湿式电除尘器对烟气中颗粒物的去除特性

,  ,  ,  ,

downloadPDF

上一篇

下一篇

沈志刚, 刘启贞, 陶雷行, 徐建刚, 徐淑红. 湿式电除尘器对烟气中颗粒物的去除特性[J]. 环境工程学报, 2016, 10(5): 2557-2561. doi: 10.12030/j.cjee.201412096
引用本文: 沈志刚, 刘启贞, 陶雷行, 徐建刚, 徐淑红. 湿式电除尘器对烟气中颗粒物的去除特性[J]. 环境工程学报, 2016, 10(5): 2557-2561. doi: 10.12030/j.cjee.201412096
shu
Shen Zhigang, Liu Qizhen, Tao Leixing, Xu Jiangang, Xu Shuhong. Removal characteristics of particulate matters in flue gas by wet electrostatic precipitator[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2557-2561. doi: 10.12030/j.cjee.201412096
Citation: Shen Zhigang, Liu Qizhen, Tao Leixing, Xu Jiangang, Xu Shuhong. Removal characteristics of particulate matters in flue gas by wet electrostatic precipitator[J]. Chinese Journal of Environmental Engineering, 2016, 10(5): 2557-2561. doi: 10.12030/j.cjee.201412096
shu

湿式电除尘器对烟气中颗粒物的去除特性

  • 1.

    上海申欣环保实业有限公司, 上海 200233

  • 2.

    上海市环境监测中心, 上海 200235

  • 3.

    上海明华电力技术工程有限公司, 上海 200437

  • 基金项目:

    上海市环保科研项目(沪环科2013-14,2015-42)

  • 中图分类号: X513

Removal characteristics of particulate matters in flue gas by wet electrostatic precipitator

  • 1.

    Shanghai Oriental Enviro-Industry Co. Ltd., Shanghai 200233, China

  • 2.

    Shanghai Environmental Monitoring Center, Shanghai 200235, China

  • 3.

    Minghua Electric Power Technology & Engineering Co. Ltd., Shanghai 200437, China

  • Fund Project:

HTML全文

  • 摘要: 当前,中国以PM2.5为代表的灰霾污染形势依然严峻,采取更为严格的措施进一步降低燃煤电厂等重点大气污染源排放已成必然趋势。湿式电除尘器(WESP)由于具有去除PM2.5等细颗粒物的能力而被越来越多的电厂选用。对上海长兴岛第二发电厂烟气中可过滤颗粒物(FPM)、可凝结颗粒物(CPM)、SO3、液滴等关键指标进行了测试分析。结果表明,在湿式电除尘器停运和运行时,烟囱中总颗粒物(TPM)排放浓度分别为30.31 mg/m3和15.74 mg/m3,FPM排放浓度分别为20.31 mg/m3和6.09 mg/m3,PM2.5排放浓度分别为4.06 mg/m3和2.50 mg/m3,CPM分别占TPM的33%和61%,SO3排放浓度分别为4.51 mg/m3和3.06 mg/m3,液滴排放浓度分别为114 mg/m3和102 mg/m3。测试证明,湿式电除尘器的投运对颗粒物和液滴的去除均有明显效果。
    Abstract: Haze pollution involving PM2.5 is currently a serious problem in China, and the implementation of tougher measures to further reduce emissions from key air pollution sources such as coal-fired power plants has become an inevitable trend. Wet electrostatic precipitator (WESP) technology is being adopted by an increasing number of power plants due to its ability to remove PM2.5 and other fine particulate matter. In this study, key indicators such as filterable particulate matter (FPM), condensable particulate matter (CPM), sulfur trioxide (SO3), and droplets in the flue gas of Shanghai Changxing Island No. 2 Power Plant were measured and analyzed. The results indicated that the emission concentrations of total particulate matter (TPM) were 30.31 mg/m3 and 15.74 mg/m3, FPM were 20.31 mg/m3 and 6.09 mg/m3, PM2.5 were 4.06 mg/m3 and 2.50 mg/m3, SO3 were 4.51 mg/m3 and 3.06 mg/m3, and droplets were 114 mg/m3 and 102 mg/m3 at the stack when the WESP was turned off or on, respectively. Similarly, CPM accounted for 33% and 61% of TPM, respectively. This study demonstrates that the utilization of WESP technology has a significant effect on the removal of particulate matter and droplets.
  • [1] 王颖聪. 湿法脱硫烟气石膏雨成因分析及处理方案综述. 华北电力技术, 2012(10): 68-71 Wang Yingcong. Analysis and solution to gypsum rain of wet flue gas desulfurization. North China Electric Power, 2012(10): 68-71(in Chinese)
    [2] 李春雨. 火电厂湿法烟气脱硫中"石膏雨"问题分析. 能源工程, 2012(1): 43-47 Li Chunyu. Analysis for gypsum rain of wet flue gas desulfurization system. Energy Engineering, 2012(1): 43-47(in Chinese)
    [3] 曾庭华, 杨华, 廖永进, 等. 湿法烟气脱硫系统的调试、实验及运行. 北京: 中国电力出版社, 2008
    [4] 李晓金, 甄志. 取消GGH后湿法烟气脱硫系统设计方案. 中国电力, 2010, 43(11): 56-59 Li Xiaojin, Zhen Zhi. Discussion on wet flue gas desulfurization system scheme for uninstalling GGH. Electric Power, 2010, 43(11): 56-59(in Chinese)
    [5] 陈牧. 湿法脱硫后烟囱出口烟气液滴夹带问题分析及解决. 电力建设, 2010, 31(10): 80-83 Chen Mu. Analysis of the liquid drips carried by flue gas at the outlet of stack after wet desulfurization. Electric Power Construction, 2010, 31(10): 80-83(in Chinese)
    [6] 裴冰. 固定源排气中可凝结颗粒物排放与测试探讨. 中国环境监测, 2010, 26(6): 9-12 Pei Bing. Discussion on the emission issues and testing of condensable particulate matter from exhaust gas of stationary source. Environmental Monitoring in China, 2010, 26(6): 9-12(in Chinese)
    [7] Corio L. A., Sherwell J. In-stack condensible particulate matter measurements and issues. Journal of the Air & Waste Management Association, 2000, 50(2): 207-218
    [8] 董雪玲, 刘大锰, 袁杨森, 等. 北京市2005年夏季大气颗粒物污染特征及影响因素. 环境工程学报, 2007, 1(9): 100-104 Dong Xueling, Liu Dameng, Yuan Yangsen, et al. Pollution characteristics and influencing factors of atmospheric particulates in Beijing during the summer of 2005. Chinese Journal of Environmental Engineering, 2007, 1(9): 100-104(in Chinese)
    [9] 王冰, 张承中, 周变红, 等. 西安南郊采暖期大气颗粒物PM2.5的污染特征分析. 环境工程学报, 2009, 3(9): 1635-1638 Wang Bing, Zhang Chengzhong, Zhou Bianhong, et al. Characteristics of atmospheric particulate pollution PM2.5 during the heating period in the south of Xi'an. Chinese Journal of Environmental Engineering, 2009, 3(9): 1635-1638(in Chinese)
    [10] 黄丽坤, 王广智, 王琨, 等. 哈尔滨市采暖与非采暖期大气颗粒物污染特性研究. 环境工程学报, 2011, 5(1): 146-150 Huang Likun, Wang Guangzhi, Wang Kun, et al. Pollution properties of atmospheric particles in Harbin during heating and non-heating periods. Chinese Journal of Environmental Engineering, 2011, 5(1): 146-150(in Chinese)
    [11] 李礼, 余家燕, 鲍雷, 等. 重庆主城区春季典型天气的大气颗粒物浓度变化分析. 环境工程学报, 2012, 6(6): 2012-2016 Li Li, Yu Jiayan, Bao Lei, et al. Concentration analysis of atmospheric particulate matter under typical spring weather condition in Chongqing. Chinese Journal of Environmental Engineering, 2012, 6(6): 2012-2016(in Chinese)
    [12] Lu Ping, Wu Jiang, Pan Weiping. Particulate matter emissions from a coal-fired power plant//Proceedings of the 4th International Conference on Bioinformatics and Biomedical Engineering (iCBBE). Chengdu, China: IEEE, 2010: 1-4
    [13] EPA. Method 201A: Determination of PM10 and PM2.5 Emissions from Stationary Source. U.S. Environmental Protection Agency, 2010
    [14] EPA. Method 202: Dry Impinger Method for Determining Condensable Particulate Emissions from Stationary Source. U.S. Environmental Protection Agency, 2010
    [15] EPA. Method 8A: Determination of Sulfuric Acid Vapor or Mist and Sulfur Dioxide Emissions from Kraft Recovery Furnaces. U.S. Environmental Protection Agency, 1997
    [16] 中华人民共和国国家质量监督检验检疫总局,国家标准化管理委员会. GB/T 21508-2008 燃煤烟气脱硫设备性能测试方法. 北京: 中国标准出版社, 2008
