(49): 17373-17378
    [2] Huang Rujin, Zhang Yanlin, Bozzetti C., et al. High secondary aerosol contribution to particulate pollution during haze events in China. Nature, 2014, 514(7521): 218-222
    [3] 朱振明, 王长生, 闫学军. 普通车用汽油和E10乙醇汽油对汽车尾气排放的影响调查. 预防医学论坛, 2006, 12(5): 561-562 Zhu Zhenming, Wang Changsheng, Yan Xuejun. The detection analysis on auto-exhaust of the gasoline used by local vehicle and E10 ethanol. Preventive Medicine Tribune, 2006, 12(5): 561-562(in Chinese)
    [4] 刘圣华, 魏衍举, 吕胜春, 等. 乙醇汽油发动机排放特性研究. 西安交通大学学报, 2006, 40(7): 745-747 Liu Shenghua, Wei Yanju, Lü Shengchun, et al. Study on emission characteristics of gasohol engine. Journal of Xi'an Jiaotong University, 2006, 40(7): 745-747(in Chinese)
    [5] 彭华, 吴新杰, 李明. 汽车使用乙醇汽油后排放污染物变化趋势. 城市环境与城市生态, 2004, 17(3): 43-44 Peng Hua, Wu Xinjie, Li Ming. Variational trend of contaminatants after using the benizine with ethanol. Urban Environment & Urban Ecology, 2004, 17(3): 43-44(in Chinese)
    [6] 梁宾, 葛蕴珊, 谭建伟, 等. 汽油车燃用乙醇汽油的颗粒物与醛酮排放特性. 燃烧科学与技术, 2013, 19(4): 341-346 Liang Bin, Ge Yunshan, Tan Jianwei, et al. Particles, aldehydes and ketones emitted from a gasoline vehicle fueled with E10 ethanol gasoline. Journal of Combustion Science and Technology, 2013, 19(4): 341-346(in Chinese)
    [7] Beer T., Carras J., Worth D., et al. The health impacts of ethanol blend petrol. Energies, 2011, 4(2): 352-367
    [8] Storey J. M., Barone T., Norman K., et al. Ethanol blend effects on direct injection spark-ignition gasoline vehicle particulate matter emissions. SAE International Journal of Fuels and Lubricants, 2010, 3(2): 650-659
    [9] 强添纲. 低温条件下燃用乙醇汽油对汽车使用性能及城市交通的影响. 哈尔滨: 东北林业大学博士学位论文, 2012 Qiang Tiangang. Study of vehicle performance and influence on urban traffic with gasohol at low temperature. Harbin: Doctor Dissertation of Northease Forestry University, 2012(in Chinese)
    [10] 靖苏铜, 王伟, 石则强, 等. 低温条件下燃用汽油和乙醇汽油车辆排水特性的研究. 交通节能与环保, 2014, 10(3): 25-28 Jing Sutong, Wang Wei, Shi Zeqiang, et al. Research on the performance of water emission of vehicle using gasoline or ethanol gasoline in low-temperature environment. Energy Conservation & Environmental Protection in Transportation, 2014, 10(3): 25-28(in Chinese)
    [11] 臧杰. 乙醇汽油车冬季滴水问题研究. 内燃机, 2010(3): 16-18 Zang Jie. Research on dripping water of ethanol-gasoline vehicle in winter. Internal Combustion Engines, 2010(3): 16-18(in Chinese)
    [12] 苏会波, 林海龙, 李凡, 等. 乙醇汽油对减少机动车污染排放的机理研究与分析. 环境工程学报, 2015, 9(2): 823-829 Su Huibo, Lin Hailong, Li Fan, et al. Mechanism study and analysis on emission reduction of pollutants with ethanol gasoline. Chinese Journal of Environmental Engineering, 2015, 9(2): 823-829(in Chinese)
    [13] 刘全根. 乙醇汽油的应用. 炼油设计, 2002, 32(2): 40-43 Liu Quangen. Application of ethanol gasoline. Petroleum Refinery Engineering, 2002, 32(2): 40-43(in Chinese)
    [14] 郭美华, 杜宝杰, 李岳林. 乙醇汽油混合燃料的排放特性研究. 内燃机, 2010(6): 45-48 Guo Meihua, Du Baojie, Li Yuelin. Research on emission characteristics of ethanol-gasoline blends. Internal Combustion Engines, 2010(6): 45-48(in Chinese)
    [15] 王春杰, 王玮, 汤大钢, 等. 车用乙醇汽油和无铅汽油对电喷汽车排放性能的影响. 环境科学, 2004, 25(4): 113-116 Wang Chunjie, Wang Wei, Tang Dagang, et al. Effect of ethanol gasoline and unleaded gasoline on exhaust emissions of EFI vehicles with TWC. Environmental Science, 2004, 25(4): 113-116(in Chinese)
    [16] 肖干, 张煜盛, 郎静, 等. 进气温度对汽油直喷压燃发动机燃烧及排放性能影响的实验. 内燃机学报, 2014, 32(2): 125-130 Xiao Gan, Zhang Yusheng, Lang Jing, et al. Experiment of the effects of intake temperature on GCI engine combustion and emission characteristics. Transactions of CSICE, 2014, 32(2): 125-130(in Chinese)
    [17] 赵清华, 吴心平. 乙醇汽油对发动机的CO/HC排放影响研究. 汽车实用技术, 2012(8): 35-37 Zhao Qinghua, Wu Xinping. CO/HC emissions analysis of engine used ethanol gasoline. Automobile Applied Technology, 2012(8): 35-37(in Chinese)
    [18] 刘少华, 申立中, 叶年业, 等. E10含水乙醇汽油对汽油机性能及排放的影响研究. 内燃机工程, 2012, 33(5): 46-51 Liu Shaohua, Shen Lizhong, Ye Nianye, et al. Research on effects of E10 hydroous ethanol gasoline blend on performance and emissions of gasoline engine. Chinese Internal Combution Engine Engineering, 2012, 33(5): 46-51(in Chinese)
    [19] Al-Hasan M. Effect of ethanol-unleaded gasoline blends on engine performance and exhaust emission. Energy Conversion and Management, 2003, 44(9): 1547-1561
    [20] Yükesl F., Yüksel B. The use of ethanol-gasoline blend as a fuel in an SI engine. Renewable Energy, 2004, 29(7): 1181-1191
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1835
  • HTML全文浏览数:  1440
  • PDF下载数:  807
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-01-08
  • 刊出日期:  2016-06-03
苏会波, 林海龙, 武国庆, 靖苏铜, 石则强. 低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放[J]. 环境工程学报, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
引用本文: 苏会波, 林海龙, 武国庆, 靖苏铜, 石则强. 低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放[J]. 环境工程学报, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
shu
Su Huibo, Lin Hailong, Wu Guoqing, Jing Sutong, Shi Zeqiang. Condensate water and pollutants emission from ethanol gasoline and regular gasoline in low-temperature environment[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
Citation: Su Huibo, Lin Hailong, Wu Guoqing, Jing Sutong, Shi Zeqiang. Condensate water and pollutants emission from ethanol gasoline and regular gasoline in low-temperature environment[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2519-2526. doi: 10.12030/j.cjee.201412140
shu

低温环境中乙醇汽油和普通汽油的冷凝水与污染物排放

  • 1. 中粮营养健康研究院, 国家能源生物液体燃料研发中心, 北京 102209
  • 2. 交通运输部公路科学研究院, 北京 100088
  • 收稿日期:  2015-01-08
基金项目:

国家高技术研究发展计划(863)项目(2012AA022304)

摘要: 对低温环境中乙醇汽油和普通汽油的冷凝水、CO、HC、NOx和CO2排放特性进行了研究,并对5种排放物的形成机理和排放趋势进行了分析。ECE工况(-20、-10和0 ℃)和怠速工况(-30、-20、-10和0 ℃)下,乙醇汽油和普通汽油的冷凝水排放量主要受含氢量、车辆构造和外界环境的共同影响。ECE工况中冷凝水的总体排放趋势是随着温度降低而增加,乙醇汽油的总排水量持平或略低于普通汽油。-10 ℃时乙醇汽油的高含氧量能促进燃烧速度和燃烧效率,减少CO和HC排放,增加NOx排放;0 ℃时低温环境和乙醇的高汽化潜热会影响可燃混合气形成和燃烧速度,降低缸壁温度,增加CO和HC排放。
